Description of washing machine
1. Front panel
2. Detergent dispenser
3. Door
4. Filter lid
Technical information
5. Adjustable legs
6. Water outlet hose
7. Water inlet hose
8. Main power cable
Dimensions (w x d x h):
600 mm x 600 mm x 850 mm
Dimensions (w x d x h):
600 mm x 440 mm x 850 mm
Depth with door open:
106 cm / 88 cm (depending on model)
Weight (net): 79 kg
Nominal voltage: 120 V, 60 Hz
Power: 1500 W
Max. load: 15 lbs (7kg)
Power socket: 120 V, 15 A, 60 Hz
Water pressure:
min. 7 psi (0,05 MPa, max. 116 psi (0,8 MPa)
Fuse: 15 A
3
