Instruction Manual
6.
Batteries
Your Sovereign Elite is supplied with a rechargeable 12 Volt NiMH
battery pack and mains charger. A car charger is also available as an
accessory item from your authorised Minelab Dealer.
6.1
Installation of NiMH Battery Pack
a) Ensure your NiMH pack is fully charged.
b) Place the base of the battery pack at the
rear of the battery compartment (A). Push
the front edge of the battery pack into
position (B). The two battery clips will
"click" into position to hold the battery pack
in place (see figure 9).
Note: The NiMH battery pack is factory sealed
and does not open.
6.2
Installation of Alkaline Batteries
A 12 Volt battery pack to hold 8 'AA' alkaline batteries is available as an
accessory item. These are useful to have as back-up if ever your NiMH
batteries are flat.
a) Ensure the detector is switched "Off" before opening the battery
compartment.
b) Slide open the lid on the battery pack.
c) Place 8 "AA" alkaline batteries (16) into the
base of the alkaline pack (15). Ensure they
are aligned as shown in figure 10 and as
indicated inside the compartment.
d) Slide the battery lid closed.
e) Place the base of the battery pack at the rear of the battery
compartment (A). Push the front edge of the battery pack firmly into
position (B). The two battery clips will "click" into position to securely
hold your battery pack in place (see figure 9).
Page 13
B
A
Figure 9 - Installing
the battery pack
16
Figure 10 - Replacing
the battery lid
P0575-A
15
