Instruction Manual
LOW
CONDUCTIVITY
DISC
FERROUS
Figure 16 - Ignoring targets using the Notch control
When using the Notch and Disc controls in combination, most
unwanted objects can be successfully ignored (see Figure 16). Turning
the Notch control to ignore the pull-tab and the Disc control to ignore the
aluminium foil will set up the Sovereign Elite to ignore pull-tabs and
aluminium foil while still detecting most valuable non-ferrous objects (see
figure 17).
Note: Different pull-tabs may require a slight movement of the Notch
setting.
LOW
CONDUCTIVITY
DISC
FERROUS
Figure 17 - Ignoring targets using the Disc and Notch controls
CONDUCTIVITY
FOIL LOW COINS
AND RINGS
IGNORED
CONDUCTIVITY
FOIL LOW COINS
AND RINGS
IGNORED
NOTCH
PULL-TABS HIGH COINS
AND RINGS
NON-FERROUS
ACCEPTED
NOTCH
PULL-TABS HIGH COINS
AND RINGS
NON-FERROUS
ACCEPTED
Page 9
HIGH
CONDUCTIVITY
COPPER, SILVER,
BRASS and LEAD
P0236-C
HIGH
CONDUCTIVITY
COPPER, SILVER,
BRASS and LEAD
P0236-D
