Majestic fireplaces NVSTR36 Installation And Operating Manual
Majestic fireplaces NVSTR36 Installation And Operating Manual

Majestic fireplaces NVSTR36 Installation And Operating Manual

Decorative gas appliance

Advertisement

INSTALLER/CONSUMER

SAFETY INFORMATION

PLEASE READ THIS MANUAL
BEFORE INSTALLING AND USING
APPLIANCE.
IMPORTANT: Read all instructions
and warnings carefully before start-
ing installation. Failure to follow these
instructions may
result in a possible fire hazard
and will void the warranty.
WARNING: If the information in
this manual is not followed
exactly, a fire or explosion may result
causing property damage, personal in-
jury or loss of life.
FOR YOUR SAFETY:
Installation and service must be per-
formed by a qualified installer, service
agency, or the gas supplier. Do not
store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of
this or any other appliance.
FO R YOUR SAFETY,
if you smell gas:
1. Open windows.
2. Do not touch electrical switches.
3. Do not try to light any appliance.
4. Extinguish any open flame.
5. Do not use the phone in your build-
ing.
6. Immediately call your gas supplier
from a neighbor's phone.
7. Follow your gas supplier's instruc-
tions.
8. If you cannot reach your gas sup-
plier, call the fire department.
Decorative Gas Appliance
Models: NVSTR36
NVCVR36
Homeowner's Installation and
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
NVCVR36
FP653_NVSTR_NVCVR_nu_cvr
3/28/98
rev. 08-20-02
Operating Manual
NVSTR36
rjs
7412958 7/06 Rev. 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVSTR36 and is the answer not in the manual?

Questions and answers

Joseph Calhoun
February 2, 2025

Do you sell glass doors for this NVSTR36RN fireplace unit

User image 679f6c65990d9
1 comments:
Mr. Anderson
February 10, 2025

Yes, Majestic Fireplaces sells glass doors for the NVSTR36RN fireplace unit. Both bi-fold and single panel glass doors are available as accessories.

This answer is automatically generated

Summary of Contents for Majestic fireplaces NVSTR36

  • Page 1: Safety Information

    Decorative Gas Appliance Models: NVSTR36 NVCVR36 INSTALLER/CONSUMER SAFETY INFORMATION PLEASE READ THIS MANUAL NVSTR36 BEFORE INSTALLING AND USING APPLIANCE. IMPORTANT: Read all instructions and warnings carefully before start- ing installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty.
  • Page 2: Table Of Contents

    NVSTR/ NVCVR Series Table of Contents Thank you, and Congratulations on your purchase of a CFM Corporation Fireplace. PLEASE READ THESE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING THE APPLIANCE. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty.
  • Page 3: Installation & Operating Instructions

    NVSTR/ NVCVR Series Installation & Operating Instructions This gas appliance should be installed by a qualified in- Description staller in accordance with local building codes and with current CSA-B149.1 Installation codes for Gas Burning NVSTR / NVCVR Series are radiant, natural draft appli- Appliances and Equipment.
  • Page 4: Fireplace Framing And Specification Dimensions

    (191mm) ��" ����" 40���" 3���" 3���" (305mm) (165mm) (1029mm) (90mm) (79mm) FP651 Fig. 1 NVSTR36 Series specification and framing dimensions. FP651 NVSTR36 NVCVR36 Series Gas Appliance, Cove Model 3/30/98 ���" (16mm) Framing Recess 6" DIA. Rough �����" (578mm) Opening Depth Recessed ���"...
  • Page 5: Clearance To Combustibles

    NVSTR/ NVCVR Series Clearance to Combustibles Appliances Top ............0” (0 mm) Bottom ............. 0” (0 mm) Side ............0” (0 mm) Back ............0” (0 mm) Perpendicular Sidewall ....... 6” (152 mm) Top of unit to ceiling ......36” (914 mm) Front of unit to combustibles .....
  • Page 6: Framing And Finishing

    5.5" w.c. 11.0" w.c. Figure 4. Maximum Inlet Pressure 14.0" w.c. 14.0" w.c. Manifold Pressure 3.5" w.c. 10.0" w.c. NVSTR36 / NVCVR36 Nail top standoffs Certified To Nail eight (8) ANSI Z21.50b–2002/ CSA 2.22b–2002 side-nailing flanges Vented Gas Fireplace Units: F34AR6, F34BR6, F34HR6, F34AR9, F34HR9...
  • Page 7: Parts Identification And Chase Installation

    NVSTR/ NVCVR Series Parts Identification and Chase Installation (Insulation methods shown are optional for cold climate, not a requirement for unit operation.) Termination Cap NVSTR Storm Collar Pan Flashing Batt Insulation (cut out around firestop) Draftstop Firestop Ceiling Level Header* Standoff Surround Nailing Flange...
  • Page 8: Gas Line Installation

    NVSTR/ NVCVR Series 2. Attach wire to switch and install switch into recep- Gas Line Installation tacle box. Attach cover plate to switch. If gas piping is not yet completed from the source to the 3. Connect wiring to gas valve. Refer to Figure 7 or 8 appliance location, install the required pipe.
  • Page 9: Eb-1 Electrical Box

    NVSTR/ NVCVR Series EB-1 Electrical Box Install the Venting System, Flashing, and Termination The fireplace, when installed, must be electrically connected and grounded in See venting installation instructions provided by the B- accordance with local codes or, in the ab- Vent manufacturer.
  • Page 10: Venting Runs

    NVSTR/ NVCVR Series Venting Runs Horizontal Run (in feet) Horizontal Run (in feet) 10 12 14 16 18 20 9 10 = Acceptable venting configuration = Unacceptable venting configuration FP567a A: Vertical installations up to 40 feet (12.2 m) in Venting = Acceptable venting configuration height.
  • Page 11: Operating Instructions

    Replacement glass is available through your The lava rock provided with this fireplace must be Majestic Fireplaces dealer and should only be placed on the firebox base on either side of the burner installed by a licensed qualified service person.
  • Page 12: Flame Adjustment

    NVSTR/ NVCVR Series Log, Left Front, Right Rear Cross 20005441 Log, Right Front, Left Rear Cross Log 20005442 Log, Right Front 20005446 Log, Left Front 20005445 Log, End 3079168 NVCVR Log, Left Rear Only 20005443 Log, Right Rear 20005444 Log, Log, Left Front, Right Front, Left Right Rear Cross...
  • Page 13: Lighting And Operating Instructions

    NVSTR/ NVCVR Series Lighting and Operating Instructions FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- •...
  • Page 14 NVSTR/ NVCVR Series Lighting and Operating Instructions For Fireplaces equipped with SIT822 Gas Valve (EN or EP) Warning:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury and loss of life. FOR YOUR SAFETY READ THE FOLLOWING WARNINGS BEFORE LIGHTING THE APPLIANCE neighbor’s phone.
  • Page 15: Troubleshooting

    NVSTR/ NVCVR Series Troubleshooting Nova SIT 820 Standing Pilot START CHECK • Supply Line Hooked up Gas Supply On • Shutoff Valve Open • Lockout has engaged. Wait 60 seconds and try again. • Piezo not tight enough for good ground.
  • Page 16 NVSTR/ NVCVR Series Troubleshooting NOVA SIT 822 w/ Honeywell S8600 B Electronic Ignition Remove glass panel before servicing. START CHECK : • Line Voltage (120VAC) • Turn gas supply off • Low Voltage Transformer • Turn ON/OFF Switch (19.5 minimum VAC) to call for heat.
  • Page 17: Maintenance

    NVSTR/ NVCVR Series Maintenance Keep the control compartment, logs and burner area Cleaning Automatic Direct surrounding the logs clean by vacuuming or brushing at Electronic Ignition System least twice a year. THE LOGS CAN GET VERY HOT — HANDLE ONLY WHEN COOL. The Electronic Ignition burner/ control system consists Always turn off gas to the pilot before cleaning.
  • Page 18: Replacement Parts 4/30/98

    NVSTR/ NVCVR Series 35a,b 3a,b Nova SIT 822 Valve Nova SIT 820 Valve 1 NVSTR/ NVCVR36 Logs 12a/b 24a/b 5a/b 25a/b MVPV SENSE SPARK (BURNER) 4a/b CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice.
  • Page 19 NVSTR/ NVCVR Series NVSTR/ CVR (F34) (continued) Ref. Description Part Number Burner Orifice - Natural 20005480 Burner Orifice - LP 20005481 Orifice, Pilot, #62 Top Conv. 10002268 Orifice, Pilot, #35 Top Conv. 10002269 Pilot Assembly 3-way N/DV RN Top Conv. 10002264 Pilot Assembly 3-way N/DV RP Top Conv.
  • Page 20 NVSTR/ NVCVR Series Contact CFM Corporation for questions concerning Model and serial numbers are listed on the rat- prices and policies covering replacement parts. Parts ing plate (located on right side of combustion may be ordered through your CFM Corporation distribu- chamber).
  • Page 21: Accessories

    NVSTR/ NVCVR Series Accessories Glass Doors Bi-fold and single panel glass doors are available to enhance the viewing of the fireplace. Unit Models Description Thermal Vent Damper NVSTR/CVR 36GSKBB Brushed Brass Solid Glass Screws Panel NVSTR/CVR 36GDKBB Brushed Brass Bi-fold NVSTR/CVR 36GDKBK Black Bi-fold NVSTR/CVR 36GDKDP Polished Brass Bi-fold...
  • Page 22 NVSTR/ NVCVR Series 7412958...
  • Page 23: Warranty

    NVSTR/ NVCVR Series LIMITED LIFETIME WARRANTY PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic or Northern Flame brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY •...
  • Page 24 CFM Corporation 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 800-668-5323 • www.cfmcorp.com...
