INSTALLER/CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND USING
APPLIANCE.
IMPORTANT: Read all instructions
and warnings carefully before starting
installation. Failure to follow these in-
structions may result in a possible fire
hazard and will void the warranty.
WARNING: If the information in this
manual is not followed exactly, a fire
or explosion may result causing prop-
erty damage, personal injury or loss of
life.
FOR YOUR SAFETY
Installation and service must be per-
formed by a qualified installer, service
agency, or the gas supplier. Do not
store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of
this or any other appliance.
FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Do not touch electrical switches.
3. Do not try to light any appliance.
4. Extinguish any open flame.
5. Do not use the phone in your build-
ing.
6. Immediately call your gas supplier
from a neighbor's phone.
7. Follow your gas supplier's instruc-
tions.
8. If you cannot reach your gas sup-
plier, call the fire department.
Decorative Gas Appliances
Models: NVBR36, NVBC42
NVBR36, NVBC42
Homeowner's Installation and
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
NVBR36
NVBC42
Operating Manual
950
NVB cover 2/1/01
C E RT I F I E D
7412950 8/06 Rev. 15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVBC42 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Majestic fireplaces NVBC42

Summary of Contents for Majestic fireplaces NVBC42

  • Page 1 7. Follow your gas supplier's instruc- tions. 8. If you cannot reach your gas sup- plier, call the fire department. Decorative Gas Appliances Models: NVBR36, NVBC42 NVBR36, NVBC42 Homeowner's Installation and Operating Manual INSTALLER: Leave this manual with the appliance.

  • Page 2: Table Of Contents

    NVB Series B-Vent Gas Fireplace Thank you and Congratulations on your purchase of a CFM Corporation fireplace. PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING THE APPLIANCE IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty.

  • Page 3: General Information

    This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CSA-B149.1 Installation codes for Gas Burning Appliances and Equipment. FOR U.S.A Installations follow local codes and/or the cur- rent National Fuel Gas Code. ANSI Z223.1/NFPA 54. In the Commonwealth of Massachusetts, all gas fittings and installation of this heater shall only be done by a licensed gas fitter or licensed plumber.
  • Page 4 NVB Series B-Vent Gas Fireplace 45���" (1162mm) ���" (13mm) �����" (822mm) ���" 36" (914mm) Outside Electrical Access �����" (337mm) Fig. 1 NVBR36 Series specification and framing dimensions. NVBC36 Series Gas Appliance — Circulating Model 45���" (1162mm) ���" (13mm) �����" (822mm) ���"...
  • Page 5 NVBC42 Series Gas Appliance — Circulating Model 49" (1245mm) ���" (13mm) 35���" (895mm) ���" 36" (914mm) Outside Electrical Access �����" (337mm Fig. 4 NVBC42 Series specification and framing dimensions. 7412950 NVBR42 Series Gas Appliance ��" (711mm) Rough Opening Depth ����" (213mm) �����" (521mm) 20"...

  • Page 6: Clearance To Combustibles

    NVB Series B-Vent Gas Fireplace Clearance to Combustibles Appliances Top ...0” (0 mm) Bottom ...0” (0 mm) Side ...0” (0 mm) Back ...0” (0 mm) Perpendicular Sidewall ...0” (0 mm) Top of unit to ceiling ...36” (914 mm) Front of unit to combustibles ...36” (914 mm) Venting B-Vent ...1”...

  • Page 7: Framing & Finishing

    Minimum Inlet Pressure FP549 Maximum Inlet Pressure Manifold Pressure NVBR36 / NVBC36 / NVBC42 / NVBR42 ANSI Z21.50b-2002 / CSA 2.22b-2002 Vented Gas Fireplace Input ratings are shown in BTU per hour and are certified without deration for elevations up to 4,500 feet (1,370m) above sea level.

  • Page 8: Parts Identification And Chase Installation

    NVB Series B-Vent Gas Fireplace Parts Identification and Chase Installation (Insulation methods shown are optional for cold climate, not a requirement for unit operation.) Batt Insulation (cut out around firestop) Firestop Ceiling Level Nailing Flange Electrical Access Outside Air Cover Plate Fig.

  • Page 9: Remote Wall Switch

    U.S.: Consult the current National Fuel Gas Code, ANSI Z223.1/NFPA 54. Canada: CSA - B149.1 installation code. Test for leaks. Use a 50/50 solution of liquid soap and water to test for leaks at gas fittings and joints. Apply water/soap solution with brush only - do not over apply. NEVER test with an open flame.

  • Page 10: Eb-1 Electrical Box

    NVB Series B-Vent Gas Fireplace EB-1 Electrical Box The fireplace, when installed, must be elec- trically connected and grounded in accor- dance with local codes or, in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code. For USA installations, follow local codes and the National Electrical Code, ANSI/ NFPA No.

  • Page 11: Venting Runs

    Venting Runs Horizontal Run (in feet) �������������������������������� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� = Acceptable venting configuration = Unacceptable venting configuration A: Vertical installations up to 40 feet (12m) in height. Up to a 6 ft. horizontal vent run can be installed within the vent system using a maximum of two 90-degree elbows or four 45-degree elbows.

  • Page 12: Operating Instructions

    NVB Series B-Vent Gas Fireplace Glass Information Only glass approved for use in Majestic Fireplaces products may be used for re- placement. • Glass doors are optional. The appliance may be operated safely without glass doors. • The use of any non-approved replacement glass will void all product warranties.

  • Page 13: First Firing

    Left Cross Left Rear Ember Left Log Lava Rock LG148 Fig. 16 NVB42 log placement. Under no circumstances should lava rock be placed on any part of the burner assem- bly. First Firing Upon completing the gas line connection, a small LG148 amount of air will be trapped in the line.
  • Page 14 NVB Series B-Vent Gas Fireplace Fig. 19 NVB36 flame appearance. Fig. 20 NVB42 flame appearance. Red Glow LG151 NVB36 log flames 2/2/01 djt LG150 NVB42 log flames 2/1/01 djt Embers LG151 LG150 7412950...

  • Page 15: Lighting & Operating Instructions

    Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- ally.
  • Page 16 NVB Series B-Vent Gas Fireplace Lighting and Operating Instructions For Fireplaces equipped with SIT822 Gas Valve (EN or EP) Warning: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury and loss of life. FOR YOUR SAFETY READ THE FOLLOWING WARNINGS A.

  • Page 17: Troubleshooting

    Nova SIT 820 Standing Pilot START Gas Supply On Pilot Lights with Piezo Ignitor Pilot Stays Lit Pilot Lights Main Burner System OK 7412950 Troubleshooting CHECK • Supply Line Hooked up • Shutoff Valve Open • Lockout has engaged. Wait 60 seconds and try again.
  • Page 18 NVB Series B-Vent Gas Fireplace NOVA SIT 822 with Honeywell S8600 B Electronic Ignition START • Turn gas supply off • Turn ON/OFF Switch to call for heat. Power to module (24V nominal) Spark across Ignitor Sensor gap • Turn gas on Pilot burner lights? Spark stops when pilot is lit?

  • Page 19: Cleaning The Standing Pilot Control System

    Burner and Burner Compartment It is important to keep the burner and the burner compartment clean. At least once per year the logs and lava rock/ember material should be removed and the burner compartment vacuumed and wiped out. Remove and replace the logs as per the instructions in this manual.

  • Page 20: Replacement Parts

    NVB Series B-Vent Gas Fireplace 1. NVB36 Logs 19a/b 21a/b � � 23a/b CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. NVB Series Ref. Description Logs - Complete Set Log - Left Rear Log - Right Rear...
  • Page 21 (continued) Ref. Description Door Track - Brass Side Brick - Left Back Brick Side Brick - Right Ceramic Panel - Left Ceramic Panel - Right Glass Grate O.S.A. Assy. 19a. Valve Nova - Natural 19b. Valve Nova - LP Piezo Ignitor 21a.

  • Page 22: Optional Accessories

    36GDKBK 36GDKDP 36GDKS Optional Accessories Appliance Models NVBR42/NVBC42 The Model AK-MST Outside Air Kit is designed to bring additional combustion air directly from the outside to the fireplace. Refer to installation instructions provided with the Outside Air Kit. Installing the TVD6/7 Thermal Vent Damper reduces cold air infiltration when fireplace is not in use by open-...

  • Page 23: Installation & Operating Instructions

    PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic or Northern Flame brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY CFM Corporation (hereinafter referred to collectively as the Company) warrants that your new Vermont Castings or Majestic Gas Fireplace/ Stove is free from manufacturing and material defects for a period of one year from the date of purchase, subject to the following conditions...
  • Page 24 CFM Corporation 2695 Meadowvale Blvd. • Mississauga, Ontario, Canada L5N 8A3 800-668-5323 • www.cfmcorp.com...
