INSTALLER/CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND
USING APPLIANCE.
IMPORTANT: Read all instruc-
tions and warnings carefully
before starting installation.
Failure to follow these instruc-
tions may result in a possible
fire hazard and will void the
warranty.
WARNING: If the information in
this manual is not followed
exactly, a fire or explosion may
result causing property dam-
age, personal injury or loss of
life.
FOR YOUR SAFETY
Installation and service must
be performed by a qualified
installer, service agency, or the
gas supplier. Do not store or
use gasoline or other flam-
mable vapors and liquids in the
vicinity of this or any other
appliance.
FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Do not touch electrical
switches.
3. Do not try to light any appli-
ance.
4. Extinguish any open flame.
5. Do not use the phone in
your building.
6. Immediately call your gas
supplier from a neighbor's
phone.
7. Follow your gas supplier's
instructions.
8. If you cannot reach your gas
supplier, call the fire depart-
ment.
INSTALLER: DO NOT DISCARD THIS MANUAL - Leave in fireplace for homeowner.
Decorative Gas Appliances
Models: NVBR36, NVBC36
NVBR42, NVBC42
NVBC42
Homeowner's Installation and
Operating Manual
Vermont Castings, Majestic Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
www.majesticproducts.com • www.vermontcastings.com
NVBR36
950
C E RT I F I E D
7412950 9/03 Rev. 12
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Majestic fireplaces NVBC42
Summary of Contents for Majestic fireplaces NVBC42
- Page 1 INSTALLER: DO NOT DISCARD THIS MANUAL - Leave in fireplace for homeowner. Decorative Gas Appliances Models: NVBR36, NVBC36 NVBR42, NVBC42 NVBC42 Homeowner's Installation and Operating Manual Vermont Castings, Majestic Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com •...
-
Page 2: Table Of Contents
Majestic Fireplaces NVB Series B-Vent ® Thank you and Congratulations on your purchase of a PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING THE APPLIANCE IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty. -
Page 3: Installation & Operating Instructions
This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CSA-B149.1 Installation codes for Gas Burning Appliances and Equipment. FOR U.S.A Installations follow local codes and/or the current National Fuel Gas Code. ANSI Z223.1. FOR SAFE INSTALLATION AND OPERATION PLEASE NOTE THE FOLLOWING: 1. -
Page 4: Fireplace Dimensions
Majestic Fireplaces NVB Series B-Vent ® 45 " (1162mm) " (13mm) " (822mm) " 36" (914mm) Outside Electrical Access (337mm) Fig. 1 NVBR36 Series specification and framing dimensions. NVBC36 Series Gas Appliance — Circulating Model 45 " (1162mm) " (13mm) "... - Page 5 NVBC42 Series Gas Appliance — Circulating Model 49" (1245mm) " (13mm) " 36" (914mm) Outside Electrical Access Fig. 4 NVBC42 Series specification and framing dimensions. RecessedNailing 7412950 Rough Rough Opening Width 47" Majestic Fireplaces NVBR42 Series Gas Appliance Rough Opening Depth "...
-
Page 6: Clearance To Combustibles
Majestic Fireplaces NVB Series B-Vent ® Clearance to Combustibles Appliances Top ... 0” (0mm) Bottom ... 0” (0mm) Side ... 0” (0mm) Back ... 0” (0mm) Perpendicular Sidewall ... 0” (0mm) Top of unit to ceiling ... 36” (914mm) Front of unit to combustibles ... 36” (914mm) Venting B-Vent ... -
Page 7: Framing & Finishing
NVBR42EP Propane Electronic Ignition 30,000 22,000 NVBC42EP Propane Electronic Ignition 30,000 22,000 Gas Inlet & Manifold Pressures Minimum Inlet Pressure Maximum Inlet Pressure Manifold Pressure NVBR36 / NVBC36 / NVBC42 / NVBR42 Nail Top Standoffs ANSI Z21.50a-1999/CSA 2.22A-M-99 Nail Side- Nailing... -
Page 8: Parts Identification And Chase Installation
Majestic Fireplaces NVB Series B-Vent ® Parts Identification and Chase Installation (Insulation methods shown are optional for cold climate, not a requirement for unit operation.) Batt Insulation (cut out around firestop) Firestop Ceiling Level Nailing Flange Electrical Access Outside Air Cover Plate Fig. -
Page 9: Remote Wall Switch
U.S.: Consult the current National Fuel Gas Code, ANSI Z223.1 Canada: CSA - B149.1 installation code. Test for leaks. Use a 50/50 solution of liquid soap and water to test for leaks at gas fittings and joints. Apply water/soap solution with brush only - do not over apply. -
Page 10: Eb-1 Electrical Box
Majestic Fireplaces NVB Series B-Vent ® EB-1 Electrical Box The fireplace, when installed, must be electrically connected and grounded in accordance with local codes or, in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code. For USA installations, follow local codes and the National Electrical Code, ANSI/ NFPA No. -
Page 11: Venting Runs
Venting Runs Horizontal Run (in feet) 1 2 3 4 5 6 7 = Acceptable venting configuration = Unacceptable venting configuration A: Vertical installations up to 40 feet (12m) in height. Up to a 6 ft. horizontal vent run can be installed within the vent system using a maximum of two 90-degree elbows or four 45-degree elbows. -
Page 12: Operating Instructions
Majestic Fireplaces NVB Series B-Vent ® Glass Information Only glass approved for use in Majestic Fireplaces products may be used for replacement. • Glass doors are optional. The appliance may be operated safely without glass doors. • The use of any non-approved replacement glass will void all product warranties. -
Page 13: Ember Material Placement
Ember Material Placement Separate the ember material into small pieces, roughly 1/2" in diameter and place on bracket over front burner tube. Do not pack down; leave in loose, fluffy condition for most realistic ember effect. (Fig. 15 & 16) Lava Rock The lava rock provided with this fireplace must be placed on the firebox base on either side of the burner... -
Page 14: Lighting & Operating Instructions
Majestic Fireplaces Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manually. - Page 15 Lighting and Operating Instructions For Fireplaces equipped with SIT822 Gas Valve (EN or EP) Warning: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury and loss of life. FOR YOUR SAFETY READ THE FOLLOWING WARNINGS A.
-
Page 16: Troubleshooting
Majestic Fireplaces NVB Series B-Vent ® Nova SIT 820 Standing Pilot START Gas Supply On Pilot Lights with Piezo Ignitor Pilot Stays Lit Pilot Lights Main Burner System OK Troubleshooting CHECK • Supply Line Hooked up • Shutoff Valve Open •... - Page 17 NOVA SIT 822 with Honeywell S8600 B Electronic Ignition START • Turn gas supply off • Turn ON/OFF Switch to call for heat. Power to module (24V nominal) Spark across Ignitor Sensor gap • Turn gas on Pilot burner lights? Spark stops when pilot is lit? Main Burner lights?
-
Page 18: Maintenance
Majestic Fireplaces NVB Series B-Vent ® Burner and Burner Compartment It is important to keep the burner and the burner compartment clean. At least once per year the logs and lava rock/ember material should be removed and the burner compartment vacuumed and wiped out. Remove and replace the logs as per the instructions in this manual. - Page 19 19a/b 23a/b NVB Series Ref. Description Logs - Complete Set Log - Left Rear Log - Right Rear Log - Right Cross Log - Left Cross Log - Center Cross Log - Left Ember (Long) Log - Right Ember (Short) Lava Rock Package Bag of Embers Burner Housing w/Tile...
-
Page 20: Replacement Parts
Majestic Fireplaces NVB Series B-Vent ® (continued) Ref. Description Door Track - Black Door Track - Brass Side Brick - Left Back Brick Side Brick - Right Ceramic Panel - Left Ceramic Panel - Right Glass Grate O.S.A. Assy. 19a. Valve Nova - Natural 19b. -
Page 21: Optional Accessories
36GDKS 7412950 Majestic Fireplaces Optional Accessories Appliance Models NVBR42/NVBC42 The Model AK-MST Outside Air Kit is designed to bring additional combustion air directly from the outside to the fireplace. Refer to installation instructions provided with the Outside Air Kit. Installing the TVD6/7 Thermal Vent Damper reduces cold air infiltration when fireplace is not in use by opening and closing automatically. - Page 22 Majestic Fireplaces NVB Series B-Vent ® Shrouds Decorative shrouds are available to enhance the appearance of the termination cap. Square Shroud SSKDKU Pagoda Shroud PSKDKU Bishop Shroud BSKDKU TT Shroud TTSKDKU 7412950...
-
Page 23: Warranty
Damage to the unit while in transit is not covered by this warranty but • is subject to claim against the common carrier. Contact the dealer from whom you purchased your fireplace/stove (do not operate the appliance as this might negate the ability to process the claim with the carrier). - Page 24 Vermont Castings, Majestic Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.majesticproducts.com • www.vermontcastings.com...
