10. SYMPTOM: THE SPA JET UNIT CONTINUES
TO RUN AFTER IT HAS BEEN SHUT OFF
a. To turn the spa jets on high, press the ON/OFF
button once. To turn the spa jets on low, press
the ON/OFF button twice. To turn the spa jets
off, press the button three times. The spa jets
will remain off for three hours, at which time
Part List Ñ Model No. IMHS40090
Key No. Qty. Description
1 1 Pressure Switch
2 1 Access Cover
3 1 Dual Temperature Probe
4 1 Inflatable Cover
5 4 #8 x 5/8Ó Screw
6 2 Removable Collar
7 8 #6 x 1 1/4Ó Wood Screw
8 1 Filter Cover
9 1 Spa Shell
10 4 Small Fixed Jet
11 1 Spa Cover
12 2 Heater Gasket
13 1 Temperature Probe Guard
14 1 Heater Assembly
15 2 #4 x 3/8Ó Screw
16 1 Filter
17 2 #10 x 1 1/4Ó Screw
18 2 Suction Cover
19 2 Suction Guard
20 1 Pump Motor
21 1 Heater Terminal Cover
22 1 Heat Controller
23 1 Heater Wire Harness
24 5 #10 Kep Nut
25 1 Electronic Control
26 4 Large Fixed Jet
27 1 Drain Plug
28 1 Drain Plug O-ring
29 1 Quick Mount Bracket
30 6 Buckle
Note: Ò#Ó indicates a non-illustrated part. Specifications are subject to change without notice.
they will begin running the filter cycle. At any
time after the spa jets have been shut off, the
pump will begin cycling the water if the temper-
ature falls below the minimum setting. Note: If
the water temperature is already below the
minimum setting, the pump will not shut off.
Key No. Qty.
31 12
32 4
33 8
34 1
35 4
36 4
37 1
38 1
39 1
40 1
41 1
42 1
43 2
44 1
45 1
46 2
47 1
48 4
49 1
50 1
# 1
# 2
# 1
# 1
# 2
# 1
# 1
# 1
# 1
18
R0299A
Description
#4 x 3/4Ó Screw
5/16Ó Dampening Screw
5/16Ó Nylon Locknut
3/8Ó Star Washer
1/4Ó x 1 1/4Ó Bolt
5/16Ó Lock Washer
Thermostat Knob
3/8Ó Jamnut
On/Off Switch Assembly
Air Control Knob
On/Off Wire Harness
On/Off Switch Bracket
Wire Tie
Temperature Probe Assembly
Overlay
Rubber O-ring
Rubber Grommet
5/16Ó Flat Washer
Wire Harness 3 to 1
Motor Mount Plate
Ground Wire
Ground Wire Bracket
Water Treatment Kit
Water Test Strip
Key
UserÕs Manual
Large Warning Sign
Warning Sign
Foot Pump
