Model No. IMHS80081
Serial No.
Write the serial number in the space
above for reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or find that there
are missing or damaged parts,
we will guarantee complete satis-
faction through direct assistance
from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USERÕS MANUAL
¨

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMHS80081 and is the answer not in the manual?

Questions and answers

Related Manuals for Image IMHS80081

Summary of Contents for Image IMHS80081

  • Page 1 Model No. IMHS80081 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or find that there are missing or damaged parts,...

  • Page 2: Table Of Contents

    Note: A PART LIST and an EXPLODED DRAWING are attached to the center of this manual. Remove the PART LIST and EXPLODED DRAWING before beginning assembly. IMAGE ¨ ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the following important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the hydrotherapy spa are adequately informed of all precautions.

  • Page 4: Save These Instructions

    motor of this unit to connect a minimum No. 8 AWG (804 mm ) solid copper conductor between this unit and any metal equipment, electrical enclosure made of metal, metal water pipes, or conduit within five feet (1.52m) of the unit. 22.

  • Page 5: Warning Label Identification

    WARNING LABEL IDENTIFICATION The warning labels shown below have been placed on the spa cover, printed inside the inflatable spa liner, and placed on the side of the spa jet unit of the hydrotherapy spa. Locate the labels and familiarize yourself with this information.

  • Page 6: Before You Begin

    (excluding holidays). To help us assist you, please note the product model number and serial number before calling. The model number is IMHS80081. The serial number can be found on a decal attached to spa jet unit (see the front cover of this manual).

  • Page 7: Choosing A Location For The Hydrotherapy Spa

    CHOOSING A LOCATION FOR THE HYDROTHERAPY SPA There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you use the hydrotherapy spa inside or outside. We have listed several factors you may wish to consider as you decide where you want to use the hydrotherapy spa.

  • Page 8: Assembly

    ASSEMBLY Before beginning assembly, carefully read the following information and instructions: ¥ Place all parts in a cleared area and remove the packing materials; do not dispose of the packing materials until assembly is completed. ¥ Assembly requires two people. 1.
  • Page 9 4. Remove the power cord from the Spa Jet Unit (13). With the help of a second person, place the Spa Jet Unit (13) over the Side Panel (1) and the section of the Inflatable Spa Liner (9) which does not have the cushion.

  • Page 10: Using The Hydrotherapy Spa

    7. Place the Spa Cover (11) over the Side Panels (1, 2) and the Spa Jet Unit (13). Be sure that the Spa Cover is properly centered and that the straps on the Spa Cover line up with the straps extend- ing from the slots in the Side Panels (1, 2).
  • Page 11 STARTING THE HYDROTHERAPY SPA Once you have tested the GFCI, you should verify the water flow from the pumping unit. Set the air control on the console to the lowest setting (see USING THE CONSOLE on the next page). The pumping unit will heat the water as it pumps.
  • Page 12 DIAGRAM OF THE CONSOLE USING THE CONSOLE Refer to the console diagram above. The function of each console control is explained below: Primer: This opening allows you to prime the spa jet unit before operation (see PRIMING THE SPA JET UNIT on page 10).

  • Page 13: Maintenance

    ment by removing the filter cover and the two filter cover screws and then pulling the filter from the spa jet unit. The spa jet unit features an automatic filter cycle and freeze protection. If the spa jet unit has not been oper- ated for three hours, the pump will begin circulating the water for twenty minutes to filter any impurities.

  • Page 14: Trouble-Shooting

    lines when handling the chemicals: 1. Always read and follow the directions on the label, unless directed otherwise. 2. Never mix different chemicals. 3. Keep all chemicals out of the reach of chil- dren and pets. 4. Do not exceed the recommended amountsÑfollow the directions on the label closely.
  • Page 15 b. The pump may have a bad bearing. Contact our customer service department. 6. SYMPTOM: THE WATER DOES NOT HEAT a. The heater is attached to the pump in the spa jet unit. If the pump is operating, the water should heat.

  • Page 16: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information when calling: 1. The MODEL NUMBER of the product (IMHS80081). 2. The NAME of the product (IMAGE ¨...
  • Page 17 PART LISTÑModel No. IMHS80081 Key No. Qty. Description Side Panel Rubber Grommet Dual Temperature Probe Support Ball #8 x 5/8Ó Screw Removable Collar 1/4Ó x 1 1/2Ó Bolt Fabric Spa Surround Inflatable Spa Liner Fixed Jet Spa Cover Lower Heater Gasket...
