USER'S MANUAL
Visit our website at
www.workoutwarehouse.com
new products, prizes,
fitness tips, and much more!
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Renew 455 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Image Renew 455

Summary of Contents for Image Renew 455

  • Page 1 ® Model No. IMHS45592 Serial No. USER’S MANUAL The serial number is found on a plastic sign inside the spa behind the access panel. Write the serial number in the space above for reference. Access Panel QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction.

  • Page 2: Table Of Contents

    Table of Contents Posting the Warning Sign ..............2 Important Safety Instructions .

  • Page 3: Important Safety Instructions

    Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure 10.
  • Page 4 21. DANGER—If you will be using the hydrother- 29. WARNING—To reduce the risk of injury: The apy spa outside, do not bury the power cord. water temperature should never exceed Keep the power cord away from lawn mow- 104°F. Temperatures between 100°F and 104°F ers, hedge trimmers, and other similar equip- are considered to be safe for healthy adults.
  • Page 5 36. If you feel pain or dizziness at any time while 41. WARNING DECAL PLACEMENT: Locate the using the hydrotherapy spa, discontinue use decals shown below and familiarize yourself and contact a physician. with the information on the decals. 37. WARNING—To reduce the risk of injury: It is especially important for persons over the age of 35 or persons with pre-existing health problems, such as obesity, heart disease,...

  • Page 6: Before You Begin

    RENEW 455 hydrotherapy spa. The innovative using the RENEW 455. If you have additional ques- RENEW 455 allows you to enjoy all the benefits of tions, please call our Customer Service Department hydrotherapy in the comfort and privacy of your home.

  • Page 7: Choosing A Location For The Hydrotherapy Spa

    Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa.

  • Page 8: Assembly

    Assembly Before beginning assembly, carefully read the ASSEMBLY REQUIRES THE FOLLOWING following information and instructions: TOOLS (not included): • Place all parts in a cleared area and remove the • One (1) phillips screwdriver packing materials from the spa shell. Do not dis- pose of the packing materials until assembly is •...
  • Page 9 3. Refer to the inset drawing. Set a Filter Gasket (33) on top of the Filter (16). Next, press the Filter Cover (8) into the spa until it is fully seated. Then, tighten the Locking Ring (19) onto the spa. Remove the two warning decals (not shown) from the spa shell.

  • Page 10: Using The Hydrotherapy Spa

    Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat five adults. TESTING AND TREATING THE WATER The spa holds 225 gallons of water and offers a heat- ing system (70°F to 104°F), a filtration system, ten The hydrotherapy spa comes with a starter chemical adjustable hydrotherapy jets, and a powerful whirlpool pack for maintaining the water in the spa.

  • Page 11: Spa Shell Diagram

    Spa Shell Diagram Refer to the diagram above. The function of each H. The filter can be removed for cleaning or replace- component is explained below. ment (see CHECKING AND CLEANING THE FIL- TER on page 13). A. The ten hydrotherapy jets provide a relaxing mas- sage action.

  • Page 12: Using The Controls

    Using the Controls Air Control Light Temperature Diverter Button Button Buttons Refer to the diagram above. The function of each Light Button: Turns the underwater light on and off. control is explained below: Temperature Buttons: Control the temperature setting Air Control: Determines the amount of air flowing of the water.

  • Page 13: Maintenance

    Maintenance The hydrotherapy spa is designed to provide years of enjoyment. Please follow the guidelines below to The spa cover should be cleaned monthly. To clean properly maintain your spa. the spa cover, use water and a non-abrasive cleaner on the entire cover. Rinse the cover with a garden MAINTENANCE SCHEDULE hose to remove any cleaner residue.
  • Page 14 WATER CHEMISTRY ATTACHING AND REMOVING THE ACCESS PANEL The hydrotherapy spa comes with a starter chemical To locate the access panel, refer to the drawing on pack for maintaining the water in the spa. (See TEST- page 6. Note: The slats on the Assess Panel are ING AND TREATING THE WATER on page 10.) narrower than the slats on the rest of the spa.
  • Page 15 To drain the hydrotherapy spa, follow the steps below: WINTER USE AND CARE 1. Using the console, adjust the temperature to the The hydrotherapy spa is designed for year-round use. lowest setting. If you decide to store the spa for the winter, store it in 2.

  • Page 16: Trouble-Shooting

    Trouble-shooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time. 1.
  • Page 17 10. SYMPTOM: THE SPA JET UNIT CONTINUES 12. SYMPTOM: THE CONSOLE DISPLAYS THE TO RUN AFTER IT HAS BEEN SHUT OFF WORDS “COOL” OR “ICE” a. To turn the spa jets on low, press the jet button a. This is a normal function of the spa; no action once.

  • Page 18: Part List

    Part List—Model No. IMHS45592 R1200A Key No. Qty. Description Key No. Qty. Description Compression Fitting Assembly Diverter Knob Access Panel Push/Pull Movable Jet Whirlpool Jet Drain Plug Inflatable Cover Drain Plug O-ring #8 x 5/8” Screw Air Vent Removable Collar Buckle #10 x 1 3/4”...

  • Page 19: Exploded Drawing

    Exploded Drawing—Model No. IMHS45592 R1200A...

  • Page 20: Ordering Replacement Parts

    2. The NAME of the product (IMAGE ® RENEW 455) 3. The SERIAL NUMBER of the product (see the front cover of this manual) 4. The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and EXPLODED DRAWING on pages 18 and 19).
