Model No. IMSB63121
IMSG63121
Serial No.
The serial number is on a plastic sign
inside the spa behind the access
panel. Record the serial number in
the space above.
Access Panel
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-877-897-7493
Mon.–Fri., 8 a.m.–5 p.m. CST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.workoutwarehouse.com
new products, prizes,
fitness tips, and much more!
®
Advertisement
Table of Contents
Related Manuals for Image IMSB63121
Summary of Contents for Image IMSB63121
- Page 1 ® Model No. IMSB63121 IMSG63121 USER’S MANUAL Serial No. The serial number is on a plastic sign inside the spa behind the access panel. Record the serial number in the space above. Access Panel QUESTIONS? If you have questions, or if there...
-
Page 2: Table Of Contents
Whenever the spa is moved, the sign must also be moved and reposted near the spa. If the sign becomes lost or illegible, call our toll-free Customer Hot Line at 1-877-897-7493 to obtain a replacement sign. Post the sign as described above. IMAGE is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure 10. - Page 4 20. DANGER—Risk of electric shock. Keep all physician before using the hydrotherapy spa. electrical appliances such as radios, tele- Pregnant women should not use the spa if phones, televisions, and lights at least five the water temperature is above 100°F; the feet away from the water.
- Page 5 35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.
-
Page 6: Before You Begin
The model busy life. The warm environment stimulates blood flow, number is IMSB63121 or IMSG63121. The serial num- which is essential in the healing process, and the ber can be found on a decal attached to the access powerful massage action eases tension and stress panel inside the spa (see the front cover of this manual). -
Page 7: Choosing A Location For The Hydrotherapy Spa
Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa. -
Page 8: Assembly
Assembly Before beginning assembly, carefully read the ASSEMBLY REQUIRES THE FOLLOWING following information and instructions: TOOLS (not included): • Place all parts in a cleared area and remove the • One (1) phillips screwdriver packing materials from the spa shell. Do not dis- pose of the packing materials until assembly is •... - Page 9 3. Refer to the drawing on page 6 and locate the long access opening. Next, locate the two indicated gate Gate Electronics Pack valves inside the opening. Make sure that the gate Valve valves are open and that the locking clips are snapped onto the stems of the gate valves (refer to the inset drawing in step 2 on page 8).
-
Page 10: Using The Hydrotherapy Spa
Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat five adults. Once you have tested the GFCI, you should verify the The spa holds 295 gallons of water and offers a heat- water flow from the pumping unit. Set the air control ing system (80°F to 104°F), a filtration system, and on the console to the lowest setting (see USING THE adjustable hydrotherapy jets. -
Page 11: Spa Shell Diagram
Spa Shell Diagram A. The seven adjustable, directional jets can be piv- system. Never operate the spa without the suc- oted to direct their water flow. tion covers in place. B. The adjustable, pulsing jet produces a soothing, L. The air controls determine the amount of air flowing pulsating massage action. -
Page 12: Using The Controls
Using the Controls Air Controls 1, 2, and 3 Display Display Invert Button Pump Pump Light Temperature Button 1 Button 2 Button Buttons Display Invert Button: Turns the display 180°, allow- flowing through the jets will increase; if the control is ing it to be read from inside or outside of the spa. -
Page 13: Maintenance
Maintenance The hydrotherapy spa is designed to provide years of MAINTAINING THE SPA COVER enjoyment. Please follow the guidelines below to properly maintain your spa. The spa cover should be cleaned monthly. To clean the spa cover, use water and a non-abrasive cleaner MAINTENANCE SCHEDULE on the entire cover. - Page 14 WATER CHEMISTRY ATTACHING AND REMOVING ACCESS PANELS CAUTION: The chemicals used to maintain the pH To locate the access panels, refer to the drawing on balance of the water and to sanitize the water can page 6. Turn off the spa power. To remove an access be dangerous.
- Page 15 To drain the hydrotherapy spa, follow the steps below: WINTER USE AND CARE 1. Using the console, adjust the temperature to the The hydrotherapy spa is designed for year-round use. lowest setting. If you decide to store the spa for the winter, store it in 2.
-
Page 16: Troubleshooting
Troubleshooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 8 a.m. until 5 p.m. Central Time. 1. - Page 17 b. A clamp or seal inside the pump compartment 12. SYMPTOM: THE CONSOLE DISPLAYS THE may be loose. Check inside the pump compart- WORDS “COOL” OR “ICE” ment for excess water and watch the pump unit while it is operating to see if water drips from a.
-
Page 18: Part List
Part List —Model No. IMSB63121/IMSG63121 R0902A Key No. Qty. Description Key No. Qty. Description Thermometer Fitting Large Rotary Jet Access Panel Face Ring Volcano Jet Small Nozzle Two-speed Motor/Pump* Jet Ring Short Panel Nozzle Bushing Rotator Nozzle Retainer Ring #10 x 2” Sheet Metal Screw... -
Page 19: Exploded Drawing
Exploded Drawing —Model No. IMSB63121/IMSG63121 R0902A... -
Page 20: Ordering Replacement Parts
Friday, 8 a.m. until 5 p.m. Central Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: • The MODEL NUMBER of the product (IMSB63121 or IMSG63121) • The NAME of the product (IMAGE ®...
