Model No. IMHS61500
Serial No.
The serial number is found on a plastic
sign inside the spa behind the access
panel. Write the serial number in the
space above for reference.
Access Panel
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL DIRECT
TO OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our customer hot line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-877-897-7493
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.workoutwarehouse.com
new products, prizes,
fitness tips, and much more!
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RENEW 615 and is the answer not in the manual?

Questions and answers

Related Manuals for Image RENEW 615

Summary of Contents for Image RENEW 615

  • Page 1 ® Model No. IMHS61500 Serial No. USER’S MANUAL The serial number is found on a plastic sign inside the spa behind the access panel. Write the serial number in the space above for reference. Access Panel QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction.

  • Page 2: Table Of Contents

    Whenever the spa is moved, the sign must also be moved and reposted near the spa. If the sign becomes lost or illegible, call our toll-free Customer Hot Line at 1-877-897-7493 to obtain a replacement sign. Post the sign as described above. IMAGE ® is a registered trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Safety Instructions

    Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure 10.
  • Page 4 20. DANGER—Risk of electric shock. Keep all physician before using the hydrotherapy spa. electrical appliances such as radios, tele- Pregnant women should not use the spa if phones, televisions, and lights at least five the water temperature is above 100°F; the feet away from the water.
  • Page 5 35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.

  • Page 6: Before You Begin

    RENEW 615 hydrotherapy spa. The innovative using the RENEW 615. If you have additional ques- RENEW 615 allows you to enjoy all the benefits of tions, please call our Customer Service Department hydrotherapy in the comfort and privacy of your home.

  • Page 7: Choosing A Location For The Hydrotherapy Spa

    Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa.

  • Page 8: Assembly

    Assembly Before beginning assembly, carefully read the ASSEMBLY REQUIRES THE FOLLOWING following information and instructions: TOOLS (not included): • Place all parts in a cleared area and remove the • One (1) phillips screwdriver packing materials from the spa shell. Do not dis- pose of the packing materials until assembly is •...
  • Page 9 Screws (7). 4. The RENEW 615 operates on a 240 volt power source and must be wired directly to a 240 volt ground fault circuit interrupter (GFCI) installed in your home. This procedure must be performed by a qualified electri- cian.

  • Page 10: Using The Hydrotherapy Spa

    Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat five adults. If the level is too high, add half of one of the “QUICK The spa holds 295 gallons of water and offers a heat- pHix It DOWN” packets to the water. Let the water cir- ing system (80°F to 104°F), a filtration system, and culate through the spa for five minutes.

  • Page 11: Spa Shell Diagram

    Spa Shell Diagram Refer to the diagram above. The function of each H. The seven-port jet returns heated water into the component is explained below. spa and provides a soothing foot massage. A. The five adjustable push/pull jets allow you to I.

  • Page 12: Using The Controls

    Using the Controls Air Control Light Temperature Button Button Buttons Refer to the diagram above. The function of each as required to maintain the set tempature. Note: To control is explained below: keep the filter and heat cycles from running, the power to the spa must be turned off.

  • Page 13: Maintenance

    Maintenance The hydrotherapy spa is designed to provide years of MAINTAINING THE SPA COVER enjoyment. Please follow the guidelines below to properly maintain your spa. The spa cover should be cleaned monthly. To clean the spa cover, use water and a non-abrasive cleaner MAINTENANCE SCHEDULE on the entire cover.
  • Page 14 WATER CHEMISTRY ATTACHING AND REMOVING THE ACCESS PANEL The hydrotherapy spa comes with a starter chemical To locate the access panels, refer to the drawing on pack for maintaining the water in the spa. (See TEST- page 6. Turn off the spa power. To remove an access ING AND TREATING THE WATER on page 10.) panel, first remove the four indicated screws.
  • Page 15 To drain the hydrotherapy spa, follow the steps below: WINTER USE AND CARE 1. Using the console, adjust the temperature to the The hydrotherapy spa is designed for year-round use. lowest setting. If you decide to store the spa for the winter, store it in 2.

  • Page 16: Trouble-Shooting

    Trouble-shooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time. 1.
  • Page 17 10. SYMPTOM: THE SPA JET UNIT CONTINUES a. This is a normal function of the spa; no action TO RUN AFTER IT HAS BEEN SHUT OFF is necessary. The word “COOL” will appear in the display if the temperature of the water is a.

  • Page 18: Part List

    Part List—Model No. IMHS61500 R0600A Key No. Qty. Description Key No. Qty. Description Thermometer Fitting Drain Plug Long Access Panel Drain Plug O-ring Adjustable Jet Small Quick Release Bracket Heater Pump/Motor Buckle Short Access Panel #4 x 3/4” Screw Heater Pump/Motor O-ring Whirly Jet 1/4”...

  • Page 19: Exploded Drawing

    Exploded Drawing—Model No. IMHS61500 R0600A...

  • Page 20: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information when calling: 1. The MODEL NUMBER of the product (IMHS61500) 2. The NAME of the product (IMAGE ® RENEW 615) 3.
