Profile Panel RGB™
Unpacking:
Thank you for purchasing the Profile Panel RGB™ by
American DJ
. Every Profile Panel RGB™ has been thoroughly tested
®
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your fix-
ture for any damage and be sure all accessories necessary to operate
the unit has arrived intact. In the case damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Do not return this unit to your dealer without first
contacting customer support.
Introduction:
The Profile Panel RGB™ is part of American DJ's con-
tinuing pursuit for creating high quality affordable intelligent fixtures.
The Profile Panel RGB™ is a DMX intelligent LED stage panel/wash.
This wash can be used in a stand alone mode or connected in a Master/
Slave configuration. The unit can also be controlled via DMX controller.
This wash has four operating modes: Sound Active mode, Program
mode, RGB mode, and DMX control mode.
Customer Support:
American DJ
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
4:30 p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2941
E-mail:
support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ
.
®
PLEASE recycle the shipping carton when ever possible.
American DJ
- www.americandj.com - Profile Panel RGB™ User Manual Page 2
©
®
