Profile Panel RGB™
Operating Modes:
You can use the Profile Panel RGB™ in either a stand alone mode or
a master/slave configuration, there are 5 modes to choose from:
• Program Mode - Choose a static color, color show, color fade
show, or color cycle. The speed of the show is adjustable. You can
also have the unit strobe in this mode.
• Sound-Active mode - The unit will react to sound, chasing through
the built in programs.
• RGB mode - Choose one of the three colors to remain static or
adjust the intensity of each color to make your desired color.
• Macro Mode - Choose 1 of 32 color macros.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as
as the Elation Show Designer™.
®
Master-Slave Operation:
This function will allows you to link units together to run in a Master-
Slave mode. In Master-Slave operation one unit will act as the con-
trolling unit and the others will react to the controlling units built-in
programs. Any unit can act as a Master or as a Slave however, only
one unit can be programmed to act as the "Master."
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the
unit. Use standard XLR microphone cables to link your units to-
gether. Remember that the Male XLR connector is the input and
the Female XLR connector is the output. The first unit in the chain
(master) will use the female XLR connector only. The last unit in
the chain will use the male XLR connector only.
2. Using the Master unit, choose your desired mode or program and
connect the "Slave" unit or units.
3. Set the "Slave" unit(s) to the DMX address mode. They will now
follow the "Master" unit.
Program Mode & Sound Active Mode:
In Program Mode you can pick your desired factory installed pro-
gram; static color, color show, color fade, or color cycle. You can
apply a strobe effect to static colors, and control the speed of the
color shows, color fade, and color cycle.
American DJ - www.americandj.com - Profile Panel RGB™ User Manual Page 7
© ®
Operating Instructions Profile Panel RGB™
• A-01 - A-07 are static colors.
• A-08 - A-22 are color shows.
• A-23 is a color fade show.
• A-24 is a color cycle.
1. Plug the fixture in and press the MODE button until A-XX is dis-
played. You are now in AUTO mode.
2. Press the UP or DOWN buttons to find your desired effect.
3. If you have selected a static color, press the MODE button.
F-XX should be displayed. Use the UP or DOWN buttons to adjust
and select your desired Flash rate.
4. When you have chosen a color show (A-08 - A-23), press the
MODE button to adjust the speed of the show. When you press
the MODE button, the display will show "P-XX". Press the UP or
DOWN button to adjust and set the speed. When the display
shows "P-So" your desired program is running in sound active
mode.
NOTE: If you have a static color selected (A-01 - A-07), the
Program speed (P-XX) menu will not display.
Macro Mode:
In this mode you can select 1 of 32 macros
1. Plug the fixture in and press the MODE button until either C-XX is
displayed.
2. Press the UP or DOWN buttons to find your desired macro.
RGB Mode:
In this mode you can select either red, green, blue, or adjust the col-
ors to make a deisred color, which will remain static. Adjust the inten-
sity of each color to make your desired color.
1. Plug the fixture in and press the MODE button until either "R", "G",
or "B" is displayed.
2. Press the UP or DOWN buttons to adjust the intensity of the dis-
played color. When you have adjusted your desired color press
MODE to scroll to the next color.
DMX Mode:
There are seven DMX Modes to choose from: 2 Channels, 3 Channels,
4 Channels, 6 Channels, 7 Channels, 24 Channels, or 27 Channels.
Operating through a DMX controller give the user the freedom to cre-
American DJ - www.americandj.com - Profile Panel RGB™ User Manual Page 8
© ®
