Profile Panel RGB™
Channel Value
1
1 - 255
2
1 - 255
3
1 - 255
4
1 - 255
5
1 - 255
6
1 - 255
7
1 - 255
8
1 - 255
9
1 - 255
10
1 - 255
11
1 - 255
12
1 - 255
13
1 - 255
14
1 - 255
15
1 - 255
16
1 - 255
17
1 - 255
American DJ - www.americandj.com - Profile Panel RGB™ User Manual Page 15
© ®
27 Channel Mode
Function
RED 1
0% - 100%
GREEN 1
0% - 100%
BLUE 1
0% - 100%
RED 2
0% - 100%
GREEN 2
0% - 100%
BLUE 2
0% - 100%
RED 3
0% - 100%
GREEN 3
0% - 100%
BLUE 3
0% - 100%
RED 4
0% - 100%
GREEN 4
0% - 100%
BLUE 4
0% - 100%
RED 5
0% - 100%
GREEN 5
0% - 100%
BLUE 5
0% - 100%
RED 6
0% - 100%
GREEN 6
0% - 100%
Profile Panel RGB™
Channel Value
18
1 - 255
19
1 - 255
20
1 - 255
21
1 - 255
22
1 - 255
23
1 - 255
24
1 - 255
25
0 - 15
16 - 255
26
0 - 79
80 - 89
90 - 99
100 - 109
110 - 119
120 - 129
130 - 139
140 - 149
150 - 159
160 - 169
170 - 179
180 - 189
190 - 199
200 - 209
210 - 219
220 - 229
American DJ - www.americandj.com - Profile Panel RGB™ User Manual Page 16
© ®
27 Channel Mode
Function
BLUE 6
0% - 100%
RED 7
0% - 100%
GREEN 7
0% - 100%
BLUE 7
0% - 100%
RED 8
0% - 100%
GREEN 8
0% - 100%
BLUE 8
0% - 100%
STROBE
OFF
SLOW - FAST
PROGRAMS
OFF
PROGRAM 1
PROGRAM 2
PROGRAM 3
PROGRAM 4
PROGRAM 5
PROGRAM 6
PROGRAM 7
PROGRAM 8
PROGRAM 9
PROGRAM 10
PROGRAM 11
PROGRAM 12
PROGRAM 13
PROGRAM 14
PROGRAM 15
