SLX User Manual

Designer indoor tv aerial

Advertisement

USER GUIDE
27772RG
Philex Customer Careline: 08457 573 479

Setting up your aerial

1. Plug the lead from the 12VDC/50mA Power Adaptor (supplied) into the
DC in socket on the back of your aerial.
2. Plug the coax cable running from the back of the aerial into the ANT IN (aerial input)
on the back of your television (or VCR/Satellite Receiver/PVR if preferred).
3. Plug the 12VDC/50mA Power Adaptor into
a mains wall socket and switch on.
4. Turn the Power ON/Gain adjust knob to MAX
(as far to the right as it will go). The LED on the
front of the aerial will light up to indicate that
the power is on.
5. Position the aerial to obtain the best reception.
If there is no picture or the picture breaks up/
freezes reduce the gain a little (turn knob to the
left) and try again. Repeat the process until you
find the optimum aerial position and amount
of gain..
Designer Indoor TV Aerial
4. Power ON/
Gain Adjust Knob
1. Socket for
12VDC/50mA
Power Adaptor
2. Coax Cable
Signal Out
To TV
LED Power
Indicator
Ready
