USER GUIDE

27997R
Philex Customer Careline:
Introduction
Congratulations on your purchase of the SLx
Wireless AV System. This product has been designed
to allow an audio/video signal from equipment such
as DVD players, Digital TV receivers, Satellite Receivers
and VCRs to be both watched and controlled in a
different room without the need to run of cable.
The receiver can work within 30m of the Transmitter
,depending on the building structure, and is supplied
with a Infrared Extender & a Infrared Receiver
allowing you to control your equipment from a
different room.
Parts supplied with the sender system
NOTE:
The transmitter and receiver
can be identified by the label
on the base.
TRANSMITTER SCART
TO 3.5mm JACK
INFRARED EXTENDER
*Careline calls are charged at £1 per minute from a BT landline. Call charges from other networks may vary.
COMPACT AV SENDER
0901 293 0038*
In this day and age, more and more equipment is
becoming wireless. To prevent interference from
neighbouring AV senders, wireless routers, DECT
phones etc this system has up to 4 operating
frequencies to choose from.
Before attempting to install the system, please read
through the instructions carefully ensuring you under-
stand the procedure and have all items necessary.
RECEIVER
RECEIVER SCART TO
3.5mm JACK
POWER ADAPTOR x2
INFRARED RECEIVER
TRANSMITTER
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLx and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SLX SLx

Summary of Contents for SLX SLx

  • Page 1: User Guide

    27997R 0901 293 0038* Philex Customer Careline: Introduction Congratulations on your purchase of the SLx In this day and age, more and more equipment is Wireless AV System. This product has been designed becoming wireless. To prevent interference from to allow an audio/video signal from equipment such...

  • Page 2: Channel Select Button

    Receiver connections & switches layout AV OUTPUT SOCKET Infrared ANTENNA Infrared RECEIVER SOCKET DC INPUT 2.4 GHz wireless video sender CHANNEL SELECT BUTTON ON/OFF SWITCH NOTE: Receiver can be identified by label under the unit...
  • Page 3 Transmitter connections & switches layout Infrared EYE EXTENDER SOCKET AV INPUT SOCKET 2.4 GHz wireless video sender CHANNEL SELECT BUTTON ON/OFF SWITCH NOTE: Transmitter can be identified by label under the unit...
  • Page 4 Getting the best reception • Both the AV Transmitter and Receiver units should • Minimise the number of obstacles between be placed on flat, stable surfaces or wall mounted. the AV Transmitter and Receiver. • Fully extend the Infrared Antenna from the Receiver.

  • Page 5: Transmitter Unit

    Fig. 2 - Receiver Connections Room 2 SECOND TV (BEDROOM/KITCHEN etc.) INFRA-RED ANTENNA POWER ADAPTOR INFRA-RED RECEIVER RECEIVER UNIT SCART INPUT RECEIVER SCART TO 3.5mm JACK Fig. 3 -Transmitter Connections Main Room INFRA-RED EXTENDER (see Fig. 3 for positioning) POWER ADAPTOR SAT, DVD, DVBT etc TRANSMITTER...

  • Page 6: Troubleshooting

    Troubleshooting PROBLEM CAUSE ACTION Problem Cause Action No Picture or Sound The Transmitter and receiver are set Set to identical channels to different channels (See step 6) The Transmitter and/or Receiver are Check the power switches on the not powered unit(s) are both in the On position Check that the Mains Electrical...
  • Page 7 PROBLEM CAUSE ACTION Distance between the Transmitter Reduce the distance between the and receiver is too far units or position the units for a better signal The Transmitter and receiver are set Set to identical channels (See step to different channels The equipment providing or receiv- The Leads are not inserted correct- ing the AV signal is...

  • Page 8: Customer Support

    Declaration of conformity 1856 Declaration of Conformity available at: www.philex.com/support Environmental policy Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority for recycling advice. © Philex Electronic Ltd. 2010. V.1.2...
