- Page 1 Omnidome Compact Amplified VHF/UHF Aerial Kit 27907PI/18 User Guide www.philex.com/products/technical-support/...
- Page 2 Security Installation Safety Warnings • This product may contain small parts-keep out of reach of children. • Risk of accident can be greatly reduced by planninga • After installation make regular maintenance checks project before starting. for wear and tear. •...
-
Page 3: Main Features
Main Features - Compact omni directional amplified ➎ VHF/UHF aerial ideal for outside ➊ ➍ or loft mounting. Suitable for medium and strong signal ➌ ➌ strength areas. ➎ ➋ ➍ ➒ ➑ Before you start ➏ If in any doubt about installation, refer to a professional aerial installer. - Page 4 Assembly 50mm ➍ ➎ ø10mm ➋ ➍ ➎ ➊ ➋ ➌ ➊ ➋ ➊ ➋ Omnidome Compact Amplified UHF Aerial Kit...
-
Page 5: Installation
➊ ➏ Installation I. The power supply unit (11) provides 9VDC power ➐ to the aerial’s amplifier, choose a location close to your TV/PVR, so that a flylead (not supplied) will reach the “ANT IN” aerial socket and within approx. 80cms of a mains socket. -
Page 6: Product Maintenance
Product maintenance - After installation make regular maintenance checks for wear and tear caused by weather or wildlife. Also check connections. If it’s not working - No picture/Poor picture: Check all connections from aerial to TV. Check aerial is facing the nearest transmitter. Check there are no close by obstructions between aerial and transmitter. -
Page 7: Technical Data
Technical Data Frequency VHF: 88-108MHz, UHF: 470-694MHz Gain 18dB Amp. power required 9-12VDC, 100mA Connector F Connector (Female) Power Adaptor AC Input 100-240V~50Hz, 300mA max. DC output 12VDC/300mA max., 3.6W Dimensions W 277 x D 188 x H 193mm The power supply for this product is a Class II appliance protected by double insulation. The power supply for this product is for indoor use only. - Page 8 Waste electrical and electronic products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority for recycling advice. UK Distributor: EU Distributor: Philex Electronic Limited, Philex Electronic Ireland Ltd., Kingfisher Wharf, London Road, Robwyn House, Corrintra, Bedford, MK42 0NX, Castleblayney, Co.
