- Page 1 ASSEMBLY INSTRUCTIONS FOR THE DF832 PEC ATTACHMENT (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
-
Page 2: Box Contents
LEFT HAND CAM FLOATING PULLEY ARM PAD QTY 1 QTY 1 BRACKET QTY 2 QTY 1 CABLE BACKREST PAD RIGHT HAND ARM LEFT HAND ARM QTY 1 QTY 1 QTY 1 QTY 1 DF832 DF832 INSTRUCTIONS HARDWARE QTY 1 QTY 1... - Page 3 M10 LOCK NUT M8 LOCKNUT QTY 2 QTY 2 QTY 8 QTY 2 (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
- Page 4 ARM & PULLEY MOUNT INSTALLATION FRONT OF MACHINE TOOLS REQUIRED: WRENCHES OR METRIC SOCKET SET ASSEMBLE THE ARM MOUNT (A) AND THE SWIVEL PULLEY MOUNT BRACKET (D) TO THE FRONT SUPPORT OF THE LAT MACHINE USING THE M10 x 75MM BOLTS (R), M10 FLAT WASHERS (W) AND M10 LOCK NUTS (AA) NOTE: THE NUTS USED ON THIS PRODUCT ARE LOCK NUTS SO YOU MUST USE A WRENCH TO TIGHTEN THE BOLT.
- Page 5 CAM & ARM PAD ASSEMBLY INSTALL THE ROLLER PADS (H) ON THE ARMS (K,J). (NOTE IT MAY HELP TO TAKE A DAMP CLOTH AND WET THE ARM BEFORE SLIDING THE PAD ON THE ARM) NEXT INSTALL THE CAMS (E,F) ON THE ARMS. THERE IS A LEFT HAND AND A RIGHT HAND SIDE SO YOU WILL NEED TO LOOK AT THE DIAGRAM TO ENSURE CORRECT INSTALLATION NOW INSERT THE 2”...
- Page 6 ARM INSTALLLATION INSERT THE ARM BUSHINGS (N) INTO THE ARM MOUNT (A). NOW ASSEMBLE THE WEIGHT ARMS TO THE ARM MOUNT (A) USING THE M19 LOCKNUTS (Y)
-
Page 7: Swivel Pulley Assembly
SWIVEL PULLEY ASSEMBLY ASSEMBLE THE 4 ½” PULLEY (P) INTO THE SWIVEL PULLEY BRACKET (C) USING THE M10 x 50MM BOLT (S), M10 WASHERS (W), AND M10 LOCKNUT (AA). REPEAT FOR OTHER SWIVEL PULLEY ASSEMBLY. SWIVEL PULLEY INSTALLATION INSTALL THE SWIVEL PULLEY ASSEMBLIES TO THE MOUNT BRACKET USING THE M12 x 190MM BOLTS (Q), M12 WASHERS (V), AND... - Page 8 FIXED PULLEY ASSEMBLY INSTALL THE 4 ½” PULLEY(P) INTO THE FIXED PULLEY BRACKET (B) USING THE M10 x 50MM BOLT (S) M10 WASHERS (W), AND M10 LOCK NUT (AA). FIXED PULLEY & BACKREST INSTALLATION ASSEMBLE THE BACKREST PAD (I) TO THE FRONT SUPPORT OF THE LAT MACHINE USING THE M8 x 70 BOLTS(T) AND THE M8 FLAT WASHERS (X).
-
Page 9: Floating Pulley Assembly
FLOATING PULLEY ASSEMBLY ASSEMBLE THE 4 ½” PULLEY (P) TO THE FLOATING PULLEY BRACKET (G) USING THE M10 x 50MM BOLT (S), M10 WASHERS (W) AND M10 NUT (AA). -
Page 10: Cable Installation
CABLE INSTALLATION SWIVEL PULLEY ASSEMBLIES FIGURE A FLOATING PULLEY ASSEMBLY ATTACH THE PEC CABLE TO THE CAM ON THE LEFT SIDE USING THE M8 x 25MM BOLT, M8 WASHERS , AND M8 LOCKNUT. (SEE FIGURE A) NOTE: THERE ARE ADJUSTMENT HOLES ON EACH CAM TO COMPENSATE FOR CABLE STRETCH AFTER THE MACHINE IS USED FOR A WHILE. - Page 11 CABLE INSTALLATION RE-ATTACH LOWER CABLE HERE DISCONNECT LOWER CABLE FROM HERE DISCONNECT THE LOWER CABLE ALREADY ATTACHED TO THE MACHINE AND RUN IT THOUGH THE FIXED PULLEY AND RE-ATTACH IT TO THE RING AT THE BOTTOM OF THE FLOATING PULLEY ASSEMBLY. MAKE SURE ALL YOUR BOLTS ARE TIGHT BEFORE USE.
-
Page 12: Safety Notice
SAFETY NOTICE WARNING: THE USER OF THIS WEIGHT EQUIPMENT ASSUMES THE POSSIBILITY OF INJURY BY EXERCISING ON THIS EQUIPMENT. THE POSSIBILITY OF RISK CAN BE REDUCED BY ALWAYS FOLLOWING THESE SIMPLE RULES: 1) BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR DOCTOR FOR A COMPLETE PHYSICAL EXAMINATION AND SUGGESTED EXERCISE PROGRAM SPECIFIC FOR YOU. - Page 13 T-SHIRT ORDER FORM DELTECH FITNESS T - SHIRT SIZES AVAILABLE ARE M-XXL. THE COLOR OF THE SHIRTS ARE WHITE. RED AND BLACK LOGO. ONLY $12.99 DELTECH FITNESS MUSCLE SHIRT SIZES AVAILABLE M-XXL THE COLOR AVAILABLE IS BLACK. RED AND WHITE LOGO.
