3Com V7122 Installation Manual page 48

Load an ini File Screen
Figure 22
In the Load an ini File screen, you can now choose to either:
6
Click Browse and navigate to the ini file; the Use existing configuration check box, by
default checked, becomes unchecked. Click Send File; the ini file is loaded to the
V7122 gateway and you are notified as to a successful loading.
Ignore the Browse button (its field remains undefined and the check box Use existing
configuration remains checked by default).
Ignore the Browse button and uncheck the Use existing configuration check box; no
ini file is loaded, the V7122 gateway uses its factory-preconfigured values.
You can now choose to either:
Click Cancel; the V7122 gateway resets utilizing the cmp, ini and all other
configuration files that were previously stored in flash memory. Note that these are
NOT the files you loaded in the previous Wizard steps.
Click Reset; the V7122 gateway resets, utilizing the new cmp and ini file you loaded
up to now as well as utilizing the other configuration files.
Click Back; the Load a cmp file screen is reverted to; see
Click Next; the Load a CPT File screen opens, see
file or any other auxiliary file listed in the Wizard is optional.
48
Figure 20.
Figure 23; Loading a new CPT
V7122 Digital Gateway Installation Guide
