Page 1: User Manual
User Manual Edition: 2013-03-12 Draco KVM Extender Model: K474 Series IHSE GmbH Maybachstrasse 11 88094 Oberteuringen Germany info@ihse.de www.ihse.de Tel. +49 7546-9248-0 Fax +49 7546-9248-48... - Page 2 Draco KVM Extender Copyright © 2013. All rights reserved. This information may not be reproduced in any manner without the prior written consent of the manufacturer. Information in this document is subject to change without notice. Trademarks All trademark and trade names mentioned in this document are acknowledged to be the property of their respective owners.
-
Page 3: Table Of Contents
Contents Contents About This Manual ............... 7 Scope.................. 7 Validity ................7 Cautions and Notes ............7 Safety Instructions ............... 8 Description ................... 9 Application ................9 System Overview .............. 10 Product Range ..............11 3.3.1 Part Numbers............11 3.3.2 Chassis ............... - Page 4 Draco KVM Extender 3.6.14 Model L- / R474-BUE .......... 26 3.6.15 Model L- / R474-BAX .......... 27 3.6.16 Model L- / R474-BAP .......... 27 3.6.17 Model L- / R474-BXP .......... 28 3.6.18 Model L- / R474-BDX .......... 28 3.6.19 Model L- / R474-BAH .......... 29 3.6.20 Model L- / R474-BDH..........
- Page 5 Contents Configuration File .............. 49 Operation ..................50 Download of DDC Information .......... 50 Specifications ................51 Interfaces ................51 7.1.1 DVI-D Single Link..........51 7.1.2 DVI-I Single Link ..........51 7.1.3 USB-HID ............. 51 7.1.4 PS/2 ..............52 7.1.5 USB 2.0 (transparent) .........
- Page 6 Certificates.................. 77 10.1 CE Declaration Of Conformity........... 77 10.2 North American Regulatory Compliance ......78 10.3 WEEE ................78 10.4 RoHS/RoHS 2..............78 Glossary..................79 Pos: 1 /806-IHSE/Zu diesem Handbuch/ATB_Zu diesem Handbuch @ 5\mod_1278573163276_6.doc @ 41510 @ 1222 @ 1 2013-03-12...
-
Page 7: About This Manual
This symbol indicates important information to help you make the best use of this product. This symbol indicates best practice information to show recommended and optimal ways to use this product in an efficient way. Pos: 2 /806-IHSE/Sicherheitshinweise/ATB_Sicherheitshinweise @ 5\mod_1278573321245_6.doc @ 41528 @ 1 @ 1 2013-03-12... -
Page 8: Safety Instructions
Do not attempt to open or repair the KVM Extender. There are no user serviceable parts inside. Please contact your dealer or manufacturer if there is a fault. Pos: 3 /806-IHSE/Beschreibung/UEB_Beschreibung @ 5\mod_1278573379151_6.doc @ 41546 @ 1 @ 1 2013-03-12... -
Page 9: Description
The KVM Extender with fiber interconnect cables can also be used with applications in environments which are difficult in electromagnetical aspects. Electromagnetical interference can limit the maximum distance und reliability. Pos: 5 /806-IHSE/Beschreibung/System-Übersicht /474-xx @ 6\mod_1304579735410_6.doc @ 50803 @ @ 1 2013-03-12... -
Page 10: System Overview
KVM Extender CON Unit Console (monitor, keyboard, mouse) Second monitor (option, only with Dual-Head devices) USB-HID devices (option, only with 4x USB-HID devices) See Chapter 4.3, Page 43 for installation examples. Pos: 6 /806-IHSE/Beschreibung/Gerätetypen/474-xx @ 6\mod_1304579897770_6.doc @ 50821 @ 2333333 @ 1 2013-03-12... -
Page 11: Product Range
The part numbers for the CPU Unit and the CON Unit can be derived from the part number of the complete device. CPU Unit: L474 CON Unit: R474 All devices of the K474 series are technically compatible to the devices of the K477 series. 3.3.2 Chassis Model Description... -
Page 12: Kvm-Extender Modules
Draco KVM Extender Model Description 474-BODY6R Empty chassis for up to 6 boards, 1x internal power supply unit, preparation for redundancy for a second power supply unit (external) 474- Empty chassis for up to 21 boards, 1x internal power BODY21R supply unit, preparation for redundancy for a second power supply unit (internal) 3.3.3... -
Page 13: Complete Units
Description Model Description L474-BAH Upgrade module with Analog Audio / Serial (bidirectional) and 2x USB-HID R474-BAH L474-BUE Upgrade module with Analog Audio (bidirectional) and 2x USB 2.0 R474-BUE L474-BAE Upgrade module with Analog Audio / Serial (bidirectional) and 2x USB 2.0 R474-BAE L474-BDH Upgrade module with Digital Audio (unidirectional) and... -
Page 14: Model Description
Draco KVM Extender Model Description K474-1SHxD Single-Head-KVM Extender for 1x DVI-D Single Link (up to 1920x1200), 2x USB-HID and Digital Audio Option Single-Head-KVM Extender for 1x DVI-D Single Link (up K474-1SExD to 1920x1200) with 2x USB-HID, 2x USB 2.0 and Digital Audio option Single-Head-KVM Extender for 1x DVI-D Single Link (up K474-1S4x... - Page 15 Description Model Description K474-2STxA Dual-Head-KVM Extender for 2x DVI-D Single Link (up to 1920x1200), 4x USB-HID, Analog Audio / Serial option and 4x USB 2.0 K474-2STxD Dual-Head-KVM Extender for 2x DVI-D Single Link (up to 1920x1200), 4x USB-HID, Digital Audio option and 4x USB 2.0 K474-4S8x Quad-Head-KVM Extender for 4x DVI-D Single Link...
-
Page 16: Accessories Upgrade Kits
When using redundant power supply units, there will be a load sharing. Pos: 7 /806-IHSE/Beschreibung/Einbauoptionen/474-xx @ 6\mod_1304580008551_6.doc @ 50839 @ 2 @ 1 Accessories Upgrade Kits Model... -
Page 17: Accessories
Please note that you will need at least 0.5 U (height unit) for the ventilation above the extenders, if you mount them into racks. Pos: 8 /806-IHSE/Beschreibung/Zubehör/477-xx_COMP @ 5\mod_1291120662750_6.doc @ 44582 @ 2 @ 1 Accessories Model... -
Page 18: Device Views
Draco KVM Extender Device Views Pos: 10 /806-IHSE/Beschreibung/Geräteansichten/474-xx/2-fach Vario-Gehäuse 474-BODY2/2R @ 6\mod_1304580280566_6.doc @ 50858 @ 3 @ 1 3.6.1 2-fold Vario Chassis 474-BODY2/2R CPU and CON Unit Rear View Slot for modules #1 Connect to 5VDC power supply (standard) Slot for modules #2 Connect to 5VDC power supply (redundancy, optional) Pos: 11 /806-IHSE/Beschreibung/Geräteansichten/474-xx/2-fach Vario-Gehäuse 474-BODY2N @ 8\mod_1348578478411_6.doc @ 69380 @ 3 @ 1... -
Page 19: 2-Fold Vario Chassis 474-Body2N
The 2-fold vario chassis with an internal power supply is not equipped with a fuse on primary side. Therefore the protection against excessive currents has to be provided by the electrical installation of the building. Pos: 12 /806-IHSE/zz_Layout/Seitenumbruch @ 8\mod_1348581820516_0.doc @ 69462 @ @ 1 2013-03-12... -
Page 20: 4-Fold Vario Chassis 474-Body4/4R
Draco KVM Extender Pos: 13 /806-IHSE/Beschreibung/Geräteansichten/474-xx/4-fach Vario-Gehäuse 474-BODY4/4R @ 6\mod_1304580359098_6.doc @ 50876 @ 3 @ 1 3.6.3 4-fold Vario Chassis 474-BODY4/4R CPU and CON Unit Rear View Slot for modules #3 Slot for modules #1 Connect to 5VDC power supply (standard) -
Page 21: 6-Fold Vario Chassis 474-Body6R
Description Pos: 15 /806-IHSE/Beschreibung/Geräteansichten/474-xx/6-fach Vario-Gehäuse 474-BODY6R @ 6\mod_1304580442488_6.doc @ 50894 @ 3 @ 1 3.6.4 6-fold Vario Chassis 474-BODY6R CPU and CON Unit Rear View Slot for modules #5 Slot for modules #3 Slot for modules #1 Connect to power supply (standard) -
Page 22: 21-Fold Vario Chassis 474-Body21R
Draco KVM Extender Pos: 17 /806-IHSE/Beschreibung/Geräteansichten/474-xx/21-fach Vario-Gehäuse 474-BODY21R @ 8\mod_1348579151346_6.doc @ 69400 @ @ 1 3.6.5 21-fold Vario Chassis 474-BODY21R CPU and CON Unit Front View Slots for modules #1 - #21 Rear View Connect to power supply 2 Locking for power supply 2 (redundancy) -
Page 23: Model L- / R474-Bshc
To CPU: USB-HID Connect to USB-HID devices To CPU: DVI-D Connect to DVI monitor Pos: 20 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BSHS / -BSHX @ 6\mod_1304580536098_6.doc @ 50930 @ 3 @ 1 3.6.7 Model L- / R474-BSHS / -BSHX CPU Module CON Module... -
Page 24: Model L- / R474-Bshs-Red
Draco KVM Extender Pos: 22 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BSHC-RED @ 9\mod_1362471988604_6.doc @ 71210 @ 3 @ 4 3.6.8 Model L- / R474-BSHCR CPU Module CON Module Rear View Rear View Service port Service port Connect to interconnect cable 1 Connect to interconnect cable 1... -
Page 25: Model L- / R474-Bshcv
IR receiver for remote control IR receiver for remote control Connect to DVI monitor Service port (DVI-I) Pos: 25 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BSHSV / -BSHXV @ 6\mod_1304583459332_6.doc @ 50966 @ 3 @ 1 3.6.11 Model L- / R474-BSHSV / -BSHXV CPU Module CON Module... -
Page 26: Model L- / R474-Bxh
CON Module Rear View Rear View To CPU: USB-HID Connect to USB-HID devices Pos: 27 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BXE @ 7\mod_1331798896275_6.doc @ 58110 @ 3 @ 1 3.6.13 Model L- / R474-BXE CPU Module CON Module Rear View Rear View To CPU: USB 2.0... -
Page 27: Model L- / R474-Bax
Connect to serial (D-Sub 9) Audio IN Audio IN Audio OUT Audio OUT Pos: 30 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BAP @ 9\mod_1362472648439_6.doc @ 71250 @ 3 @ 4 3.6.16 Model L- / R474-BAP CPU Module CON Module Rear View Rear View... -
Page 28: Model L- / R474-Bxp
L- / R474-BAX and –BAH. A separate slot is required for each module. Pos: 32 /806-IHSE/zz_Layout/Seitenumbruch @ 8\mod_1348581820516_0.doc @ 69462 @ @ 1 Pos: 33 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BDX @ 6\mod_1304583577801_6.doc @ 51020 @ 3 @ 1 3.6.18 Model L- / R474-BDX CPU Module... -
Page 29: Model L- / R474-Bah
Audio IN Audio OUT Audio OUT To CPU: USB-HID Connect to USB-HID devices Pos: 35 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BDH @ 6\mod_1304583646457_6.doc @ 51056 @ 3 @ 1 3.6.20 Model L- / R474-BDH CPU Module CON Module Rear View Rear View... -
Page 30: Model L- / R474-Bae
Audio IN Audio OUT Audio OUT To CPU: USB 2.0 Connect to USB 2.0 devices Pos: 37 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BDE @ 8\mod_1348580272466_6.doc @ 69440 @ 3 @ 1 3.6.22 Model L- / R474-BDE CPU Module CON Module Rear View... -
Page 31: Model L- / R474-Bdd
Description Pos: 40 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BDD @ 6\mod_1304583696426_6.doc @ 51074 @ 3 @ 1 3.6.24 Model L- / R474-BDD CPU Module CON Module Rear View Rear View S/PDIF input (RCA) S/PDIF output (RCA) AES/EBU input (Mini-XLR) AES/EBU output (Mini-XLR) -
Page 32: Modell L- / R474-Bxtc
Draco KVM Extender Pos: 43 /806-IHSE/Beschreibung/Geräteansichten/474-xx/Typ L- / R474-BXTC @ 6\mod_1304583784582_6.doc @ 51110 @ 3 @ 1 3.6.26 Modell L- / R474-BXTC CPU Module CON Module Rear View Rear View Service port Service port Connect to interconnect cable Connect to interconnect cable To CPU: USB 2.0... -
Page 33: Status Leds
Connection and USB signal (interconnect) available Violet Green Connection and video signal available Connection, USB and video signal available Light Blue (operating status) Pos: 48 /806-IHSE/Beschreibung/Diagnose LEDs/474-xx/Diagnose KVM-Extender-Modul VGA / DVI-I @ 6\mod_1304584132098_6.doc @ 51183 @ 3 @ 1 2013-03-12... -
Page 34: Status Kvm-Extender Module Vga / Dvi-I
Video signal supported; monitor not detected Blue No video signal; monitor detected Violet Video signal not supported; monitor detected Light Blue Video signal supported; monitor detected Pos: 49 /806-IHSE/Beschreibung/Diagnose LEDs/474-xx/Diagnose Zusatzmodul Digital-Audio @ 6\mod_1304584173301_6.doc @ 51201 @ 3 @ 1 2013-03-12... -
Page 35: Status Upgrade Module Digital Audio
CPU Unit: S/PDIF signal (RCA) available Violet CPU Unit: AES/EBU signal (Mini-XLR) available Blue CPU Unit: S/PDIF signal (TOSLINK) available Green CON Unit: Signal available Pos: 50 /806-IHSE/Beschreibung/Diagnose LEDs/474-xx/Diagnose Zusatzmodul USB-HID @ 6\mod_1304584220145_6.doc @ 51219 @ 3 @ 1 2013-03-12... -
Page 36: Status Upgrade Module Usb-Hid
CON Unit: Keyboard in command mode Flashing CON Unit: KVM Extender in command slowly mode or no connection Flashing Operating status fast Pos: 51 /806-IHSE/Beschreibung/Diagnose LEDs/474-xx/Diagnose Zusatzmodul USB 2.0 embedded @ 7\mod_1331803265129_6.doc @ 58231 @ 3 @ 1 2013-03-12... -
Page 37: Status Upgrade Module Usb 2.0 Embedded
CPU) available USB 2.0 device(s) connected Status LED No connection between CON and CPU (green) module Connection between CON and CPU module available Pos: 52 /806-IHSE/Beschreibung/Diagnose LEDs/474-xx/Diagnose Zusatzmodul USB 2.0 @ 6\mod_1304584254816_6.doc @ 51237 @ 3 @ 1 2013-03-12... -
Page 38: Status Upgrade Module Usb 2.0
Only connection available, no USB 2.0 signal Green / Connection available, no USB 2.0 device light blue connected flashing Light blue Connection and USB 2.0 signal available (operating status) Pos: 53 /806-IHSE/Installation/UEB_Installation @ 5\mod_1278574971589_6.doc @ 41768 @ 1 @ 1 2013-03-12... -
Page 39: Installation
Installation Installation Pos: 54 /806-IHSE/Installation/Lieferumfang prüfen/474-xx @ 6\mod_1304584334582_6.doc @ 51255 @ 2 @ 1 Package Contents Your extender package contains the following items: KVM Extender: KVM Extender pair (CPU Unit and CON Unit) in the vario chassis 1x (redundancy 2x) 5VDC international power supply unit per KVM Extender unit ... - Page 40 USB cable (1.8 m, USB type A to type B) Additional content for upgrade module USB 2.0: USB cable (1.8 m, USB type A to type B) If anything is missing, contact your dealer. Pos: 55 /806-IHSE/zz_Layout/Seitenumbruch @ 8\mod_1348581820516_0.doc @ 69462 @ @ 1 2013-03-12...
-
Page 41: System Setup
Installation Pos: 56 /806-IHSE/Installation/System anschließen/474-xx @ 6\mod_1304584542160_6.doc @ 51273 @ 233 @ 1 System Setup First time users are recommended to setup the system with the CPU Unit and the CON Unit in the same room as a test setup. This will allow you to identify and solve any cabling problems, and experiment with your system more conveniently. -
Page 42: Setup Of Upgrade Modules
Draco KVM Extender 4.2.2 Setup of Upgrade Modules The modules can be hot plugged. Upgrade Module Analog Audio / Serial: Connect the audio source with the CPU Unit (e.g. CPU audio output with audio input, CPU audio input with audio output). Connect the audio output at the CON Unit with headphones or suitable speakers. -
Page 43: Example Applications
Connect the CPU with the CPU Unit (USB 2.0). Connect the USB 2.0 devices with the CON Unit (Connect to USB 2.0 devices). Pos: 57 /806-IHSE/Installation/Installationsbeispiele/UEB_Installationsbeispiele @ 5\mod_1278581564870_6.doc @ 42759 @ 2 @ 1 Example Applications This section illustrates typical installations of KVM Extenders: Pos: 58 /806-IHSE/Installation/Installationsbeispiele/477-xx_COMP @ 5\mod_1291124264328_6.doc @ 44767 @ @ 1... - Page 44 Draco KVM Extender KVM Extender (Single-Head with Digital / Analog Audio) KVM Extender (Dual-Head with 4x USB-HID) Source (computer, CPU) KVM Extender CPU Unit Interconnect cable KVM Extender CON Unit Console (monitor, keyboard, mouse) Second monitor (option, only with Dual-Head devices) USB 2.0 devices (option, only with 2x USB 2.0 devices) Audio sink (optional, only with devices with Analog Audio / Serial option or Digital Audio option)
-
Page 45: Configuration
In exceptional cases there can appear detached "frame droppings" (loss of single pictures) or color effects. Pos: 61 /806-IHSE/Konfiguration/DDC-Einstellungen/477-xx @ 5\mod_1278937107542_6.doc @ 43093 @ 2 @ 1 DDC Settings By default, the device transmits the factory preset DDC information to the CPU. -
Page 46: Command Mode
Draco KVM Extender Pos: 62 /806-IHSE/Konfiguration/Kommando-Modus/474-xx @ 6\mod_1304585026863_6.doc @ 51291 @ 2 @ 1 Command Mode During normal use, the console keyboard functions in the usual manner. However, for all KVM Extenders with USB-HID support, you can set the keyboard into a Command Mode by using a specific 'Hot Key' sequence. - Page 47 In order to set a 'Hot Key' back to default settings of the extender, press the key combination <Right Shift> + <Del> within 5 s after switching on the CON unit or plugging in a keyboard. Pos: 63 /806-IHSE/Konfiguration/USB-HID-Ghosting/K477_USB-HID-Ghosting @ 9\mod_1362404683851_6.doc @ 71192 @ 2 @ 4 2013-03-12...
-
Page 48: Usb-Hid Ghosting
CPU Unit. Deleting the descriptions out of the CPU Unit. The input devices connected to the CON Unit will be now passed transparently to the source (computer, CPU). Pos: 64 /806-IHSE/Konfiguration/474_Konfigurationsdatei/474-xx @ 7\mod_1331801555639_6.doc @ 58172 @ 2 @ 1 2013-03-12... -
Page 49: Configuration File
USB connection to a computer. The configuration file can be edited with all common text editors. The individual settings of the parameters are described in the respective chapters. Pos: 65 /806-IHSE/Betrieb/UEB_Betrieb @ 5\mod_1278577614980_6.doc @ 41970 @ 1 @ 1 2013-03-12... -
Page 50: Operation
Draco KVM Extender Operation Pos: 66 /806-IHSE/Betrieb/Laden von DDC-Informationen/477-xx @ 5\mod_1278937455136_6.doc @ 43130 @ 2 @ 1 Download of DDC Information By default, data from the internal DDC list is reported to the source (computer, CPU). If these settings do not lead to a satisfying result, the DDC information of the console monitor can be downloaded and stored internally. -
Page 51: Specifications
Specifications Specifications Pos: 68 /806-IHSE/Technische Daten/Schnittstellen/UEB_Schnittstellen @ 5\mod_1278578201870_6.doc @ 42114 @ 2 @ 1 Interfaces Pos: 69 /806-IHSE/Technische Daten/Schnittstellen/DVI-D-Single-Link @ 5\mod_1278578254058_6.doc @ 42132 @ 3 @ 1 7.1.1 DVI-D Single Link The video interface supports the DVI-D protocol. All signals that comply to DVI-D Single Link norm can be transmitted. -
Page 52: Ps/2
Mouse Compatible with most 2-button, 3-button and scroll mice. Pos: 73 /806-IHSE/Technische Daten/Schnittstellen/474-xx (USB 2.0 (transparent)) @ 7\mod_1331801757497_6.doc @ 58190 @ 3 @ 1 7.1.5 USB 2.0 (transparent) KVM Extender models with transparent USB 2.0 support allow the connection of all types of USB 2.0 devices (without restriction). -
Page 53: Fiber Sfp Type Lc (Interconnect)
SFP modules can be damaged by electrostatic discharge (ESD). Please consider ESD handling specifications. Pos: 76 /806-IHSE/Technische Daten/Schnittstellen/Serielle Schnittstelle @ 5\mod_1291127444390_6.doc @ 44828 @ @ 1 7.1.8 Serial Interface The serial interface option supports a... -
Page 54: Analog Audio Interface
DTR (Data Terminal Ready) DSR (Data Set Ready) Pos: 77 /806-IHSE/Technische Daten/Schnittstellen/474-xx (Analoge Audio-Schnittstelle) @ 7\mod_1332491046975_6.doc @ 58270 @ 3 @ 1 7.1.9 Analog Audio Interface The analog audio option supports a bidirectional stereo audio transmission, in nearly CD quality. -
Page 55: Serial Interface Rs422
2x 3.5 mm stereo jack plug (audio in & audio out) Pos: 78 /806-IHSE/Technische Daten/Schnittstellen/Serielle Schnittstelle RS422 @ 9\mod_1362475591209_6.doc @ 71309 @ 3 @ 4 7.1.10 Serial Interface RS422 KVM Extenders with a serial interface RS422 (D-Sub 9) support a differential full duplex transmission up to a Baud rate of 115,200 Baud. -
Page 56: Digital Audio Interface
Draco KVM Extender 7.1.11 Digital Audio Interface The digital audio option supports the unidirectional transmission of digital audio data. Up to three sources can be connected to the CPU Unit. The active source is transmitted. If several sources are active, the XLR signal takes priority, otherwise the first active signal. -
Page 57: Interconnect Cable
Optical (S/PDIF; TOSLINK) Pos: 80 /806-IHSE/Technische Daten/Verbindungskabel/UEB_Verbindungskabel @ 5\mod_1279191107845_6.doc @ 43870 @ 2 @ 1 Interconnect Cable Pos: 81 /806-IHSE/Technische Daten/Verbindungskabel/Verbindungskabel (Cat X) @ 5\mod_1278578406026_6.doc @ 42205 @ 3 @ 1 7.2.1 Cat X A point-to-point connection is required. Operation with several patch fields is possible. -
Page 58: Cat X
The use of flexible cables (patch cables) type AWG26/8 is possible, however the maximum possible extension distance is halved. Pos: 82 /806-IHSE/Technische Daten/Verbindungskabel/Verbindungskabel (Cat X)_Kabellänge 477-xx @ 5\mod_1278937761105_6.doc @ 43167 @ @ 1 Maximum Acceptable Cable Length Cat X Installation Cable... -
Page 59: Fiber
Pos: 85 /806-IHSE/Technische Daten/Verbindungskabel/Verbindungskabel (LWL)_Steckverbinder 477-xx @ 5\mod_1278954447542_6.doc @ 43740 @ @ 1 Type of Connector Connector LC Connector Pos: 86 /806-IHSE/Technische Daten/Unterstützte Peripherie/UEB_Unterstützte Peripherie @ 5\mod_1278578478761_6.doc @ 42242 @ 2 @ 1 2013-03-12... -
Page 60: Supported Peripherals
Draco KVM Extender Supported Peripherals Pos: 87 /806-IHSE/Technische Daten/Unterstützte Peripherie/USB-HID-Geräte @ 5\mod_1278578523558_6.doc @ 42260 @ @ 1 7.3.1 USB-HID Devices The KVM Extender will support most USB-HID devices, including the vast majority of keyboards and mice currently on the market. Many other kinds... -
Page 61: Connector Pinouts
Specifications Connector Pinouts Pos: 90 /806-IHSE/Technische Daten/Pinbelegungen/Buchse DVI-D Single-Link @ 5\mod_1278578723073_6.doc @ 42333 @ @ 1 Connector DVI-D Single-Link 1......8 C1 C2 17......24 C3 C4 Pin Signal Pin Signal Pin Signal T.M.D.S data 2 – 9 T.M.D.S data 1 – 17 T.M.D.S data 0 –... - Page 62 V-sync Hot Plug T.M.D.S clock– recognition Red signal Blue signal Green signal H-sync Pos: 92 /806-IHSE/Technische Daten/Pinbelegungen/Buchse USB Typ B @ 5\mod_1278578750464_6.doc @ 42351 @ @ 1 Connector USB Type B Picture Signal Color VCC (+5VDC) Data – White Data +...
- Page 63 Picture Signal Color VCC (+5VDC) Data – White Data + Green Black Pos: 94 /806-IHSE/Technische Daten/Pinbelegungen/Buchse Mini-USB Typ B @ 5\mod_1278578794167_6.doc @ 42387 @ @ 1 Connector Mini USB Type B Picture Signal Color VCC (+5VDC) Data – White ..5...
- Page 64 D-Sub 9 (Serial) RS232 Picture Signal Signal n.c. 1....5 6...9 n.c. Pos: 100 /806-IHSE/Technische Daten/Pinbelegungen/D-Sub 9 (Seriell) RS422 Controlled Device @ 9\mod_1362477200520_6.doc @ 71349 @ @ 4 D-Sub 9 (Serial) RS422 Controlled Device Picture Signal Signal Rx-GND 1....5 6...9 Tx-GND n.c.
- Page 65 Tx-GND 1....5 6...9 Rx-GND n.c. n.c. Pos: 102 /806-IHSE/Technische Daten/Pinbelegungen/Stereo-Klinkenbuchse 3,5 mm @ 5\mod_1291128765156_6.doc @ 44901 @ @ 1 3.5 mm Stereo Jack Plug Picture Signal Audio IN / OUT L Audio IN / OUT R Pos: 103 /806-IHSE/Technische Daten/Pinbelegungen/RCA (Cinch) @ 5\mod_1291128877593_6.doc @ 44920 @ @ 1...
-
Page 66: Power Supply
Draco KVM Extender TOSLINK Picture Diode Signal Data IN / OUT Pos: 106 /806-IHSE/Technische Daten/Stromversorgung/474-xx @ 6\mod_1304586284191_6.doc @ 51327 @ 2 @ 1 Power Supply AC Power Supply Model Nominal Current Nominal Voltage Frequency 474-BODY2N 700 mA max. 100-240 V... -
Page 67: Environmental Conditions
Storage Temperature –13 to 140°F (–25 to 60°C) Relative Humidity Max. 80% non-condensing Pos: 108 /806-IHSE/Technische Daten/Abmessungen/474-xx @ 6\mod_1304586358176_6.doc @ 51345 @ 2 @ 1 Size Devices in the 2-fold Vario Chassis 1 CPU Unit / CON Unit 145 x 147 x 41 mm (5.7" x 5.8" x 1.7") Shipping Box 210 x 140 x 165 mm (8.3"... -
Page 68: Shipping Weight
4.6 kg (10.1 lb) Devices in the 21-fold Vario Chassis CPU Unit / CON Unit 10.0 kg (22.1 lb) Shipping Box 14.5 kg (32.0 lb) Pos: 111 /806-IHSE/Hilfe im Problemfall/UEB_Hilfe im Problemfall @ 5\mod_1278579113839_6.doc @ 42536 @ 1 @ 1 2013-03-12... -
Page 69: Troubleshooting
CPU Unit quality of interconnect cables between the units. Download DDC information from console monitors (see Chapter 6.1, Page 50). Reboot CPU if necessary. Pos: 113 /806-IHSE/Hilfe im Problemfall/Störung am USB-HID-Anschluss/474-xx @ 6\mod_1304586621613_6.doc @ 51399 @ @ 1 2013-03-12... -
Page 70: Usb-Hid
USB device No USB-HID device Connect USB-HID device. without function USB-HID device is not Contact dealer if necessary. supported Pos: 114 /806-IHSE/Hilfe im Problemfall/Störung am seriellen Anschluss/474-xx @ 6\mod_1304586713332_6.doc @ 51418 @ @ 1 2013-03-12... -
Page 71: Serial Connection
Touch screen Hardware handshake Adjust serial interface to X-ON / not operational X-OFF software handshake. Pos: 115 /806-IHSE/Hilfe im Problemfall/Störung am Analog-Audio-Anschluss/474-xx @ 6\mod_1304586773051_6.doc @ 51437 @ @ 1 Analog Audio Diagnosis Possible Reason Measure CON Unit: No audio connection to ... -
Page 72: Digital Audio
No signal / Digital Silence at active Check LEDs at CPU Unit. LEDs 1 OK audio source Check audio format. Change audio input. Pos: 117 /806-IHSE/Hilfe im Problemfall/Störung am USB-HID-Modul-Anschluss/474-xx @ 6\mod_1304586906004_6.doc @ 51475 @ @ 1 2013-03-12... -
Page 73: Upgrade Module Usb-Hid
CON Unit: Connection between Check interconnect cable and LED 3 flashing CON Unit and CPU Unit connections. slowly Keyboard in Command Press <Esc> to leave Command Mode Mode. Pos: 118 /806-IHSE/zz_Layout/Seitenumbruch @ 8\mod_1348581820516_0.doc @ 69462 @ @ 1 2013-03-12... -
Page 74: Usb 2.0 Embedded
Draco KVM Extender Pos: 119 /806-IHSE/Hilfe im Problemfall/Störung am USB-2.0-Embedded-Anschluss/474-xx @ 7\mod_1331802913522_6.doc @ 58211 @ 2 @ 1 USB 2.0 embedded CPU Module CON Module Rear View Rear View Diagnosis Possible Reason Measure CPU & CON No connection to CPU ... -
Page 75: Usb 2.0
Troubleshooting Pos: 121 /806-IHSE/Hilfe im Problemfall/Störung am USB-2.0-Anschluss/474-xx @ 6\mod_1304586956738_6.doc @ 51494 @ 2 @ 1 USB 2.0 CPU Module CON Module Rear View Rear View Diagnosis Possible Reason Measure CPU Unit: No connection to CPU Check connection USB cable to All LEDs off CPU;... -
Page 76: Technical Support
Note your RMA number visibly on your shipment. Devices that are sent in without a RMA number cannot be accepted. The shipment will be sent back without being opened, postage unpaid. Pos: 123 /806-IHSE/Zertifikate/UEB_Zertifikate @ 5\mod_1278579534933_6.doc @ 42668 @ 1 @ 1 2013-03-12... -
Page 77: Certificates
Certificates Certificates Pos: 124 /806-IHSE/Zertifikate/ATB_Europäische Konformitätserklärung @ 5\mod_1278579640901_6.doc @ 42686 @ 2 @ 1 10.1 CE Declaration Of Conformity The products listed below in the form as delivered comply with the provisions of the following European Directives: 2004/108/EG Council Directive on the approximation of the laws of... -
Page 78: North American Regulatory Compliance
All power supplies are certified to the relevant major international safety standards. Pos: 125 /806-IHSE/Zertifikate/ATB_WEEE @ 5\mod_1278579673292_6.doc @ 42704 @ 2 @ 1 10.3 WEEE The manufacturer complies with the EU Directive 2012/19/EU on the prevention of waste electrical and electronic equipment (WEEE). -
Page 79: Glossary
Glossary Glossary The following terms are commonly used in this guide or in video and KVM technology: Term Explanation AES/EBU Digital audio standard that is officially known as AES3 and that is used for carrying digital audio signals between devices. Cat X Any Cat 5e (Cat 6, Cat 7) cable The Color Graphics Adapter (CGA) is an old analog... - Page 80 Draco KVM Extender Term Explanation Digital video standard, introduced by the Digital Display Working Group (http://www.ddwg.org). Single Link and Dual Link standard are distinguished. The signals have TMDS level. DVI-I A combined signal (digital and analog) that allows running a VGA monitor at a DVI-I port – in contrast to DVI-D (see DVI).
- Page 81 Glossary Term Explanation S-Video (Y/C) The S-Video (Y/C) is a video format transmitting luminance and chrominance signals separately. Thereby it has a higher quality standard than CVBS. TOSLINK Standardized fiber connection system for digital transmission of audio signals (F05 plug connection) Triple-Head A system with three video connections USB-HID...
