Product Information

The AXR-NWS NetWave Server is a two-way Radio Frequency (RF) device employing 2.4 GHz
digital communications. The AXR-NWS is compatible with both Axcess and NetLinx Integrated
Central Controllers, and communicates with up to 16 wireless devices.
The AXR-NWS complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operation.

Specifications

The following table lists the AXR-NWS specifications.
Specifications
Dimensions (HWD)
NWS without antenna
NWS with antenna
Faceplate
Weight
Power Requirement
Enclosure
Operating Frequency
Control Compatibility
Front Panel Components:
AXlink LED
Status LED
RX LED
Group Address
Group ID
Rear Panel Components:
Antenna
AXR-NWS NetWave Server
1.65" x 5.55" x 6.40" (4.19 cm x 14.10 cm x 16.20 cm)
7.41" x 5.55" x 6.40" (18.82 cm x 14.10 cm x 16.20 cm)
1.50" x 5.55" x 0.53" (3.80 cm x 14.10 cm x 1.30 cm)
10.56 oz (299.37 g)
175 mA @ 12 VDC
Metal with black anodized matte finish
2.4 GHz RF digital spread-spectrum transmission and reception with up to 16
ViewPoints
Axcess Central Controllers
NetLinx Central Controllers
Landmark Controller
Green LED that shows power and AXlink communication activity. Blink patterns
include:
• Off - No power or the controller is not functioning properly.
• One blink per second - indicates power is active and AXlink data
communication is functional.
• Full On - Indicates power is active and AXlink data communication is not
functional.
Red LED that lights when an RF link is established with one or more devices.
• If the light is On, the Server's signal is locked and communicating with the
ViewPoint.
• If the light is Off, the Server is not communicating with the ViewPoint because
the signal is either lost or broken.
Yellow LED that lights when the AXR-NWS receives RF control data.
8 position DIP switch that sets the GROUP ADDRESS (0 - 255)
4 position DIP switch that sets the control group identification (0 - 15)
Omni-directional, swivel high-gain RF antenna
Product Information
