• Do not allow the unit to be exposed to hot, cold or humid conditions. • Service should only be carried out at a Nokia Authorised Service Centre. • Please note that the only way to isolate the Mediamaster completely from...
Remote control This section describes how to operate the Mediamaster using the buttons on the remote control. mute Press once to turn the sound off/on (mute/unmute). Press and hold for a few seconds to switch the Mediamaster into standby mode. In addition, press this button to switch the Mediamaster on.
Connecting the Mediamaster Front and Rear panel antenna cable for connection of the antenna cable Slot to the cable TV antenna socket Reset button for an Irdeto smart card TV SCART socket * * for connection to the TV SCART DC in TV/VCR Digital audio...
In this section, you will see some of the most common ways to connect your equipment. If you have problems with your connections and need help, contact your retailer or Nokia Support Connecting to the TV with SCART • Connect an antenna cable from the cable TV antenna socket in the wall to the antenna cable input on the Mediamaster.
Connecting the Mediamaster Connecting a Video recorder with SCART • Connect an antenna cable from the cable TV antenna socket in the wall to the antenna cable input on the Mediamaster. • Connect a SCART cable between the main SCART socket on the TV and the TV SCART socket on the Video.
Connecting the Mediamaster & First-time installation About Smart card The Mediamaster is equipped with a built-in decoder for the Irdeto encryption system. Insert a valid smart card fully into the slot on the back of the Mediamaster. The gold chip must face downwards and inwards. Connecting a Hi-fi system It is possible to connect a TOS link cable from the Digital audio out- put on the Mediamaster to a Hi-fi system that is equipped with the...
First-time installation Language Select the desired menu language using the cursor up/down but- ton. This will now become the main language for audio and subtitling. When you now press ok again to confirm your choice of language, you simultaneously start the searching for TV/Radio channels. Channel search Enter the valid values for the local network where your Media- master is connected.
Watching TV & listening to the radio General information You can watch digital TV and listen to digital radio with this Mediamaster. • If no TV channel is automatically shown after you have finished the installation procedure, press any of the number buttons, or step up and down with cursor up/down to select a channel.
Watching TV & listening to the radio Temporary settings By pressing opt, a menu appears that allows you to configure tem- porary settings for the channel you are currently watching. If you leave the channel and return to it later, your temporary settings will be deleted.
Watching TV & listening to the radio External equipment With the 0 (zero) button, you can toggle between externally con- nected equipment, e.g., a VCR (the VCR must be switched on.) This function may not be available on all TV and video models. Sorting channels You can select how the channels shall be sorted in the All TV and All radio folders.
Watching TV & listening to the radio Teletext Pressing txt will open a teletext page, if teletext is transmitted for that channel. Select teletext pages using the number buttons on the remote control (Fig. 1). You can also quickly move to the different page options shown on any page by pressing cursor left/right.
Watching TV & listening to the radio Folder functions The “All TV” folder can contain hundreds of channels. Create a new favourite folder, e.g. “Sports” or “Movies”, in which you can put the bookmarks of the channels you most often watch. That way you can make channel handling more convenient.
Watching TV & listening to the radio • Open Navi Bars. • Select the channel bookmark in the All TV/All Radio folder you want to copy. • Press opt to open the Options menu and step down to Book- mark functions. •...
Navi Bars Navigating with Navi Bars Navi Bars are used for selecting TV/Radio channels and to enter Navi Bars menus in which you can perform different settings. Bookmark Bookmark 1. Display Navi Bars by pressing the navi or ok button; to hide them, name press the back button.
Navi Bars The Settings folder Each of the bookmarks in the Settings folder contains menus from where you can change the settings of the Mediamaster. For some of the menus, you will be asked to enter your access code. The access code is set to 1234 at the factory. The settings folders can not be deleted.
Navi Bars The TV folder TV screen format Select your TV screen format. The 4:3 format is standard for most TV screens. Select 16:9 for widescreen TV. Press opt to get a TV programme in the background from which you can instantly watch the result of your choice. Position of the RGB output Adjust the horizontal position of the menus with the buttons.
1234. NOTE: do not forget your access code as without it, you will not have access to any of the functions that require the code. If you should forget it, please contact Nokia Support for help. GB 19...
Navi Bars Maintenance folder System Information When you enter the Maintenance folder, you will find general information about which hardware and software version your Mediamaster is running on. Reinstall Only use this option if you have to start the complete installation procedure from scratch.
Navi Bars EPG (Electronic Programme Guide) In the EPG folder (Electronic Programme Guide) you will find infor- mation about the programmes for the current day and for the fol- lowing seven days (provided that this information is included in the channel transmission from the distributor.) You may also select the Type of programme you want information about, e.
Technical specifications Supply voltage for the TV SCART separate Power Supply 110-240V AC, 50-60Hz Video output 75 Ohm From thePower supply to the Audio output 0.5 V >10 Ohm 16 V RGB output Internal RGB Power consumption max RGB bandwidth 5.8 MHz ±3 dB Power consumption in standby...
This Software Agreement (“Agreement”) is between You (either an individual or an entity), the End User, and Nokia Corporation Multimedia, (“Nokia”). The Agreement authorizes You to use the Software specified in Clause 1 below and which is included in this Nokia digital TV receiver. This is an agreement on end-user rights and not an agreement concerning sale.
Nokia is a registered trademark of Nokia Corporation www.nokia.com 00032805.01...
