- Page 1 User’s guide “RWF” series Wall fan heater Replacement component list included This unit complies with the CSA standards For further information or to consult this guide online, please visit our Web site. INSRWF0310...
- Page 2 If needed, refer to a specialist who will be able to calculate these heat losses and optimize the required capacity or consult the “Online heating calculation” section of the Stelpro Design Web site (residential buildings). To heat a large room and increase your comfort, it is recommended to install several units instead of one.
-
Page 3: Specifications
SPECIFICATIONS WALL FAN HEATER MODEL VOLTS 120, 208, 240, 277, 347 V WATTS 500 to 2000 W WEIGHT 6 lb/2.7 kg DEPTH 3 1/4”/82 mm WIDTH 8 11/16”/220 mm HEIGHT 17 1/8”/435 mm TECHNICAL DRAWINGS INSTALLATION N.B. Cut off power supply at circuit breaker/fuse before proceeding to installation. INSRWF0310... -
Page 4: Maintenance
INSTALLATION OF THE BACK BOX IN A NEW BUILDING WARNING: This unit must be installed at least 8” (20 cm) from adjacent walls and the floor. 1. Determine which side of the back box is to be mounted against a stud or ceiling joist. Allow for the thickness of the finished wall when installing the back box. - Page 5 REPLACEMENT COMPONENT LIST N° DESCRIPTION N° DESCRIPTION BOUT-009 WHITE THERMOSTAT BUTTON ELF-RWF028 ELEMENT (KIT) 500/1000 W-120 V BOUT-010 BLACK THERMOSTAT BUTTON ELF-RWF029 ELEMENT (KIT) 750/1500 W-120 V BOUT-011 ALMOND THERMOSTAT BUTTON ELF-RWF030 ELEMENT (KIT) 500/1000 W-208 V SB-005 WHITE PLUG 5/8’’ ELF-RWF031 ELEMENT (KIT) 750/1500 W-208 V ELF-RWF001...
-
Page 6: Limited Warranty
Stelpro reserves the right to examine or to ask one of its representatives to examine the product itself or any part of it before honoring the warranty. Stelpro reserves the right to replace the entire unit, refund its purchase price or repair a defective part.
