GB
The Motivation.
ELECTRIC WHEELCHAIR
POWER TOMMY
Model 1.440
OPERATING MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Tommy 1.440 and is the answer not in the manual?

Questions and answers

Related Manuals for Meyra Power Tommy 1.440

Summary of Contents for Meyra Power Tommy 1.440

  • Page 1 The Motivation. ELECTRIC WHEELCHAIR POWER TOMMY Model 1.440 OPERATING MANUAL...

  • Page 2: Table Of Contents

    Table of contents Introduction ....................6 Acceptance ....................6 Assembly ....................7 Specifications/ utilisation ................ 7 Statutory regulations ................8 Legal requirements for Germany ..............8 Electric wheelchairs with a top speed of 6 km/h ........8 CE regulations ....................8 Overview ....................
  • Page 3 Legrests ....................21 Calf belt ....................21 Folding up the foot plates ..............22 Turning the legrests to the side ............... 23 Removing the legrests ................24 Attaching the legrests ................24 Adjusting the length of the legrests ............25 Continuous legrest, code 54 .................
  • Page 4 Drive-/push mode ................... 38 Selecting the push mode ................. 39 Selecting the motor mode ............... 39 Folding/Unfolding ................... 40 Folding the wheelchair ................40 Unfolding the wheelchair ................ 41 Loading and transportation ..............42 Safety informations ................. 42 Transport in vehicles ................42 Loading .....................
  • Page 5 Fuses ......................55 Replacing the fuses .................. 55 Fuse ......................55 Wheel change ..................56 Detaching the drive wheels ..............56 Changing the tyres ................... 56 Dismantling the steering wheels ............. 57 Changing the tyres ................... 57 Maintenance instructions ..............58 Fault correction ..................

  • Page 6: Introduction

    INTRODUCTION ACCEPTANCE The model 1.440, fulfills the wish for All MEYRA products are checked for mobility and more independence by faults in the factory and packed in spe- way of a new styling of the proven cial boxes. MEYRA technology. Make use of the...

  • Page 7: Assembly

    ASSEMBLY SPECIFICATIONS/ UTILI- SATION The specialist workshop delivers your wheelchair to you in an operative sta- The wheelchair Power Tommy, mo- te and adapted to your requirements. del 1.440 was developed for children about 6 to 15 years of age. It is only If adjustments become necessary due permitted for indoor use on hard sur- to growth or changes to the clinical...

  • Page 8: Statutory Regulations

    STATUTORY REGULATI- CE REGULATIONS Note: The technology of this electric Please comply with the legal require- wheelchair complies with the re- ments of the country in which the quirements of the EEC 93/42 direc- wheelchair is used. tive on electromagnetic compati- bility.

  • Page 9: Overview

    OVERVIEW The overview (fig. 1 and 2) shows the important components and control de- vices of the wheelchair. Backrest Operating module Side part with armrest Joystick Seat belt Driving wheel Leg support Support wheel Calf belt Battery holder with battery Footrest Push handle Steering wheel...

  • Page 10: Driving

    DRIVING Drive especially carefully during your first journey! Bearing this in mind, set the pre-se- lectable final speed to the lowest set- ting. Attention: Children may not use the wheelchair without supervision or without an attendant. • Do not touch the I/O button while Speeds up to a maximum of 6 km/ driving.

  • Page 11: Braking The Wheelchair

    First driving exercises The drive can cause malfunctions with devices that are not normati- A low maximum speed must be pre- selected on the control unit for the initial driving practice. Make yourself Electromagnetic fields created by familiar with the driving behaviour of equipment which emits radiation the electric wheelchair in small steps.

  • Page 12: Safety Informations

    Safety informations • Only use the drive when the sup- port castors that belong to Attention: wheelchair are mounted. Before you make your first drive, read and observe the contents of • Before starting to drive adjust to this operating manual and the lowest final speed on the ope- rating module so that a slow and –...

  • Page 13: Functional Checks

    • Functional checks Never expose electric wheelchair to extreme weather The functions and safety of the elec- conditions. tric wheelchair must be checked be- fore the start of each journey. • Do not throw or drop parts belon- ging to the wheelchair! Attention: Observe the brochure <...

  • Page 14: Brakes

    BRAKES Braking the wheelchair Attention: Attention: For this reason, ensure that you Have the brakes repaired immedi- brake the wheelchair in good time ately by a specialist dealer if they when you encounter other people work one-sided or if the braking or obstacles.

  • Page 15: Locking The Brake

    Locking the brake Push the brake release lever forward as far as it will go (fig. 4). Attention: It is impossible to push the wheelchair when in drive mode. • The brake performance reduces with the brake pads are worn. If the wheelchair demonstrates an uneven or impaired braking effect, take it immediately to your specialist...

  • Page 16: Preparing The Wheelchair For Operation

    PREPARING THE WHEELCHAIR FOR OPE- RATION Follow the instructions below in the stated order. Attention: The functions and safety of the electric wheelchair must be che- cked before the start of each jour- ney. Charge the batteries via the opera- ting module before the first jour- ney.

  • Page 17: Check Battery Plug Connection

    Check battery plug connection The plugged connection of the batte- ry power supply (fig. 9/ ) is located at the battery lid underneath the cross brace. Positioning the operating mo- dule The position of the operating module (fig. 10) is to be adjusted so that you are capable of comfortably and safely steering your wheelchair.

  • Page 18: Switching The Operating Module On

    Switching the operating modu- le on – Press the ON/OFF key (fig. 12/ on the keypad. Only actuate the joystick (fig. 13/ ) after the self-test of the elec- tronics has been completed! – If necessary the key function has to be switched off first.

  • Page 19: Operating Module

    OPERATING MODULE Function description You will find a detailed description of the keys and symbols in the operating manual for < Operating module >. Position of the operating modu- The position of the operating module can be adjusted to suit the individual size of the user.

  • Page 20: Height Adjustment Of The Operating Module

    Height adjustment of the opera- ting module In order to adjust the height of the operating module, the operating mo- dule has to be removed together with the side element. For this observe chapter < Remo- ving the side element >. –...

  • Page 21: Legrests

    LEGRESTS Various legrest models for the wheelchair are available. The foot pla- tes can be folded up. Attention: Do not use the legrests to lift or carry the wheelchair. • Lift the feet, respectively place them on the foot plates before each movement of the wheelchair.

  • Page 22: Folding Up The Foot Plates

    Folding up the foot plates For easy transfer into and out of the wheelchair as well as more foot space the footplates can be folded up (fig. 19). – Switch the wheelchair off and shift the brake release lever into the dri- ve position.

  • Page 23: Turning The Legrests To The Side

    Turning the legrests to the side For easy transfer into and out of the wheelchair as well as a reduced wheelchair length (important for transport) the legrest can be swivelled outward (fig. 20). – Switch the wheelchair off and shift the brake release lever into the dri- ve position.

  • Page 24: Removing The Legrests

    Removing the legrests For easy transfer into and out of the wheelchair as well as a reduced wheelchair length (important for transport) the legrest can be removed (fig. 22). – Switch the wheelchair off and shift the brake release lever into the dri- ve position.

  • Page 25: Adjusting The Length Of The Legrests

    Adjusting the length of the legrests The legrests can be adjusted via a te- lescopic tube. Tools: 1x hexagonal stud wrench (WW* 4) – Switch the wheelchair off and shift the brake release lever into the dri- ve position. – This prevents the wheelchair from rolling away acci- dentally.

  • Page 26: Continuous Legrest, Code 54

    CONTINUOUS LEGREST, CODE 54 The footboard of the continuous leg- rest (fig. 26) can be folded up to the side. Folding up the foot board For an unobstructed foot area, fold up the left side of the foot board to the right as far as it will go, (fig.

  • Page 27: Depth Adjustment Of The Footboard

    Depth adjustment of the foot- board The depth adjustment of the foot- board is done by repositioning the removable distancer pieces (fig. 30/ – Lift up the footboard slightly on the left side (fig. 30). – Reposition the desired amount of distancer pieces on the left side (fig.

  • Page 28: Armrests

    ARMRESTS For easy transfer into and out of the wheelchair the side elements can be folded up or removed. Attention: Do not lift the wheelchair using the side elements. • The wheelchair should only be used with the armrests assembled! Folding up the side element –...

  • Page 29: Removing The Side Element

    Removing the side element After folding up the side element it can be removed. – Remove the armrest in an upwards direction (fig. 34). In doing so the side element is pulled out of the guide tube (fig. 35/ Attention: Removed armrests must be careful- ly replaced before the wheelchair is used again!

  • Page 30: Armrests

    ARMRESTS The armrests can be adjusted in height to suit the needs of the user. Attention: Do not use the armrests to lift or carry the wheelchair. • Do not drive without the armrests! Armrest height adjustment Tools: 1x hexagonal stud wrench WW* 4 Attention: 1 x open-end or ring spanner WW* 10 Before loosening the screw (fig.

  • Page 31: Backrest

    BACKREST The tension of the backrest is adjus- table. – Pull the back cover off and fold it to the front (fig. 38). – Open the Velcro fastener of the belt that you wish to adjust and close it again after adjustment. Attention: The overlapping of the Velcro fas- tener has to be at least 10 cm!

  • Page 32: Push Handles

    PUSH HANDLES The height adjustable push handles code 502 (fig. 39/ ) are attached to the backrest with a clamping jig each (fig. 40/ / ) and can be adjusted to the requirements of the attendant. The push handles are about 30 cm step- lessly height adjustable, turnable in steps of 30°...

  • Page 33: Removing The Push Handles

    Removing the push handles – Loosen the clamping screws with the clamping levers (fig. 40/ ) so far that the respective push handle can be pulled upward. – To pull out the push handles press down the respective spring button (fig.

  • Page 34: Support Castors

    SUPPORT CASTORS The support castors (fig. 42/ ) incre- ase the stability against tipping over to the rear when crossing an obstacle or driving on a rising gradient. Attention: Support castors do not provide suf- ficient protection against tipping over in certain situations. Therefore, do not: Leaning the upper body far back.

  • Page 35: Options

    OPTIONS Options are not a part of the standard scope of supply. Note: Options from other companies can cause malfunctions. LAP BELT The lap belt is used for securing a per- son sitting in the wheelchair. – Additional stabilization of the sit- ting position.

  • Page 36: Strapping On The Lap Belt With Lock

    Strapping on the lap belt with lock Pull both belt halves to the front and slide the catch halves together so that they latch together (fig. 43). Then carry out a pull test. You open the lap seatbelt by pressing in the red unlocking button (fig.

  • Page 37: Headrest

    HEADREST The headrest (fig. 44) is swivel proof, height adjustable and removable. Adjustment of the headrest The headrest can be detached or ad- justed in height after the clamping lever (fig. 45/ ) has been slackened. Slacken the clamping screws (fig. 45/ ) and position the headrest at the desired height.

  • Page 38: Drive-/Push Mode

    DRIVE-/PUSH MODE The lever (fig. 46/ ) for switching the drive motors between the drive mode and push mode is located on the right side of the wheelchair (optional: le- ver on the left side). Attention: Push the wheelchair only for ma- noeuvring or in emergency cases but never on gradients.

  • Page 39: Selecting The Push Mode

    Selecting the push mode 1. Switch off the operating module because the pushing will otherwi- se be made difficult by the electric system. 2. Pull the locking sleeve (fig. 47/ up and then push the selection le- ver to the rear (fig. 48). The wheelchair can now be pushed.

  • Page 40: Folding/Unfolding

    FOLDING/UNFOLDING The electronic wheelchair is also col- lapsible for car transportation (fig. 49). Folding the wheelchair – Switch off the wheelchair. – Do this by pressing the ON/OFF key on the operating module. The battery con- trol display goes off. –...

  • Page 41: Unfolding The Wheelchair

    Unfolding the wheelchair – Tilt wheelchair to the side towards you. – The outside driving wheel must not have any contact with the ground. – Press the inside seat tube down. – The seat tubes must be placed in the appropriate receptacles, (fig. 53).

  • Page 42: Loading And Transportation

    LOADING AND TRANS- PORTATION Safety informations For the transport in vehicles, you must leave the wheelchair and sit in a sui- table seat in the vehicle. – The wheelchair is not designed to with- stand the forces which are generated in accidents, which exposes the user to considerable risks.

  • Page 43: Transport Security

    Transport security Carry out the following steps when the wheelchair is located in the transport vehicle: – Switch off the wheelchair. – Put the operating module in a safe place or replace it on the wheelchair. – Stow all disassembled wheelchair parts in a secure and protected way.

  • Page 44: Safety Informations

    Safety informations Note: Suitable fixing points can usually Loose object are to be stored secu- be found in the car and in the ve- rely. hicle operating manual. Before transporting the wheelchair, ask your car dealer how to secure it without risk to the existing fix- tures or other safety fittings! Attention: Make sure that the operating mo-...

  • Page 45: Ramps And Lifting Equipment

    RAMPS AND LIFTING EQUIPMENT When the wheelchair is loaded with the help of ramps or lifting platforms, the following safety information are to be observed: The brochure < Safety informations – electronic wheelchairs > The operating manual for the trans- port vehicle.

  • Page 46: Special Safety Informations

    Special safety informations Only approved ramps or lifting equipments may be used. For safety reasons, the wheelchair must be unloaded (without bagga- Attention: ge and without user) during its loa- The loading capacity per ramp or ding into a car or when a split ramp lifting equipment must be for the is used.

  • Page 47: Transport In Handicapped Transport Automobile

    TRANSPORT IN HANDICAP- Note: PED TRANSPORT AUTOMO- The headrest on the wheelchair ser- BILE ves as a support for the posture of the head, not as a transport securi- Note: ty. Therefore a handicapped trans- For transport in vehicles we recom- port vehicle-firm headrest is neces- mend to leave the wheelchair and sary!

  • Page 48: Safety Informations

    Safety informations When transporting a person, make sure that there are no objects jam- med underneath the straps! – Thus you avoid painful pressure points As far as possible use a vehicle–in- stalled seat during transportation. Only transport the wheelchair in driving direction.

  • Page 49: Service

    SERVICE Plastic parts The plastic panels and parts are made MAINTENANCE of high-quality plastic. Take care of these by means of standard plastics Like any other technical product, your cleaning agents. Always observe the wheelchair also requires maintenance. specific product information. The following maintenance instruc- tions describe in table form the work Finish...

  • Page 50: Customer Service

    CUSTOMER SERVICE In case you have any questions or need help please contact your specialist dea- ler who can assume counselling, ser- vice and repairs. SPARE PARTS Spare parts can only be ordered from authorised dealers. Use only original spare parts for repairs! In order to ensure the correct delivery of a spare part, always quote the cor- DISPOSAL...

  • Page 51: Batteries

    BATTERIES Charging before long periods of non-use MAINTENANCE-FREE BAT- You should fully charge the batteries TERIES of the wheelchair before a long peri- od of non-use. – This lengthens the Only maintenance free batteries with service life of the batteries. Pull out bound electrolytes, such as gel-batte- the main fuse after the charging and ries are to be used.

  • Page 52: Charging Procedure

    Charging procedure Attention: Do not recharge the batteries in a damp room or enclosed space. – The charging process can produce toxic fumes. Ensure that the room is well-ventilated! • Avoid naked flames and sparks in the vicinity of the batteries. – Risk of explosion! •...

  • Page 53: Replacing The Batteries

    Replacing the batteries Batteries should be replaced (fig. 60) by your specialist workshop only be- cause it is aware of the associated risks. Batteries can explode if they come into contact with sparks, e.g. due to a short circuit of the battery terminals. –...
  • Page 54 – Lift if the battery lid. – Dismantle the battery terminal clips (fig. 64/ – Remove batteries. The fitting is done analogue in reverse order. For this you have to observe the arrangement of the pole clamps. Note: Only use batteries supplied by us or those offered as replacement.

  • Page 55: Fuses

    FUSES Replacing the fuses Before replacing fuses, park the wheelchair on a level surface and move the selection lever to the drive mode position to prevent the wheelchair from moving. Switch off the opera- ting module. Always replace fuses with one of the same type! New fuses can be obtained at petrol stations.

  • Page 56: Wheel Change

    WHEEL CHANGE A wheel/tyre change requires techni- cal knowledge. You should therefore have this work carried out by an spe- cialist workshop. Sitting in the wheelchair during a wheel change is not permitted. The wheelchair must stand on a level and firm surface. Be- fore starting the disassembly work, support the frame to prevent the wheelchair from tipping over and se-...

  • Page 57: Dismantling The Steering Wheels

    Dismantling the steering wheels Tools: Hexagonal stud wrench WW* 5 Before replacement or repair the stee- ring wheel axle is to be (fig. 67/ disassembled. Note: Take note of the arrangement of all sleeves and washers used. The valve points outwards. Changing the tyres Fully de-inflate the tyres for a tyre change.

  • Page 58: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS WHEN WHAT Remark Before starting out Check Carry out test yourself or with a helper. – Immaculate functio- ning of the brake Brochure < Safety equipment: informations – elec- tronic wheelchairs >, Switch the brake Observe the section release lever to drive entitled <...
  • Page 59 WHEN WHAT Remark Every 2 weeks Check Carry out visual check yourself. (depending on dis- – Tread pattern mini- tance covered) mal depth 1 mm. With worn down or damaged tyres call in an specialist workshop for maintenance. Visual check Do it yourself or with the aid of a helper.
  • Page 60 WHEN WHAT Remark Every 6 months Check Do it yourself or with (depending on fre- the aid of a helper. – Cleanness. quency of use) Observe section en- – General condition. titled < Care > and < – Secure screw con- Maintenance >! nections.

  • Page 61: Fault Correction

    FAULT CORRECTION Fault indications on the LED display If treated properly, your wheelchair In the event of a fault, an error indi- will not malfunction. In order to pre- cation will appear on the LED display. serve your pleasure in driving the fol- The error codes help the specialist lowing table with a list of possible workshop to quickly identify the cau-...
  • Page 62 Fault Cause Remedy The display does not – The main fuse for – Change the blade- light up after the the battery circuit is type electric fuse wheelchair has been defective (blade-type or insert it proper- switched on. fuse) or not inserted deep enough.

  • Page 63: Technical Data

    TECHNICAL DATA – frequent acceleration and braking (e.g. in city traffic) Kilometric performance – aged, sulphated batteries, Kilometric performance depends to a – frequently necessary steering ma- large extent on the following factors: noeuvres, – reduced driving speed (especially at –...

  • Page 64: Fuses

    FUSES Under the seat Battery fuse (fig. 69/ ): ..........60 A at 28 Ah ..................40 A at 15Ah TECHNICAL DATA POWER TOMMY, MODEL 1.440 All data within the following table relates to the standard version of the stated model.
  • Page 65 Dimensions: Length (incl. footplates): ................86 cm Length (without footplates): ..............68 cm Width (seat-width dependent): ......46 cm (SB 28) to 54 cm (SB 36) Width (folded): ..................... 35 cm Height (with 28 cm back height): ..............74 cm Seat height without seat cushion: ..............
  • Page 66 Batteries: Sealed drive batteries (gel): ............12 V 15 Ah (20 h) Sealed drive batteries (gel): ............12 V 28 Ah (20 h) Max. battery dimensions (LxWxH): ........278 x 175 x 190 mm Permissible battery tilting angle: ..............55° Range (see Kilometric performance): Drive batteries (gel) 15 Ah (20h) at 6 km/h: ........

  • Page 67: Meaning Of The Labels On The Wheelchair

    MEANING OF THE LABELS ON THE WHEELCHAIR Attention! Read the operating manuals and other provided documentation. Do not lift the wheelchair at the arm- rests or legrests. Detachable parts are not suitable for carrying. Drive mode Switching to push mode by moving the selection lever from the left to the right.

  • Page 68: Inspection Certificate

    INSPECTION CERTIFICATE Vehicle data: Model: Delivery note no.: Vehicle identification No. Recommended safety inspection (at least every 12 months) Pre-delivery inspection Stamp of specialist dealer: Stamp of specialist dealer: Signature: Signature: Place, date: Place, date: Next safety inspection in 12 months Next safety inspection in 12 months Date: Date:...
  • Page 69 Recommended safety inspection Recommended safety inspection (at least every 12 months) (at least every 12 months) Stamp of specialist dealer: Stamp of specialist dealer: Signature: Signature: Place, date: Place, date: Next safety inspection in 12 months Next safety inspection in 12 months Date: Date: Recommended safety inspection...

  • Page 70: Guarantee

    GUARANTEE Damage to surfaces, tyres, damage due to screws and washers which have worked loose or worn out attachment We accept a guaranty for this product holes due to frequent assembly and according to the legal regulations. dismantling are not covered by this Apart from this we warrant: guarantee.

  • Page 71: Guarantee Coupon

    GUARANTEE COUPON Fill in the details! If necessary, copy and return. Guarantee Model designation: Delivery note no.: Vehicle ID No. (Fz-I-Nr.) (view type pla- Date of delivery: te): Stamp of the authorized dealer:...
  • Page 72 Stamp of the authorized dealer: The Motivation. MEYRA • Wilhelm Meyer GmbH & Co. KG Company address: Meyra-Ring 2 D-32689 Kalletal-Kalldorf Telephone +49 (0)5733 922 - 311 Fax +49 (0)5733 922 - 143 Email: info@meyra.de Internet: http://www.meyra.de Postal address: P.O. Box 1703 • D-32591 Vlotho...
