Operating Manual
JP-SERIES
OPERATION MANUAL
COLD WATER ELECTRIC
PRESSURE WASHER
CAUTION
RISK OF INJURY!
READ MANUAL BEFORE OPERATING!
This manual is an important part of the pressure washer
and must remain with this unit!
©Copyright 2005, Mi-T-M Corporation
Form #37-0595-E/S-0909
Mi-T-M JP-Electric Operator's Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mi-T-M JP-SERIES
Summary of Contents for Mi-T-M JP-SERIES
-
Page 1: Pressure Washer
OPERATION MANUAL COLD WATER ELECTRIC PRESSURE WASHER CAUTION RISK OF INJURY! READ MANUAL BEFORE OPERATING! This manual is an important part of the pressure washer and must remain with this unit! ©Copyright 2005, Mi-T-M Corporation Form #37-0595-E/S-0909 Mi-T-M JP-Electric Operator's Manual... -
Page 2: Table Of Contents
CLEANING WITH DETERGENTS ....................7 SHUTDOWN ..........................7 STORAGE & MAINTENANCE ....................... 18-19 SPECIFIC MAINTENANCE ......................8 WINTERIZING ......................... 8-9 START UP AFTER EXTENDED STORAGE ................. 9 TROUbLESHOOTING ........................20-21 ACCESSORIES ..........................22 STATEMENT OF wARRANTY ......................23 Mi-T-M JP-Electric Operator's Manual... -
Page 3: Introduction
The contents of this manual are based on the latest product information available at reserves the right to make changes in price, color, materials, equipment, specifications ® the time of publication. Mi-T-M or models at any time without notice. ! IMPORTANT ! These paragraphs are surrounded by a "SAFETY ALERT bOX". -
Page 4: Important Safety Warnings
Allow the pressure washer to cool down. Never assume the pressure washer is safe to work on just because it is not operating. It could restart at any time! Service in a clean, dry, flat area. Mi-T-M JP-Electric Operator's Manual... -
Page 5: Spray Precautions
Serious injury or death may occur from inhaling dangerous vapors. . Follow all safety instructions provided with the materials you are spraying. Use of a respirator may be required when working with some materials. Do not use this pressure washer to dispense hazardous detergents. Mi-T-M JP-Electric Operator's Manual... -
Page 6: Miscellaneous Safety Precautions
1. Always hold on firmly to the gun/lance assembly when starting and operating the unit. Failure to do so can cause the lance to fall and whip dangerously. 2. Know how to stop the pressure washer and bleed pressures quickly. Be thoroughly familiar with controls. Mi-T-M JP-Electric Operator's Manual... -
Page 7: Detergent Cleaning Precautions
Follow all appropriate instructions regarding preparation, use, safety and transportation. 3. Protective equipment such as rubber suits, gloves and respirators are advisable, especially when using cleaning detergents. 4. Keep all detergents out of the reach of children. ! SAVE THESE INSTRUCTIONS ! Mi-T-M JP-Electric Operator's Manual... -
Page 8: Features
Decal-Warning: Risk of Injection Thermal Relief Valve Quick Connect Nozzle Detergent Strainer On/Off Switch Detergent Hose 20A. Decal-Warning: Risk of Electrocution 20B. Decal-Warning: Caution Adjustment Knob Water Inlet 20C. Decal-Warning: Risk of Injection/Explosion Water Inlet Strainer Adjustable Detergent Injector Mi-T-M JP-Electric Operator's Manual... -
Page 9: Safety Decals
Never put your hand, fingers or body directly Nunca coloque la mano, los dedos o el cuerpo over the spray nozzle. directamente sobre la boquilla de rocío. 34-1253-030801-ENG. Reference #20C Decal: Warning-Risk of Injection/Explosion (Part # 34-07) Mi-T-M JP-Electric Operator's Manual... -
Page 10: Features
Oil Sight Glass Gun Assembly Pump Decal-Warning: Risk of Injection Thermal Relief Valve Quick Connect Nozzle Detergent Strainer 9A. On Switch 19B. Off Switch Detergent Hose Adjustment Knob Decal-Warning/Caution/Operating Water Inlet Water Inlet Strainer Adjustable Detergent Injector Mi-T-M JP-Electric Operator's Manual... - Page 11 Never put your hand, fingers or body directly Nunca coloque la mano, los dedos o el cuerpo over the spray nozzle. directamente sobre la boquilla de rocío. 34-1253-030801-ENG. Reference # Tag: Warning: Risk of Electrocution (Part # 34-04) Mi-T-M JP-Electric Operator's Manual...
-
Page 12: Installation & Preparation
DO NOT STORE / OPERATE UNIT 4. Before each use, be certain the oil level is in the center of the sight glass. IN A FREEzING ENVIRONMENT. If low, fill with Mi-T-M pump oil (#AW-4085-0016). DO NOT OVERFILL! POwER CORD CONNECTION: DANGER . -
Page 13: Nozzle Review
INSTALLATION & PREPARATION POwER CORD CONNECTION, CONT'D.: 6. EXTENSION CORDS: Mi-T-M DOES NOT RECOMMEND THE USE OF EXTENSION CORDS! If use of an extension cord is unavoidable, it must be plugged into a GFCI found in circuit boxes or protected receptacles. -
Page 14: Nozzle Connection
This can cause cavitation which will result in premature failure of pump packings and valves. Using a screw driver, remove the screen; clean or replace with Mi-T-M #9-000 if necessary. 3. Connect the hoses. a. Connect one end of the water supply hose to the water inlet of the unit. -
Page 15: Thermal Relief Valve
DO NOT ATTEMPT TO OPERATE THIS PRESSURE wASHER UNTIL YOU HAVE READ AND UNDERSTOOD ALL SAFETY PRECAUTIONS AND INSTRUCTIONS LISTED IN THIS MANUAL. INCORRECT OPERATION OF THIS UNIT CAN CAUSE SERIOUS INJURY!! DO NOT ALTER OR MODIFY THIS EQUIPMENT IN ANY MANNER! Mi-T-M JP-Electric Operator's Manual... -
Page 16: Operating Instructions
PLACE HAND OR FINGERS IN the unit. If you require service, contact Mi-T-M Customer Service. FRONT OF NOzzLE! b. Inspect high pressure hose for kinking cuts and leaks. If a cut or leak is... -
Page 17: Cleaning With Detergents
4. Once pressure is relieved, disconnect the nozzle. 5. Disconnect the unit from the power source. 6. Disconnect and drain gun, wand and hoses. 7. Wipe unit clean and store with gun, wand and hoses in a safe area. Mi-T-M JP-Electric Operator's Manual... -
Page 18: Storage & Maintenance
3 months or 250 hour intervals. If oil appears dirty or milky, changes may be required at a greater frequency. Use Mi-T-M pump oil #AW-4085-0016 and fill only to the center of the oil sight glass. DO NOT OVERFILL! NOZZLES: Water flow through the spray nozzle will erode the orifice, making it larger, resulting in a pressure loss. - Page 19 2. Prior to restarting the unit, thaw out any possible ice from the wand, gun, hose and unit. 3. After following all "PREPARATION" instructions, start the unit momentarily and immediately turn "OFF" to ensure all parts are lubricated before operation. Mi-T-M JP-Electric Operator's Manual...
-
Page 20: Troubleshooting
Insert high pressure nozzle. Obstructed or worn orifice. Remove and clean, or replace. Damaged or obstructed valve assembly Remove, clean or replace. on pump. Pump packings worn. Replace packings. Unloader valve not operating correctly. Repair or replace. Mi-T-M JP-Electric Operator's Manual... - Page 21 Water flows back into detergent Ball & Spring in Venturi reversed, Remove, clean or replace. container. missing or corroded. Water flows from the nozzle when the Gun is malfunctioning. Repair or replace. trigger gun is in the "OFF" position. Mi-T-M JP-Electric Operator's Manual...
-
Page 22: Accessories
Mi-T-M All Purpose Cleaner, Paint Surface Prep, House and Deck Wash, and Heavy Duty Degreaser are specially formulated detergents for use with all Mi-T-M pressure washers and are packaged in one (), five (5), and fifty-five (55) gallon containers. Contact Mi-T-M Customer Service Department at (800) 553-9053 for more information. -
Page 23: Statement Of Warranty
STATEMENT OF wARRANTY Mi-T-M warrants all parts, (except those referred to below), of your new pressure washer to be free from defects in materials and workmanship during the following periods: For Five (5) Years from the date of original purchase:...
