- Page 1 AW220 Owner’s Manual...
-
Page 3: Power Amplifier
Owner’s Manual AW220 Balanced STEREO / MONO Power Amplifier Warning: To avoid risk of fire or electric shock, do not expose this appliance to rain or moisture. Verify line voltage before use. Do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personnel. - Page 4 Welcome to the world of Electrocompaniet We sincerely thank you for selecting an amplifier from Electrocompaniet. We hope you will enjoy years of listening pleasure and true High End musical performance from your audio system. Kindly read this owners manual to familiarize yourself with the set before operation.
- Page 5 Unpacking the AW220 Immediately upon receipt of the AW220, inspect the carton for possible dam- age during shipment. The carton and packaging have been designed to prov- ide the safest possible protection for the transport of your amplifier. Unpack the unit carefully. Save all packaging materials for future shipment.
- Page 6 See page 10 Mono operation: Push the “Stereo / Mono” switch out(LED off). Connect one channel of the preamplifier to the Right input of the AW220. Leave the left input open. Connect the positive speaker terminal to the amplifiers positive right output.
- Page 7 Warning The amplifier will be warm. Due to the high class A operating point used in the Electrocompaniet design, it is normal that the amplifier feels warm. Proper ventilation will be needed, and the amplifier should not be covered in. A good rule is to allow 1-2 inches of air sidewise, and 2-3 inches above the amplifier.
- Page 8 Technical Specification AW 220 The following technical data were measured on randomized test objects and are typical data. All measurements are made with main voltage 120/240 V 50Hz / 60Hz. Main voltage 120 / 240 V. Clipping point of the amplifier is set to a level where total harmonic distortion (THD) is 0.2%.
- Page 9 4.Always ship the unit in its original carton and packaging material to prevent damage in transit. Electrocompaniet will not cover damages incurred in transit. If you require further information concerning the operation of the unit, or if you have any questions related to service, please do not hesitate to contact your dealer or national distributor.
