Summary of Contents for Lionel Early-Era Inspection Vehicle
- Page 1 72-8453-250 2/11 Lionel Lionel Lionel Lionel Lionel Lionel Lionel Early-Era Early-Era Inspection Vehicle Inspection Vehicle Owner’s Manual Owner’s Manual featuring...
- Page 2 Detailed die-cast metal body and frame • Operating headlights The following Lionel marks are used throughout this catalog and are protected under law. All rights reserved. Lionel®, LEGACY™, FasTrack™, TrainMaster®, Odyssey®, RailSounds®, CrewTalk™, TowerCom™, DynaChuff™, StationSounds™, Pullmor®, ElectroCoupler™, Magne-Traction®, CAB® Remote Controller, American Flyer®, Lionel ZW®, ZW®, MagniVision®, TMCC®, Lionelville®, Wireless...
-
Page 3: Table Of Contents
CAB commands for your vehicle Assigning your vehicle a new ID# Reprogramming the Command reverse unit to restore features Transformer operations Running your vehicle with a Lionel transformer Command Reverse Unit switch Maintaining and servicing your vehicle Lubricating your vehicle Servicing your vehicle’s LEDs... -
Page 4: Command Control Operations
Command Control operations The Command Control environment ommand Control is the advanced model railroad control system from Lionel. Command Control gives you the power to operate multiple Command-equipped vehicles on the same track, at the same time. To operate in Command mode, you need a Command Base and a CAB Remote Controller. -
Page 5: Running Your Vehicle In The Command Environment
These settings will be lost when you assign a new engine ID number. Note! HALT Press HALT to shut down all PowerMaster electrical output on your railroad. Stops all Command- equipped Lionel locomotives in operation. only in emergency situations. HALT Note! -
Page 6: Assigning Your Vehicle A New Id
Command Control operations Assigning your vehicle a new ID# s your fleet of Command-equipped Lionel vehicles grows, you’ll want to give your vehicle a more individualized number. Choose from any between 1 and 99. To make things easy, use a portion of your vehicle’s cab number. -
Page 7: Reprogramming The Command Reverse Unit To Restore Features
Command Control operations Reprogramming the Command reverse unit to restore features ue to the inevitable derailments and static, it is possible that your Command reverse unit could someday lose its setup program. The symptom of this condition would be unresponsiveness in Command mode. This can be easily remedied by “reprogramming” your Command reverse unit using the following steps. -
Page 8: Transformer Operations
Move ‘em out! Get your vehicle moving. Press the DIRECTION button on your CAB Remote Controller or Lionel transformer. This sequences the Command reverse unit to the next operating state. Adjust track voltage until your vehicle moves at your desired speed. To increase speed, increase track voltage. -
Page 9: Command Reverse Unit Switch
Transformer operations Command Reverse Unit Switch se the Command Reverse Unit Switch to “lock” your locomotive in a single direction, or neutral, in the Conventional environment when the switch is placed in the PGM position. See Figure 1 below. Also, the switch is used to assign an ID# and reprogram the locomotive in Command operation when the switch is in the PGM position. -
Page 10: Maintaining And Servicing Your Vehicle
Maintaining and servicing your vehicle Lubricating your vehicle elp your Lionel vehicle lead a long and productive life on your railroad by maintaining it properly. We recommend that you purchase a Lionel Lubrication and Maintenance Kit (no. 6-62927), available from your Lionel dealer. Two basic rules to keep in mind: never over-lubricate (a small amount will do), and avoid getting grease or oil on the vehicle’s wheels or your track. -
Page 11: Servicing Your Vehicle's Leds
LED. Should this LED ever need to be replaced, you can obtain a replacement LED (Lionel part no. 6208452300) at www. lionel.com - Customer Services - Replacement Parts, or take your vehicle to a Factory Trained Authorized Service Station. -
Page 12: Limited Warranty/Lionel Service
(or copy) from an Authorized Lionel Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
