- Page 1 71-4262-250 12/07 Lionel Elevated Tank Owner’s Manual...
-
Page 2: Table Of Contents
Powering your Elevated Tank Installing the lamps Connecting the tanks Replacing the lamps Limited Warranty/Lionel Service The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel , TrainMaster , Odyssey... -
Page 3: Powering Your Elevated Tank
Powering your Elevated Tank our Elevated Tank operates best at 12-18 volts (AC). Because the power connections are located on the underside of the base, we recommend that you attach the wires before you attach the walkways. Power the Elevated Tank with your transformer, a separate accessory power supply, or a Lionel Lock-On (available separately, 6-62900). -
Page 4: Installing The Lamps
Installing the lamp s illustrated in Figure 2, plug the two prongs on the bottom of the lamppost into the socket on the platform. Be sure that the prongs line up with the holes. Figure 2. Lamp installation Connecting the tanks se the included walkway to connect two, three, or four Elevated Tanks to model a Tank Town. - Page 5 Connecting the tanks (continued) NOTE: ALL DIMENSIONS ARE APPROXIMATE for 3 for 4 Figure 3. Tank arrangement...
-
Page 6: Connecting The Tanks
Connecting the tanks (continued) o attach the walkway, slide the hooks at the end of the walkway into the openings on the side of the tank platform or another walkway. Refer to Figure 4. Opening in the platform Hook Figure 4. Walkway attachment... -
Page 7: Replacing The Lamps
Replacing the lamps uring the course of normal operation, your lamp may require replacement. Gently unscrew the expired lamp, turning it counter-clockwise. Replace the lamp with Lionel part no. 610-4143-300. Refer to Figure 5. Figure 5. Lamp replacement... -
Page 8: Limited Warranty/Lionel Service
Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.
