Danfoss VLT 6000 Instruction Manual page 20

Binary Outputs from Drive (status)
BACnet
REFERENCE NAME
current_status_#
voltage_status_#
motor_run_status_#
frequency_status_#
control_status_#
reference_status_#
warning_status_#
trip_status_#
coast_status_#
heatsink_temp_#
vlt2800_term_33_#
frequency_low_#
frequency_high_#
current_low_#
current_high_#
feedback_low_#
feedback_high_#
live_zero_error_#
phase_loss_#
drive_therm_overload_#
motor_therm_overload_#
current_limit_#
external_fault_#
(safety interlock)
over_temp_#
earth_fault_#
trip_lock_#
standby_#
jogging_#
hand_mode_#
off_#
local_ref_#
running_at_ref_#
sleep_mode_#
NOTE: # symbol represents drive ID number.
old
The values in are
default values.
SELECTION
0=OK 1=Limit
0=OK 1=Limit
0=Not Running 1=Running
0=Out of Range 1=In
Range
0=Local 1=Remote
0=Not on Ref. 1=On Ref.
0=OK 1= W arning
0=OK 1=Tripped
0=Not Enabled 1=Enabled
0=OK 1=Warning
(for VLT 2800 only)
0=Off 1=On
(for VLT 2800 only)
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Warning
0=OK 1=Alarm
(for VLT 6000 only)
0=OK 1=Alarm
0=OK 1=Alarm
(for VLT 6000 only)
0=OK 1=Trip Lock
0=False 1=True
(for VLT 6000 only)
0=False 1=True
(for VLT 6000 only)
0=Auto 1=Hand
(for VLT 6000 only)
0=False 1=True
(for VLT 6000 only)
0=False 1=True
(for VLT 6000 only)
0=False 1=True
(for VLT 6000 only)
0=False 1=True
(for VLT 6000 only)
Appendix
VLT 6000 VLT 2800
PARA NO. PARA NO.
527 534
527 534
527 534
527 534
527 534
527 534
527 534
527 534
527 534
VLT 2800 540
only
VLT 2800 528
only
531 540
533 540
531 540
531 540
531 540
531 540
531 540
531 540
531 540
531 540
531 540
529 VLT 6000
only
529 538
529 VLT 6000
only
529 538
532 VLT 6000
only
532 VLT 6000
only
532 VLT 6000
only
532 VLT 6000
only
532 VLT 6000
only
532 VLT 6000
only
532 VLT 6000
only
VLT is a registered Danfoss trademark
21
