Chapter 2
Power Supply
The VIA EPIA Mini-ITX Mainboard requires an ATX power supply to be
connected. Before inserting the power supply connector, always make
sure that all components are installed correctly to ensure that no damage
will be caused.
ATX 20-Pin Power Connector
To connect the ATX power supply, make sure the plugs of the power
supply are inserted in the proper orientation and the pins are correctly
aligned. Then, push down the power supply plug firmly into the connector.
2-6
