Connectors Guide - VIA Technologies Mini-ITX User Manual

Component
Fan 1, Fan 2
DIMM1, DIMM2
ATX Power Connector
PS/2 Mouse
PS/2 Keyboard
LPT Connector
RJ-45 Port
COM Port
Line Out
Line In
Mic In
USB 0, USB 1
RCA Video or S/P DIF
S-Video
CRT connector
IDE 1, IDE 2
J3
J7
J5
J6
J8
J9
J12
J10
J13
J2
J1
J4
J11
PCI Slot

Connectors Guide

Function
Fan power connectors
DIMM slot
Connecting ATX power supply
Mouse connector
Keyboard connector
Parallel port connector
Connecting to a LAN
COM port connector
Connecting Headphones/Speakers
Connecting an audio device
Connecting a Micorphone
Connecting to USB devices
Connecting to RCA Video or SPDIF
Connecting to S-Video
Connect to CRT monitor
Connecting IDE devices
Front panel connectors
CD-ROM Line in connector
FIR module connector
CIR module connector
Wake on Modem
USB Port 2 &3 Connector
Video In and PCI Riser connector
Clear CMOS jumper
Host Frequency Select
Auto Reboot Function Setting
CPU Strapping Function Setting
Disk On Chip (DOC) BIOS
RCA Video / S/P DIF
Connecting to expansion cards
1-5
Specifications
Reference
See p. 2-2
See p. 2-4
See p. 2-6
See p. 2-7
See p. 2-7
See p. 2-7
See p. 2-7
See p. 2-8
See p. 2-8
See p. 2-8
See p. 2-8
See p. 2-8
See p. 2-8
See p. 2-8
See p. 2-8
See p. 2-9
See p. 2-10
See p. 2-10
See p. 2-11
See p. 2-11
See p. 2-12
See p. 2-12
See p. 2-13
See p. 2-14
See p. 2-15
See p. 2-16
See p. 2-16
See p. 2-17
See p. 2-17
See p. 2-18
