AN-Mini/MiniVox Lite Owners Manual
AN-Mini
Feel free to call our friendly customer support staff at 1-800-ANCHOR1 Monday thru
Friday between 7:00am and 5:00pm Pacific Standard Time with any questions. We love to
hear from our customers.
Janet Jacobs, President
on behalf of all Anchor employees
CONTENTS
BASIC SYSTEM OPERATION .................................................................................................. 2
OPERATING THE WIRELESS MICROPHONE / TRANSMITTER ..................................................... 4
BATTERY INSTALLATION ...................................................................................................... 5
HAVING TROUBLE WITH YOUR SOUND SYSTEM? ................................................................... 7
AN-MINI TECHNICAL SPECIFICATIONS ................................................................................... 7
A Message from the President
Congratulations on purchasing an Anchor Audio sound system,
the choice of thousands of satisfied customers including the White
House, prestigious universities, school districts nationwide, police
and fire departments, and all branches of the U.S. military. Our
products are made of the finest materials and built with pride in
the U.S.
We've incorporated the latest technology into your sound system
yet kept it simple to use. Just take a few minutes to review this
manual to ensure the maximum enjoyment of your Anchor system.
Or, you can view a demonstration video complete with a trouble
shooting section at www.anchoraudio.com.
MiniVox Lite
(contains AN-Mini speaker
monitor, wired microphone,
and SOFT-30 soft case)
For System Setup & Operation Videos Visit Our Website: www.anchoraudio.com
MADE IN USA
MADE IN USA
SIX YEAR WARRANTY
SIX YEAR WARRANTY
GETTING STARTED
Please check your new unit carefully for any
damage which may have occurred during shipment.
Each Anchor product is carefully inspected at the
factory and packed in specially designed boxes for
safe transport.
Notify the freight carrier immediately of any damage
to the shipping box or product. Repack the unit
in the original box and wait for inspection by the
carrier's claim agent. Notify your dealer of the
pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE
OR REPAIR
For service or repair, please contact the dealer
you purchased your system from or Anchor Audio
Customer Service at 800.262.4671 to obtain a
RA (Return Authorization) number. You may
also complete an online RA request form at
www.anchoraudio.com. All shipments to Anchor
Audio must include a RA number and must be
shipped prepaid. C.O.D. shipments will be refused
and returned at your expense.
IMPORTANT: Save the shipping box & packing materials,
they were specially designed to ship your unit!
100-0174-000/A - 02/11
1
