  • Page 1 OWNER’S MANUAL AN - 1 0 0 0 X + AN - 1 3 0 + AN - 1 3 5 + AN - 3 0...

  • Page 2: Table Of Contents

    Our Technical Support team will help to troubleshoot. If unsuccessful and under warranty, they will issue you a Return Merchandise Authorization (RMA) number. Once you ship your product back to Anchor Audio with the RMA number clearly noted on the box, we will diagnose your unit and repair your unit then ship it back to you.

  • Page 3: Basic System Operation / Back Panel

    AN-1000X+ BASIC SYSTEM OPERATION *BALANCED INPUT JACK & DIP SWITCH Position the speaker to face your audience The balanced XLR input jack allows the AN-1000X+ to be Set volume control on front of speaker to minimum used in a variety of applications. The input can be configured by the user for a Lo-Z microphone or bridging balanced Plug in AC power cord to a wall power outlet line-level inputs (such as used in the pro-audio and broadcast...

  • Page 4: An-130

    • 1/4” PHONE • 3.5 mm 1/4” MIC INPUT AN-130+ Back Panel Silkscreen Artwork 217-0326-000 Rev. C (Reference dwg# 216-0326-000 for dimension & material info) Anchor Audio, Inc. April 5, 2018 AN-130U2+...

  • Page 5: An-135

    LINE IN 1/4” LINE INPUT 3.5 MM LINE INPUT POWER SWITCH POWER CORD AN-135 Back Panel Silkscreen Artwork 217-0340-000 Rev. B (Reference dwg# 216-0340-000 for dimension & material info) 3.5 MM LINE OUTPUT Anchor Audio, Inc. April 5, 2018 AN-135+...

  • Page 6: An-30

    AN-30 BASIC SYSTEM OPERATION 1. Position the speaker to face your audience 2. Insert the AC power cord to the input labeled DC IN and then plug in to a wall power outlet 3. Connect an external audio source using a 3.5 mm (AUX) cable or 1/4“ cable to the Line In. 4.

  • Page 7: Operating The Anchorlink Wireless Microphone/Transmitter

    Applicable in AN-1000X+ and AN-130+ with a built-in dual wireless receiver VOLUME/POWER KNOB PAIRING BUTTON INDICATOR LIGHTS PAIRING THE ANCHORLINK WIRELESS MICROPHONES 1. Turn on Mic Receiver (Volume knob clockwise) then hold Pairing button until green light for Mic 1 flashes, release button. 2.
  • Page 8 Q: Can I use other brand’s wireless mics with the AnchorLink? Q: Do I need to pair my microphone with my Anchor system for A: In order to achieve zero interference, we designed the...

  • Page 9: Wireless Remote Control Operation

    WIRELESS REMOTE CONTROL MUTE Applicable for AN-130RC+ models only. VOLUME DOWN Remote Control Operation Raise volume by pressing the volume up button Lower volume by pressing the volume down button VOLUME UP Mute system by pressing the mute button Stop mute by pressing the mute button again or pressing either volume button NOTE: If the system is not responding be sure the signal is not blocked.

  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS AN-1000X+ AN-130+ AN-135+ AN-30 Rated Power Output (Watts) 50W AC 30W AC 30W AC 30W AC Max SPL @ Rated Power 107 dB @ 1 meter 103 dB @ 1 meter 103 dB @ 1 meter 100 dB @ 1 meter Frequency Response 65 Hz –...

  • Page 11: Troubleshooting

    Poor Wireless Audio Quality • Minimize obstructions between the system and wireless microphone • If wireless range continues to be poor, call Anchor Audio Tech Support • Check battery level, charge battery, or plug in AC cord • Lower system volume Distorted Sound •...

  • Page 12: Important Safety Instructions

    European Union CE Mark European Union CE Mark WARNING The presence of the CE Mark on Anchor Audio equipment means that it To avoid electric shock, connect the instrument to has been designed, tested, and certified as complying with all applicable properly earth-grounded, 3-prong receptacles only.

  • Page 13: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS (CONT.) Read Instructions – All the safety and operation instructions should be read before the 15) Outdoor Antenna Grounding – If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some product is operated.

  • Page 14: Warranty

    ANCHOR AUDIO WARRANTY Anchor Audio products are warranted to be free from defects in materials and workmanship for the period of SIX (6) YEARS from the date of original purchase unless listed below. Warranted for a period of FOUR (4) YEARS: •...
