100-26-0/D, ANX 2/6/01 9:40 AM Page 1

Troubleshooting Guide

Having trouble with the sound system?
Condition
No sound (power LED not lit):
No sound (power LED lights):
Distorted sound:
Excessive hum or noise:
Mic volume too low:
Blows fuse with auxiliary speaker: • shorted speaker cable
ANCHOR Audio, Inc. (310) 784-2300
100-0026-000 / Revision D, 06/97
Possible Solution
• turn POWER switch on
• plug in power cord
• check for blown fuse
• check for output from source
• make sure all cables are completely plugged in
• increase volume control
• check input cable connection
• lower input signal level
• use shielded input cable
• set balanced input to mic-level
AN-1000X
Owner
s Manual
'
E
M
L U
O
V
L E
B
E
T R
S
S
A
B
