AN-130+ Speaker Monitor Owners Manual
your Anchor system. Or, you can view a demonstration video complete with a trouble
shooting section at www.anchoraudio.com.
Feel free to call our friendly customer support staff at 1-800-ANCHOR1 Monday thru
Friday between 7:00am and 5:00pm Pacific Standard Time with any questions. We love
to hear from our customers.
Janet Jacobs, President
on behalf of all Anchor employees
CONTENTS
GETTING STARTED .................................................................................................................. 1
BASIC SYSTEM OPERATION ..................................................................................................... 2
WIRELESS REMOTE CONTROL ................................................................................................. 3
OPERATING THE BUILT-IN UHF WIRELESS RECEIVER ................................................................. 4
OPERATING WIRELESS RECEIVER/MICROPHONE ....................................................................... 5
HAVING TROUBLE WITH YOU SOUND SYSTEM? ......................................................................... 6
AN-130+ TECHNICAL SPECIFICATIONS .................................................................................... 6
A Message from the President
Congratulations on purchasing an Anchor
Audio sound system, the choice of thousands
of satisfied customers including the White
House, prestigious universities, school districts
nationwide, police and fire departments, and all
branches of the U.S. military. Our products are
made of the finest materials and built with pride
in the U.S.
We've incorporated the latest technology into
your sound system yet kept it simple to use. Just take
a few minutes to review this manual to ensure the maximum enjoyment of
MADE IN USA
MADE IN USA
SIX YEAR WARRANTY
SIX YEAR WARRANTY

GETTING STARTED

Please check your new unit carefully for any
damage which may have occurred during shipment.
Each Anchor product is carefully inspected at the
factory and packed in specially designed boxes for
safe transport.
Notify the freight carrier immediately of any damage
to the shipping box or product. Repack the unit
in the original box and wait for inspection by the
carrier's claim agent. Notify your dealer of the
pending freight claim.
NOTE: All damage claims must be made with freight carrier!
RETURNING SYSTEMS FOR SERVICE
OR REPAIR
For service or repair, please contact the dealer
you purchased your system from or Anchor Audio
Customer Service at 800.262.4671 to obtain a
RA (Return Authorization) number. You may
also complete an online RA request form at
www.anchoraudio.com. All shipments to Anchor
Audio must include a RA number and must be
shipped prepaid. C.O.D. shipments will be refused
and returned at your expense.
IMPORTANT: Save the shipping box & packing materials,
they were specially designed to ship your unit!
WARRANTY REGISTRATION
Visit our website at www.anchoraudio.com and
select "Warranty Registration." Complete the online
form to activate the six-year limited warranty on
your AN-130++ speaker monitor and two-year
limited warranty for the microphones.
100-0184-000 rev. A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AN-130+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anchor AN-130+

Summary of Contents for Anchor AN-130+

  • Page 1: Table Of Contents

    Anchor system. Or, you can view a demonstration video complete with a trouble NOTE: All damage claims must be made with freight carrier! shooting section at www.anchoraudio.com.

  • Page 2: Basic System Operation

    AN-130+ Speaker Monitor Owners Manual MADE IN USA BASIC SYSTEM OPERATION SIX YEAR WARRANTY The AN-130++ monitor is used to amplify the signal from a microphone, electronic musical instrument or BACK PANEL OF AN-130U1+ line-level sources (MP3, cassette, CD, VCR, etc). You’ll need a connection cable and an AC outlet.

  • Page 3: Wireless Remote Control

    AN-130+ Speaker Monitor Owners Manual MADE IN USA SIX YEAR WARRANTY WIRELESS REMOTE CONTROL REMOTE OPERATION (AN-130RC+ ONLY) Point the red Mute button towards the front of the AN-130RC+, aiming the remote at VOLUME MUTE the red window located near the Volume and DOWN Tone controls.

  • Page 4: Operating The Built-In Uhf Wireless Receiver

    DIVERSITY WIRELESS BY ANCHOR AUDIO Anchor Audio UHF wireless is a 16 channel, diversity wireless system that receives signals with two independent antennae. With diversity wireless the receiver processes the stronger signal, effectively minimizing dropouts and interference from other transmitting sources. The antennae are mounted internally so there are no obstructions or risk of damage.

  • Page 5: Operating Wireless Receiver/Microphone

    AN-130+ Speaker Monitor Owners Manual MADE IN USA OPERATING THE WIRELESS MICROPHONE/TRANSMITTER SIX YEAR WARRANTY CHANNEL SELECTION - HANDHELD TRANSMITTER CHANNEL SELECTION - BODY-PACK TRANSMITTER 1. Unscrew battery cover on bottom of microphone 1. The channel selection dial is located on the side of the transmitter 2.

  • Page 6: Having Trouble With You Sound System

    • make sure all cables are completely plugged in • increase volume control • press mute button on remote (AN-130+RC only) • turn power switch to off then back to on (AN-130+RC only) Distorted Sound • check input cable connection •...
