Page 1: User Manual
User Manual Video Door Phone CDV-40N Thank you for purchasing COMMAX products. Thank you for purchasing COMMAX products. Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. -
Page 2: Table Of Contents
4. Operating ....................5 5. Installation ....................7 6. Wiring...................... 8 7. Part list..................... 9 8. Miscellaneous...................9 9. Specifications ..................9 1. Greetings Thank you very much for choosing COMMAX. Please read this manual carefully before you use the product. www.safemag.ru... -
Page 3: Warnings And Caution
www.safemag.ru 2. Warnings and caution Please follow the things described below in order to prevent any danger or property damage. Warning Prohibition. It may cause a serious damage or No disassembly injury if violated. No touch Must follow strictly. Caution Shows plugging out the power cord It may cause a minor damage or without an exception... - Page 4 www.safemag.ru Warning Please don’ t disassemble, If an abnormal sound, burning Please don’t insert any Please use only the designated repair or rebuild this product smell or smoke is coming out metallic or burnable materials batteries for the products of arbitrarily (please contact the of the product, please plug out into the ventilation hole.
-
Page 5: Part Names And Functions
www.safemag.ru 3. Part names and functions Name Description BRIGHT button Adjust brightness COLOR button Adjust color CONT button Adjust contrast RESET button Returned to default color/brightness/Contrast Handset Handset Screen LCD screen 1. Press this button to check the entrance status Monitoring / UP button 2. -
Page 6: Operating
www.safemag.ru 4. Operating 1. Calling of visitor The visitor s The visitor Open the door presses the A chime image appears call button on sounds Dialog begins on the monitor the camera To check Dialog duration 60 seconds at a time A view of the front door can be seen anytime the entrance button is pressed and a dialog can be made Hang-up the... - Page 7 www.safemag.ru (Available only in Monitoring status) 3. BRIGHT / COLOR / CONT setting 1). BRIGHT setting Press Monitoring button when the handset is hung on properly. (LED Blinking) Press BRIGHT button on the left while the screen is turned on. (Beep sound once) Power LED is blinked as fast (BRIGHT control mode) Adjust the Brightness as the user wants by pressing UP / DOWN button...
-
Page 8: Installation
www.safemag.ru 5. Installation 1. Installation Method of camera monitor Note Avoid the range of direct sunlight Recommended height is pertinent from 1450 ~ 1500mm Avoid the installation near magnetic activity, humid temperatures and gas 2. Installation Method of camera Note Do not install the camera where it is exposed to Direct sunlight Keep cleaning up its lens to... -
Page 9: Wiring
www.safemag.ru 6. Wiring 1. Camera connector polarity Red: Voice Blue: GND Yellow: Power (+12V) White: Video 2. Wiring precautions 1) If high voltage cables are present in the vicinity, use a coaxial cable with metal outer casing. 2) If any internal wires are exposed through mis-wiring, it may cause a short and become a cause of malfunction or fire. -
Page 10: Part List
www.safemag.ru 7. Parts List Bracket for wall mount Manual Body of CDV-40N T4 X 18(4EA) M3 X 6(1EA) 4P Connector (2EA) Screw for wall mount Screw for body 8. Miscellaneous ● Please carefully read this User's Guide before calling service man After checking the entire check list, please contact customer service center. - Page 11 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 PM0740N00010 Web site : www.commax.com Printed In Korea / 2011.03.104 www.safemag.ru...
