    User Manual Color video door phone CDV-70U Thank you for purchasing COMMAX products. Thank you for purchasing COMMAX products. Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.
  • Page 2: Table Of Contents

    Greetings Thank you for choosing COMMAX. Please read this manual carefully before you use the product. Table of contents Greetings ........................1 Contents table ......................1 1. Warnings and caution ...................2 2. Product Overview....................4 3. Operation Methods ....................5 4. Settings .........................6 5. Installation ......................8 6.
  • Page 3: Warnings And Caution

    1. Warnings and caution Please follow the things described below in order to prevent any danger or property damage. Warning Prohibition. No disassembly It may cause a serious damage or injury if violated. No touch Caution Must follow strictly. Shows plugging out the power cord It may cause a minor damage or injury if violated.
  • Page 4 Warning Please don’ t disassemble, If an abnormal sound, burning Please don’t insert any Please use only the designated repair or rebuild this product smell or smoke is coming out metallic or burnable materials batteries for the products of arbitrarily (please contact the of the product, please plug out into the ventilation hole.
  • Page 5: Product Overview

    2. Product Overview Description Description Monitor Talk Sound Level Control Speaker Call Sound Level Control On/Off & status LED Menu Button Microphone Select Button Monitor Button Up Button ( ) Interphone Button Down Button ( ) Door Release Button Power Switch Talk Button Connector Terminal 1.
  • Page 6: Operation Methods

    3. Operation Methods 3-1. Receiving a calling from visitor. When the call button is pressed by a visitor on the door camera, the melody shall be rung and visitors' image is shown on the screen (If you do not press the Talk Button, the display will be shown up for 30 seconds and turned off automatically).
  • Page 7: Settings

    4. Settings On talking or monitoring mode, press menu button on the right side of product, and press buttons to adjust display(brightness, contrast, color), to enter the Utility menu, to check the product information. Following 4 buttons on the right side of the product are used for setting. * Move up, right : (UP Button) * Menu, End : MENU...
  • Page 8 ② Select No. 1 : Talk LED is repeated bright and dark mode ③ Select No. 2 : All LEDs are repeated bright and dark mode ④ Select No. 3 : All LEDs are repeated bright and dark mode by turns ✽...
  • Page 9: Installation

    4-3. INFORMATION (Model and Version checking) Click button to check the Model and version in configuration mode (1) Model : The name of Model (2) Version : The version of the product (3) VIDEO : The video type of the product (4) SOURCE : The location of the image 4-4.
  • Page 10: Wiring

    6. Wiring CAMERA CONNECTOR POLARITY 1. RED : VOICE 2. BLUE : GND 3. YELLOW : POWER(+12V) 4. WHITE : VIDEO Caution on the Wiring Be sure to use a separate wiring for each connect 2lines of UTP CABLE[CAT.5] are required if UTP CABLE[CAT.5] is used for CAMERA1 and CAMERA2...
  • Page 11 DOOR Camera Wiring If UTP CABLE[CAT.5] is used, use 5 lines for GND line. INTERPHONE Wiring If UTP CABLE[CAT.5] is used, use 5 lines for GND line.
  • Page 12: Part List

    7. Part list ③ Manual ① Body of CDV-70U ② Bracket for wall mount ⑤ PHM 3 X 6 ZnY ⑥ 4P(2EA) ④ GH1T 4 X 18 ZnY Connector Screw for body Screw for wall mount ① Monitor(CDV-70U) ② Wall bracket ③...
  • Page 13: Caution In Use

    1. Turn on the power switch. 2. Please contact your local agent for product maintenance when you have a problem in use of CDV-70U 3. For your safety, power switch with a safety device must be used in your building.
  • Page 14 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM0270U00011 Printed In Korea / 2012.09.104...
