Replacing the battery

Replacing the battery

To replace the battery, do as follows:
1. Turn off the computer, or enter hibernation mode. Then disconnect the ac
adapter and all cables from the computer.
Note: If you are using a PC Card, the computer might not be able to enter
2. Close the computer display, and turn the computer over.
3. Slide the battery latch to the unlock position 1 ; then remove the battery
4. Align the front of the spare battery with the front side of the battery space
in the computer 3 ; then gently push the battery into the space 4 .
5. Slide the battery latch to the locked position.
6. Turn the computer over again. Connect the ac adapter and the cables to
the computer.
30
®
ThinkPad A30 Series Service and Troubleshooting Guide
hibernation mode. If this happens, turn off the computer.
2 .
