INSTALLER AND OWNER GUIDE
Firefox 5
Model 910
CAST-IRON GAS STOVE
Fitted with a Ceramic Coal fuel effect.
(GC No. 32-264-24)
For further advice please contact the retailer or company
from where you purchased your fire
INSTALLER: Please leave this guide with the owner
©
Baxi Heating U.K. Limited 2010.
5122664/02
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Baxi 910
Summary of Contents for Baxi 910
- Page 1 CAST-IRON GAS STOVE Fitted with a Ceramic Coal fuel effect. (GC No. 32-264-24) For further advice please contact the retailer or company from where you purchased your fire INSTALLER: Please leave this guide with the owner © Baxi Heating U.K. Limited 2010.
- Page 2 Applications for the copyright owner's permission to reproduce any part of this publication should be made, giving details of the proposed use, to the following address: The Company Secretary, Baxi Heating UK Limited, The Wyvern Business Park, Stanier Way, Derby, DE21 6BF.
- Page 3 INSTALLER GUIDE INSTALLER GUIDE FOR OWNER GUIDE SEE PAGES 19 TO 25 © Baxi Heating U.K. Limited 2010. Page 3...
-
Page 4: Table Of Contents
Lighting the burner. Operating the burner. Inlet pressure check. Check for spillage. Flame supervision and spillage monitoring system. 7. FINAL REVIEW AND SERVICING Final Review. Servicing. Checking the aeration setting of the burner. © Baxi Heating U.K. Limited 2010. Page 4... -
Page 5: Installer Guide
When lifting always keep your back straight. Bend your legs and not your back. Avoid twisting at the waist. It is better to reposition your feet. © Baxi Heating U.K. Limited 2010. Page 5... -
Page 6: Appliance Data And Efficiency
The efficiency of this appliance has been measured as specified in BS EN 613 and the result is as below : Model Efficiency % (Gross) 73.1 910 when converted to LPG. 73.1 © Baxi Heating U.K. Limited 2010. Page 6... -
Page 7: Unpacking
The stove is supplied with a locked door. Using a suitable sized spanner, turn the locking bolt on the front of the door in a counter clockwise direction. Carefully remove and unpack the contents of the stove. © Baxi Heating U.K. Limited 2010. Page 7... -
Page 8: Stove Set Up
There may however, be certain circumstances where fitting the restrictor causes the fire to fail the spillage test. In such cases the restrictor will have to be removed. After removal conduct the spillage check again. © Baxi Heating U.K. Limited 2010. Page 8... -
Page 9: Down Draught Deflector
It is important that it sits on top and between the raised cast areas on the rear of the stove body (See figure 3). Secure in place using the nut and washer removed previously. Figure 3. © Baxi Heating U.K. Limited 2010. Page 9... -
Page 10: Burner Module
The screw locations are shown ion figure 5). Secure the control knob assembly to the gas valve, the screw tail should secure onto the flat on the gas valve spindle. Figure 5. © Baxi Heating U.K. Limited 2010. Page 10... -
Page 11: General Installation Requirements
12mm thick. The hearth must protrude at least 150mm (6”) in front of the stove body. In most buildings with solid concrete floors this requirement will be met by the floor itself. © Baxi Heating U.K. Limited 2010. Page 11... -
Page 12: Clearances
The flue must have a minimum effective height of 3 metres (10ft), however to, to Figure 7. ensure optimum performance we recommend 3.66 © Baxi Heating U.K. Limited 2010. Page 12... -
Page 13: Ventilation
BS6891. In the Republic of Ireland check in accordance with the rules in force. Securing the stove. The stove is supplied with two wood screws and wall plugs. Secure the stove in place through the holes in the rear feet. © Baxi Heating U.K. Limited 2010. Page 13... -
Page 14: Fitting The Ceramic Fuel Effect
Depress the control knob slightly to release from the 'LOW' position and turn back (clockwise) to the ‘Pilot ignition’ position. The main burner should extinguish but the pilot should remain alight. © Baxi Heating U.K. Limited 2010. Page 14... -
Page 15: Inlet Pressure Check
Flame supervision and spillage monitoring system. The pilot unit incorporates a system that will automatically shut off the gas supply if the pilot flame goes out. Check that the system operates properly as follows; © Baxi Heating U.K. Limited 2010. Page 15... -
Page 16: Final Review And Servicing
If the appliance is in premises in the United Kingdom occupied by a tenant, point out that by law a landlord must have any gas appliance, flue and pipework which is situated in a tenant’s premises checked for safety at least every 12 months. © Baxi Heating U.K. Limited 2010. Page 16... -
Page 17: Servicing
The ceramic fuel effect guide may have been placed inside or attached to this guide. Always test for gas soundness and spillage after servicing the appliance. © Baxi Heating U.K. Limited 2010. Page 17... -
Page 18: Checking The Aeration Setting Of The Burner
To adjust the aeration setting, loosen the two aeration shutter screws, slide the aeration shutter to the position shown in figure 10 and tighten the fixing screws. Figure 10. Aeration shutter setting © Baxi Heating U.K. Limited 2010. Page 18... -
Page 19: Owner Guide
OWNER GUIDE OWNER GUIDE © Baxi Heating U.K. Limited 2010. Page 19... - Page 20 Your owner guide aims to improve your understanding and appreciation of your gas stove by providing simple and informative instructions to ensure that you benefit from the excellent performance and features it has to offer. © Baxi Heating U.K. Limited 2010. Page 20...
-
Page 21: Safety
The hearth material must be at least 12mm (1/2”) thick and should protrude at least 150mm (6”) in front of the stove body. Do provide the minimum clearances shown in figure 1. Figure 1. Dimensions and Clearances © Baxi Heating U.K. Limited 2010. Page 21... - Page 22 Don’t attempt to clean or service the gas stove until it has been switched off and allowed to cool completely. Don’t leave the stove on if the house is left unoccupied for a long period. We recommend that the stove is turned fully off. © Baxi Heating U.K. Limited 2010. Page 22...
-
Page 23: Operating Your Stove
When the control knob is released the pilot flame should remain lit. If a flame does not appear at the pilot then turn the control knob clockwise to the 'OFF' position and repeat the above. Figure 2. © Baxi Heating U.K. Limited 2010. Page 23... -
Page 24: Operating The Burner
Has a minimum natural gas input of 2.3kW (Gross) Has a minimum natural gas output of 1.68kW Model 910 when converted using kit number 0591011 Has a maximum propane gas input of 5.40kW (Gross) Has a maximum propane gas output of 3.94kW Has a minimum propane gas input of 3.8kW (Gross) -
Page 25: Cleaning Your Stove
Keep the replacement installer and owner guide with this owner guide for future reference. © Baxi Heating U.K. Limited 2010. Page 25... -
Page 26: Maintenance And Servicing
‘interpart stockist network’. For your local stockist consult Yellow pages under Central Heating. When fitting replacement parts it is important that only approved parts are used for maximum safety. © Baxi Heating U.K. Limited 2010. - Page 27 © Baxi Heating U.K. Limited 2010.
- Page 28 © Baxi Heating U.K. Limited 2010.
