5122664/01
INSTALLER GUIDE
Firefox 5
Model 910
CAST-IRON GAS STOVE
Fitted with a Ceramic Coal fuel effect.
(GC No. 32-264-24)
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20).
WHEN CONVERTED USING CONVERSION KIT NO. 0591011 THIS APPLIANCE
IS FOR USE WITH PROPANE GAS (G31).
THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE).
For technical advice firstly contact your retailer.
If further advice is required then call 01204 868550.
INSTALLER: Please leave this guide with the owner
©
Baxi Heating U.K. Limited 2007.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Firefox 5 910 and is the answer not in the manual?

Questions and answers

Related Manuals for Baxi Firefox 5 910

Summary of Contents for Baxi Firefox 5 910

  • Page 1 THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE). For technical advice firstly contact your retailer. If further advice is required then call 01204 868550. INSTALLER: Please leave this guide with the owner © Baxi Heating U.K. Limited 2007.

  • Page 2: Table Of Contents

    Applications for the copyright owner's permission to reproduce any part of this publication should be made, giving details of the proposed use, to the following address: The Company Secretary, Baxi Heating UK Limited, The Wyvern Business Park, Stanier Way, Derby, DE21 6BF.

  • Page 3: Safety

    Always grip with the palm of the hand. Do not use the tips of fingers for support. Always keep the stove as close to the body as possible. This will minimise the cantilever action. Use gloves to provide additional grip. Always use assistance if required. © Baxi Heating U.K. Limited 2007. Page 3...

  • Page 4: Appliance Data

    The conversion of net efficiency to gross was achieved by multiplying the net efficiency by the following conversion factor from Table E3 of SAP 2005, rounding down to the nearest whole number. Conversion factor from net to gross efficiency Natural Gas 0.901 0.921 © Baxi Heating U.K. Limited 2007. Page 4...

  • Page 5: Unpacking

    2 bolts with washers (For the diverter box). 3 self tapping screws (For burner). 1 Flue spigot. 1 Flue restrictor. 2 small machine screws (For flue spigot and flue restrictor). Box 2 - Ceramic fuel effect. © Baxi Heating U.K. Limited 2007. Page 5...

  • Page 6: Stove Set Up

    In such cases the restrictor will have to be Figure 1. removed. After removal conduct the spillage check again. © Baxi Heating U.K. Limited 2007. Page 6...
  • Page 7 (See figure 3). Secure in place using the nut and washer removed previously. Figure 3. © Baxi Heating U.K. Limited 2007. Page 7...
  • Page 8 The screw locations are shown ion figure 5). 10. Secure the control knob assembly to the gas valve, the screw tail should secure onto the flat on the gas valve spindle. Figure 5. © Baxi Heating U.K. Limited 2007. Page 8...

  • Page 9: General Installation Requirements

    12mm thick. The hearth must protrude at least 150mm (6”) in front of the stove body. In most buildings with solid concrete floors this requirement will be met by the floor itself. © Baxi Heating U.K. Limited 2007. Page 9...
  • Page 10 3.66 metres (12ft) or higher. The flue must be free of obstruction and any dampers must be fixed in a permanently open position. Ensure that the chimney is not closed and that it has been swept prior © Baxi Heating U.K. Limited 2007. Page 10...
  • Page 11 BS6891. In the Republic of Ireland check in accordance with the rules in force. Securing the stove. The stove is supplied with two wood screws and wall plugs. Secure the stove in place through the holes in the rear feet. © Baxi Heating U.K. Limited 2007. Page 11...

  • Page 12: Operating The Stove

    'LOW' position and turn back (clockwise) to the ‘Pilot ignition’ position. The main burner should extinguish but the pilot should remain alight. Depress the control knob slightly and turn back (clockwise) to turn OFF. © Baxi Heating U.K. Limited 2007. Page 12...
  • Page 13 Flame supervision and spillage monitoring system. The pilot unit incorporates a system that will automatically shut off the gas supply if the pilot flame goes out. Check that the system operates properly as follows; © Baxi Heating U.K. Limited 2007. Page 13...

  • Page 14: Final Review And Servicing

    12 months. Explain to the customer that when operating the stove for the first time, some © Baxi Heating U.K. Limited 2007. Page 14...
  • Page 15 The ceramic fuel effect guide may have been placed inside or attached to this guide. Always test for gas soundness and spillage after servicing the appliance. © Baxi Heating U.K. Limited 2007. Page 15...
  • Page 16 2. To adjust the aeration setting, loosen the two aeration shutter screws, slide the aeration shutter to the position shown in figure 9 and tighten the fixing screws. Figure 10. Aeration shutter setting © Baxi Heating U.K. Limited 2007. Page 16...
