Mid-sized "MAC Homogenous" StorNext configuration

Apple
OSX
XSAN
Client
HBA HBA
Celerity Celerity
FC-81EN, FC-81EN,
FC-82EN, FC-82EN,
or FC-84EN or FC-84EN
Driver: .3.1b12 Driver: .3.1b12
DS5020
Back
DS5020
Front
EXP520
(optional)
EXP520
(optional)
Example 4. In this example diagram Linux MDC Servers are shown, but only MAC Xsan Clients are shown. DS5020
connected to meshed SAN fabric with a single Fibre Channel switch. For DS5020 configurations, Multiple Fibre Channel
switches are not required, but they are recommended. Drawing shows minimal SAN to DS5020 connections to simplify the
drawing. However, up to 8 connections are supported. In this example, the Meta data Controllers each have a single dual
ported HBA. Also in this example multiple HIC cards on the DS5020 are used to increase resiliency.
Digital Media Storage Solution Installation Guide
© Copyright 2010, IBM Corporation. All rights reserved.
MetaData Ethernet Network
Apple
STORNEXT
OSX
Meta Data
XSAN
Controller
Client
RHEL or SLES
HBA
Celerity
FC-81EN,
FC-82EN,
Standard supported
or FC-84EN
Emulex or Qlogic
Driver: .3.1b12
Zone 1
Controller A
And all host
ports
Controller A
Up to 112 drives maximum
LINUX LINUX
STORNEXT
Meta Data
Controller
RHEL or SLES
RDAC RDAC
HBA HBA
Standard supported
Emulex or Qlogic
FibreChannel Switch
Apple
OSX
XSAN
Client
HBA
Celerity
FC-81EN,
FC-82EN,
or FC-84EN
Driver: .3.1b12
Zone 2
Controller B
And all host
ports
Controller B
Apple
OSX
XSAN
Client
HBA
Celerity
FC-81EN,
FC-82EN,
or FC-84EN
Driver: .3.1b12
