Specifications

The table below lists the specifications for the VSS2 Video Synch Sensor.
Specifications
Power Supply
Power Consumption
Sensitivity
Front Panel
Rear Panel
Enclosure
Dimensions (HWD)
Weight
Included Accessories
Optional Accessories
VSS2 Video Sync Sensor
12 VDC at 20 mA
2.4 W maximum
• Video - 800 mV (typical), 5V (max)
• Sync - 15.75 kHz
• Sensing - 1 kHz to 3 MHz (200 mV rms minimum), 3 MHz to 20 MHz (600 mV
rms minimum), and 20 MHz to 75 MHz (750 mV rms minimum)
• RGB Sensing - Sync on Green, Horizontal Sync
• Output - Open collector with internal pull-up to 5 volts and solid-state logic
low when sync is present.
• Power - Green LED indicator
• Sense 1 - Red LED lights when signal is within sensing range
• Sense 2 - Red LED lights when signal is within sensing range
• Video 1 - RCA jacks for OUT and IN
• Video 2 - RCA jacks for OUT and IN
• Sense Out 1 and 2 - 4-pin Phoenix connector
• 12 VDC-2-pin Phoenix connector
• Delay - None (input connected directly to output)
Metal with black matte finish
1.5" x 5.09" x 5.27" (3.81 cm x 12.93 cm x 13.39 cm)
6.70 oz (189.94 g)
• One 4-pin cable connector
• One 2-pin power connector
• 12 VDC power supply, 20 mA minimum
• AC-RK Accessory Rack Kit
