Installing The VSS2

Rack-Mounting the VSS2 (optional)

To rack-mount the VSS2 into the optional AC-RK Accessory Rack Kit:
1. Remove any connected power, AXlink, and RS-232 connectors from the rear panel.
2. Remove the two screws on the front panel of the VSS2.
3. Remove the front panel and the space bracket behind the panel.
4. Place the unit in the appropriate opening in the AC-RK.
5. Place the front panel of the VSS2 on the front of the rack, over the unit.
6. Fasten the front panel to the rack and to the unit with the two screws you removed.
