To Exit Learn Routine - Python 650 ESP Installation Manual

4. Press the transmitter button: While HOLDING the Valet
button from the transmitter that you wish to assign to the selected channel. The unit will
chirp indicating successful programming. It is not possible to teach a transmitter button
to the system more than once.
Channels #4-6: Channels 4 through 6 are used to assign the arm, disarm and panic functions to separate buttons
on the remote control. Teaching a button to Channel 4 erases all information about that remote from memory.
Any auxiliary functions that are desired will have to be reprogrammed. Similarly, if the remote is set up to use
the separate arm, disarm and panic channels and a button from that remote is entered into channel one, the
remote will be erased from memory, and the system will only recognize the button that was entered into channel
one.
Channel #9: If any transmitter button from a known transmitter is programmed to Channel 9, all transmitters
will be erased from memory and will revert to the default feature settings (see the Features Menu section of this
guide). This is useful in cases where the one of the customer's transmitters is lost or stolen. This will erase any
lost or stolen transmitters from the system's memory. It can also be used to start from scratch if the transmitter
buttons were programmed incorrectly.
5. Release: Once the code is learned, the Valet

to exit learn routine

Learn Routine™ will be exited if:
I Ignition is turned off.
I Door is closed.
I Valet
® /Program button is pressed too many times.
I More than 15 seconds elapse between steps.
One long chirp indicates that Learn Routine™ has been exited.
© 2000 Directed Electronics, Inc. Vista, CA
® /Program switch, press the
®
/Program button can be released.
25
