transmitter configurations

Using the Auto Learn functions in the Transmitter/Receiver Learn Routine, the transmitters can be programmed

either with the standard single button arm/disarm configuration (default) or with the expanded configuration,

which requires an optional 4-button transmitter.

standard single button arm/disarm configuration

When programmed for standard single button arm/disarm configuration, the transmitter buttons are assigned to

the following functions:

Your system has an expanded configuration that can be fully utilized when upgrading to the optional four-button

remote. In the expanded configuration, your system will operate similarly to many factory keyless entry systems

that use separate remote transmitter buttons for the arm, disarm, panic and auxiliary output functions:

The Expanded Configuration also allows the user to utilize Multi-Level Security Arming (described in the follow-

ing section).

NOTE: If a 2-button transmitter is programmed with the expanded configuration, the Panic feature

and Channel 2 output can no longer be controlled by the transmitter.

. . . . . . . . . . operates . . . . . . . . . . Arm/Disarm/Panic

. . . . . . . . . . operates . . . . . . . . . . Channel 2

and

. . . operates . . . . . . . . . . Channel 3

. . . . . . . . . . . operates . . . . . . . . . . . Arm only

. . . . . . . . . . . operates . . . . . . . . . . . Disarm only

. . . . . . . . . . . operates . . . . . . . . . . . Channel 2

. . . . . . . . . . . operates . . . . . . . . . . . Panic

and

. . operate . . . . . . . . . . . . Channel 3
