Summary of Contents for Python 671XP
- Page 1 M M o o d d e e l l 6 6 7 7 1 1 X X P P O O w w n n e e r r ’ ’ s s G G u u i i d d e e P P y y t t h h o o n n...
-
Page 2: L L I I M M I I T T E E D D L L I I F F E E T T I I M M E E C C O O N N S S U U M M E E R R W W A A R R R R A A N N T T Y Y
l l i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y Directed Electronics, Inc. - Page 3 CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE.
-
Page 4: Table Of Contents
t t a a b b l l e e o o f f c c o o n n t t e e n n t t s s l l i i m m i i t t e e d d l l i i f f e e t t i i m m e e c c o o n n s s u u m m e e r r w w a a r r r r a a n n t t y y ................i i 2 2 - - w w a a y y r r e e m m o o t t e e c c o o n n t t r r o o l l d d i i a a g g r r a a m m . -
Page 5: 2 - - W W A A Y Y R R E E M M O O T T E E C C O O N N T T R R O O L L D D I I A A G G R R A A M
2 2 - - w w a a y y r r e e m m o o t t e e c c o o n n t t r r o o l l d d i i a a g g r r a a m m s s t t a a n n d d a a r r d d r r e e m m o o t t e e c c o o n n f f i i g g u u r r a a t t i i o o n n s s Arm/Disarm Indicator (Orange) Receive/Transmit Indicator (Green) - Page 6 w w h h a a t t i i s s i i n n c c l l u u d d e e d d One control module An XHF2 transceiver/antenna One 4-button 2-way remote Stinger Doubleguard ®...
-
Page 7: System Maintenance
system maintenance This system needs no specific maintenance beyond 2-way remote control battery replacement. The 2-way remote is powered by a 1.5V AAA battery. Low Battery Notification If the battery is low (and this feature is programmed On) the 2- way remote will emit 2 long beeps 5-seconds after a transmission is completed. -
Page 8: Fcc/Id Notice
fcc/id notice This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesirable operation. -
Page 9: 2 - - W W A A Y Y R R E E M M O O T T E E C C O O N N T T R R O O L L F F U U N N C C T T I I O O N N S
2 2 - - w w a a y y r r e e m m o o t t e e c c o o n n t t r r o o l l f f u u n n c c t t i i o o n n s s The 2-way remote control buttons are used to send commands to the system. -
Page 10: System Signal Paging Features
Buttons An optional auxiliary convenience or expansion function that you have added to your system can be activated by pressing these buttons simultaneously. The auxiliary output controls __________________________. r r e e m m o o t t e e o o p p e e r r a a t t i i o o n n The remote start system operates at 434 MHz and incorporates Directed’s proprietary XHF2 out-board technology transceiver. - Page 11 Alarm Page If the alarm system is triggered while armed, an Alarm Page will be sent to the remote control. When the remote receives an Alarm Page, the LED icons will display the alarm system status information and the remote control will generate beeps. An Alarm Page alert is a series of 10 or 4 rapid beeps and the Red LED will illuminate.
-
Page 12: Out Of Range Notification
out of range notification If a command is issued from the remote, but the remote is beyond the range of the vehicle to receive the command, the remote responds with 2 sets of 3 quick beeps and the Green LED will flash 6-times. -
Page 13: Active Arming
Page notification The remote control can be programmed to notify the user of a page (audibly beeping if the vehicle’s status changes, e.g. door unlocked, engine started, vehicle violation, etc.). Press select page On/Off. One beep is page On, Two beeps is page Off. When programmed off the remote will not give any notification that a page was received from the vehicle. - Page 14 second chirp after arming and note that the in-vehicle’s status LED is flashing in groups, see the Diagnostics Section of this guide. This extra chirp is called Bypass Notification. The remote responds to active arming with one beep and the Orange LED will flash 3-times to indicate successful arming of the system.
- Page 15 The remote responds to passive arming with one beep and the Orange LED will flash 3-times to indicate successful arming of the system. note: If any protected entry point (such as a door or a switch-protected trunk or hood) is open, the system will not passively arm (unless forced passive arming is pro- grammed on.
-
Page 16: Multi-Level Security Arming
multi-level security arming Multi-Level Security Arming allows you to select which of the system's inputs or sensors will be active and which will be bypassed when the system is armed. (See Table of Zones section of this guide.) Pressing again within five seconds of arming the system will activate the Multi-Level Security feature. -
Page 17: Arming While Driving
After each press of the remote will emit normal arm notification (1 beep and 3 flashes of the Orange LED). For easiest operation in reaching each level of security, press immediately a a f f t t e e r r each notification. arming while driving Your security system can be armed while driving the vehicle! Simply press... -
Page 18: High Security Disarm
The remote will indicate disarm notification with 2 beeps and 3 flashes of the Orange LED. If disarming after the system has been triggered, the remote control will send a diagnostic notifi- cation as a reminder. These diagnostic notifications are: 1. -
Page 19: Disarming Without A 2-Way Remote
notes: The first press of the remote button, while the remote is beeping, only clears the alarm page (no com- mand is sent to the vehicle). The transceiver transmits immediately upon system trig- ger and does not allow disarm during the first 6 seconds after trigger. -
Page 20: Silent Mode
important! The unit can be programmed to respond to one to five pulses of the Valet function. Be sure to check with the installer for the desired programming. The remote will indicate disarm notification with 2 beeps and 3 flashes of the Orange LED. silent mode To temporarily turn off the arm or disarm chirps, use Silent Mode™. -
Page 21: Panic Mode
panic mode If you are threatened in or near your vehicle, you can attract attention by triggering the system with your 2-way remote. Just press for two seconds, and you will enter Panic Mode. The siren will sound and the parking lights will flash for the programmed siren duration. -
Page 22: Nuisance Prevention Circuitry
To enter or exit Valet ® Mode using the 2-way remote: 1. Open any vehicle door. 2. Press 3. Press 4. Press again. The in-vehicle status LED will light solidly if you are entering Valet Mode, and it will go out if you are exiting Valet ®... - Page 23 note: Arming and disarming the system does not reset this function.The only ways to reset a bypassed zone are for it to not trigger for 60 minutes, or to turn on the ignition. If testing your system, it is important to remember that the NPC®...
-
Page 24: Arming Diagnostics
This occurs at the remote after the system has received the com- mand to activate any of the Auxiliary outputs. d d i i a a g g n n o o s s t t i i c c s s The microprocessor at the heart of your security system is constantly monitoring all of the switches and sensors that are connected to it. -
Page 25: Disarming Diagnostics
disarming diagnostics Extra disarm chirps are the Tamper Alert. If four chirps are heard when disarming, the system was triggered in your absence. If five chirps are heard, a zone was triggered so many times that Nuisance Prevention Circuitry has bypassed that zone. The in-vehicle status ®... -
Page 26: Table Of Zones
table of zones The zone number is the number of in-vehicle LED flashes used by the system to identify that input. The standard input assign- ments are listed below, along with spaces to write in any optional sensors or switches you have had installed. Zone - Number of LED Flashes Description... - Page 27 c c o o d d e e h h o o p p p p i i n n g g The receiver and 2-way remotes each use mathematical formulas called algorithms to change their codes each time the 2-way remote is used.
- Page 28 o o w w n n e e r r r r e e c c o o g g n n i i t t i i o o n n Owner Recognition is a feature available exclusively from Directed.
- Page 29 p p o o w w e e r r s s a a v v e e r r m m o o d d e e Your system will automatically enter Power Saver Mode while armed or in Valet ®...
- Page 30 A A c c t t i i v v e e a a r r m m i i n n g g (only with the 2-way remote) or passive arming (automatic arming 30-seconds after the last door has been closed).
- Page 31 ajar when leaving the vehicle. Forced passive arming ensures that the security system will be armed in every situation. note: When the system passively arms after one hour, the entry point that has been left open, and anything con- nected to the same zone, is bypassed and cannot trigger the system.
- Page 32 security system with the Directed Bitwriter, the full triggered response can be programmed for any duration ranging from 1 to 180 seconds. Nuisance Prevention ® ® section of this manual for a complete explanation of how NPC operates. If NPC ®...
-
Page 33: E E H H I I C C L L E E R R E E C C O O V V E E R R Y Y S S Y Y S S T T E E M M ( ( V V R R S
i i n n s s t t a a l l l l a a t t i i o o n n o o p p t t i i o o n n s s The system has many options that may require extra parts and labor. -
Page 34: Arming The Vrs
Directed has engineered this vehicle security system, the Failsafe Starter Kill, and the VRS tion of personal safety and property protection available. When properly installed, the system can never inadvertently stop your vehicle in traffic or on railroad tracks while the vehicle is in oper- ation. -
Page 35: Vrs Triggered Sequence
if someone takes your keys and 2-way remote by force in a parking lot. note: If the VRS system is armed while operating the vehi- ® cle and not disarmed prior to leaving the vehicle, it is still armed and will trigger the next time the vehicle is driven. triggered sequence ®... -
Page 36: Disarming The Vrs
disarming the vrs ® Take the time to familiarize yourself with the VRS quence and the disarm procedure. It is important to recognize and identify the VRS trigger sequence and know how to disarm ® it in case of accidental activation. Once the VRS is armed, it does not disarm automatically. - Page 37 g g l l o o s s s s a a r r y y o o f f t t e e r r m m s s : Hand-held, 2-way transceiver which operates the 2-Way Remote various functions of your system. The "brain"...
- Page 38 This is what happens when the Trigger or Triggered Sequence: alarm "goes off" or "trips". The triggered response of your system consists of the siren sounding and parking light flashing for the programmed duration. : A small push-button switch mounted somewhere Valet ®...
- Page 39 s s e e c c u u r r i i t t y y & & c c o o n n v v e e n n i i e e n n c c e e e e x x p p a a n n s s i i o o n n s s Here we have listed only some of the many expansion options available.
- Page 40 power activated, then Directed's 522T trunk release solenoid can often be added. Automatic power window control is pro- Power Window Control: vided with the 529T and 530T systems. This system is compatible with Directed Video’s Mobile Video: MCB1000 Multi-Channel Controller, featuring on-screen secu- rity system programming and zone trigger information.
- Page 41 © 2004 directed electronics, inc.
-
Page 42: Quick Reference Guide
QUICK REFERENCE GUIDE To arm using your 2-way remote You can activate, or arm, the system by pressing second. When the system arms, you will hear a short siren sound, or chirp, and the parking lights will flash once. If the vehicle’s power door locks have been connected to the system, the doors will lock. - Page 43 The company behind this system is Directed Electronics, Inc. Since its inception, Directed has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of more than 20 patents in the field of advanced electronic technology, Directed is ISO 9001 registered.
