Controlling the projector through a LAN
environment
®
The projector supports Crestron
Network menu, you can manage the projector from a computer using a web
browser when the computer and the projector are properly connected to the
same local area network.
Wired connection
Internet
1
Take a RJ45 cable and connect one end to the RJ45 LAN input jack of the
projector and the other end to the RJ45 port .
2
Press Menu on the keypad or remote and then go to Advanced Menu > Setup
> Network menu.
3
Press v to highlight DHCP and press
4
Press v to highlight Apply and press >.
5
Please wait for around 15 - 20 seconds, and then re-enter the Network page.
The IP address, Subnet Mask, Default Gateway, DNS and MAC Address
settings will be displayed. Write down the IP address displayed in the IP
address row.
• If the Projector IP Address still does not display, contact your network
administrator.
• If the RJ45 cables are not properly connected, the IP Address, Subnet Mask,
Default Gateway, DNS and MAC Address settings will display 0.0.0.0. Make
software. With correct settings for the
IP Router
< or > to select On.
sure the cables are properly connected and perform the procedures above
again.
• If you need to connect to the projector in its standby mode, set the Power
Saving Mode feature to Off.
If you are in a non-DHCP environment:
1
Repeat steps 1-2 above.
2
Press v to highlight DHCP and press < or > to select Off.
3
Contact your network administrator for information on the IP address, Subnet
Mask, Default Gateway and DNS settings.
4
Press ^ or v to select the item you want to modify.
5
Press < or > to move the cursor and then press ^ or v to select the value.
6
Press v to highlight Apply and press > to save the settings.
• If the RJ45 cables are not properly connected, the IP Address, Subnet Mask,
Default Gateway, DNS and MAC Address settings will display 0.0.0.0. Make
sure the cables are properly connected and perform the procedures above
again.
• If you wish to connect to the projector in its standby mode, be sure to
select RJ45 and obtain the IP Address, Subnet Mask, Default Gateway, DNS
and MAC Address information when the projector is on.
(
Wired LAN
DHCP
IP Address
Subnet Mask
Default Gateway
DNS
MAC Address
Apply
Previous
31
)
MDL: IN2124a
FW: 1.10
◄ On ►
192. 168. 0. 157
255. 255. 255. 0
192. 168. 0. 1
192. 168. 0. 1
00. 60. E9. 0F. 30. 94
Execute
