AUTO OPERATION

• Air-Conditioner(s) automatically selects the
proper room temperature.
1. Press the MODE button on the Remote Con-
trol, and select AUTO (
2. Press the ON/OFF
STOP
Press the ON/OFF button again.
• Auto Mode controls every function of the air conditioner in
order for you to feel as comfortable as possible.
• The operation is automatically controlled according to
the room temperature and humidity. (When you turn on
the unit again within 2 hours of operation, the operation
proceeds in the same way as before.)
Room
Operating
Temperature
Over 27°C (81°F)
20~27°C (68~81°F)
Below 20°C (68°F)
• The room temperature is adjustable as you desire by
pressing the room temperature setting.
• The adjustable range is up to 4°C (8°F) plus or minus.
• Automatic operation will not show the set room tempera-
ture.
• The room temperature automatically appears in the dis-
play indicator about 5 seconds after adjustment.
ECR International
)mode.
button.
Set Temp.
Mode
26°C (79°F):18/24K
Cool
27°C (81°F):9/12K
Monitor
Dry
24°C (75°F)
Heat
OPERATION
• If you want the room thermostat to monitor the difference
between room temperature and set temperature, select
either COOL or DRY mode.
• In the DRY mode, the fan is running to remove the humid-
ity without dropping the room temperature.
• If Dry mode is selected, the Indoor/Outdoor Unit(s) can
be controlled very precisely and the humidity inside the
room is removed. Recommended at humid weather such
as rainy days, etc. When outside temperature is too low
or room size is too small, the room temperature may go
down further than the set point.
• When the room temperature is below 59° F , the opera-
tion is stopped and the unit is switched to the Wait Mode
at which time the room temperature is monitored.
• In case you are not satisfied with various conditions of
automatic operation, you can select these conditions as
you wish.
• Select HEAT, DRY, Cool or CIRCULATE mode as you wish.
1
Press the MODE button on the Remote Control.
• Cold weather
• High humidity
• Hot weather
• When air circulation is needed
2
Press the ON/OFF
button
When the fan speed or air flow direction is to be changed.
• When the set temperature is to be changed:
Press the SET TEMP
5

DRY MODE

MANUAL OPERATION

HEAT
DRY
COOL
CIRCULATE
button.
Each press changes
unit of temperature
16° ° ° ° ° C (61° ° ° ° ° F)
Temperature Range
Lower Limit
Hyundai Ductless Split System
mode
mode
mode
mode
1° F.
30° ° ° ° ° C (86° ° ° ° ° F)
Upper Limit
