ELECTRICAL SPECIFICATIONS AND SYSTEM PERFORMANCE
Single Zone
System
HCW9000
HCW12000
HHW12000
HCW18000
HHW18000
HCW24000
HHW24000
(1) Indoor 80/67º F, Outdoor 95º F
(2) Indoor 70/58º F, Outdoor 47º F
Cooling Capacity
Multi-Zone
(Btuh)
System
(5)
Nominal Sensible
(1)
HMCW18000 18,000 12,600
(2)
HMHW18000 17,400 11,700
(3)
HMCW24000 24,000 15,500
(4)
HMHW24000 21,000 14,100
(1) HMCW18000 consists of tw o HACM09DB (9,000 Btuh) air handlers and one HCCM09DB condenser.
(2) HMHW18000 consists of tw o HAHM09DB (9,000 Btuh) air handlers and one HCHM09DB condenser.
(3) HMCW24000 consists of tw o HACM12DB (12,000 Btuh) air handlers and one HCCM12DB condenser.
(4) HMHW24000 consists of tw o HAHM12DB (12,000 Btuh) air handlers and one HCHM12DB condenser.
(5) Indoor 80/67º F, Outdoor 95º F
• Insert the wall cap into the wall, and fill the gap with sealant to prevent rain or wind.
• When using the pipe cover, fill the gap in the wall through hole in the inside.
ECR International
CABLE CONNECTION 18/24 Btuh (Single Zone Only)
4. Fix the connecting wire between units, with wiring fixture.
5. Attach the wiring cover.
Cooling Capacity
SEER
(1)
Nominal Sensible
10.9
9,500 7,030
12,000 8,760 10.6
12,000 8,760 10.4
20,000 14,200 10.7
20,000 14,200 10.3
24,000 16,800 10.3
24,000 16,800 10.0
Heating
SEER Capacity HSPF Volts/HZ/Phase
(6)
(Btuh)
10.9 - - 208/230/60/1
10.0 17,700 6.8 208/230/60/1
10.6 - - 208/230/60/1
10.0 21,250 6.8 208/230/60/1
(6) Indoor 70/58º F, Outdoor 47º F
COMPLETION OF INTERCONNECTING TUBING
Heating Capacity
HSPF Volts/HZ/Phase
(2)
(Btuh)
- 208/230/60/1
-
- 208/230/60/1
-
208/230/60/1
12,500 7.2
208/230/60/1
- -
208/230/60/1
20,000 6.9
208/230/60/1
- -
208/230/60/1
24,000 6.8
Compressor
Cond Fan Mtr
Circuits 1 & 2
AMPS HP RLA
0.72 0.2 4.45
0.72 0.2 4.45
0.72 0.2 5.85
0.72 0.2 5.85
16
Total Max.
MCA
Amps Fuse
5.0 6.1 15
6.2 7.6 15
6.2 7.6 15
10.2 12.5 20
10.2 12.5 20
12.1 14.8 25
12.0 14.8 25
Indoor Fans Total
MCA
Amps
LRA AMPS HP
26 0.22 0.06 10.1 11.1
26 0.22 0.06 10.1 11.1
29 0.22 0.06 12.9 13.4
29 0.22 0.06 12.9 13.4
Hyundai Ductless Split System
HACR Min
BRKR Volt
15 197
15 197
20 197
20 197
