Model No.
Pick-ip Device
Power Sources
Wire installation
Minimum Illumination
Communication Ways
Hori./Vert. Frequency
Angular Field Of Adjust
Ambient Operating Temperature
Dimensions(W/H/D)mm
For Installation (with cable)
Accessories
External design, features, functions and specifications of the product can be changed without any prior, for promoting the quality of the
products.
Specification
DRC- 40CS
1/4" Color CCD Camera
DC 12V (Power supply fromthe monitor)
4 Wires Polarity/2Wires Non-polarity
3.0Lux
Synchronous Communications
Horizontal:15.735KHz/60Hz
Horizontal : 68 Vertical : 12
-10 C to +40 C
99.5/141.5/.37
For Use TIV 0.65 : 50m
For Use Coaxial Cable C5 2V :100m
T4 x 18mm : 2ea
M3 x 10mm : 1ea
7
DRC-40BS
1/3" B&W CCD Camera
0.1 Lux (For front 300mm)
Vertical :15.625KHz/50Hz
Up:8 C Down:12 C
Model No DRC-40CS/40BS
For More Information, Contact to Web Site
www.commax.co.kr
Printed in Korea
04/2002
Rev.A
